CYBEX VR3 Lat Pull Owner's And Service Manual page 40

6
7
8
8
7
8
8
7
8
8
7
8
Service
Page 6-10
Cybex VR3 12130 Lat Pull Owner's Manual
8
8
7
8
8
8
8
8
7
8
Heavy Stack Assembly Configuration
ITEM QTY
1 1
2 1
3 1
4 2
5 2
6 1
7 12
8 15
7
9 2
10 3
7
11 1
12 1
7
7
7
TORQUE SET SCREWS
300-350 IN./LBS
12
10
7
3
2
4
9
9
5
12020-021
PART NO. DESCRIPTION
11040-007 Top Weight Assembly 15
12000-378 Support
12000-384 Panel, Insert
12000-388 Extrusion, Inc Wt Channel
12102-330 Insert, Increment Weight
3900-441 Decal, Cybex
HF579000 Panel Fastner, 10-24 U Type
HX570412 BHSCS 10-24 x 50 SS
11040-409 Molded Bumper
HY740000 Set Screw
11040-216 Belt Clamp
11040-301 Belt Clamp insert
4
1
5
