Wind Crest CTG365D Install Quick Specs

Installation Type

Drop into countertop opening
Overall & Cutout Dimension(s)
CTG365D A
Overall 36"
D
Cutout 35 3/8"

Standard Features

•
304 Series, 18 gauge stainless steel
maintop and frame
•
Five high output burners (Model:
CTG365D)
•
Individual burner electronic ignition and re-
ignition system
•
One-piece brass burner heads for durability
and more precise flame control
•
Low grate profile of only ¾" above
countertop
•
Shallow rough-in box depth for extra
cabinet storage
•
Die cast, counter balanced control knobs

Finishes

•
Stainless Steel (S)

Optional Upgrades

•
Cast Wok Ring (Model: WOKRING)
•
Liquid Propane (LP) models available

Gas Supply Requirements*

NG Standard: ½"regulator (6 to 14 inches
water column/Manifold at 4-inches)
LP Standard: ½" regulator (11 to 14 inches
water column/Manifold at 10-inches)
*Regulator ships in box with cooktop. LP gas tank
must have its own pressure regulator in addition to
the one provided with the cooktop

Maximum Power Supply Required

15 Amps @ 120 V AC, 60 Hz, single phase
Cooktop comes with a 4' long, grounded cord.
Copyright 2006 Wind Crest by CNP Industries
Install Quick Specs are for planning purposes only. Please refer to the detailed installation
instructions, prior to making any cutouts.
Drop in Gas Cooktops – Install Quick Specs
CTG 36" Wide
B C
20 1/8" 2 29/32"
E
19 1/2"
A three-prong grounded receptacle is required.
Gas supply and electric are located off the right
rear of the cooktop.
Cooktop Carton Weight:
CTG365D = 83 lbs.
B
E
D
A
C
3-1/16 MIN TO
FRONT EDGE
GAS-FIRED
U L
C US
1
2-5/16
MIN
