Goodman CONDENSING UNIT HEAT PUMP Installation & Service Reference page 12

Submenu Item
Number of AC Stages (CL STG)
Number of HP Stages (HT STG)
AC Tonnage (TONS)
Submenu Item
Fault 1 (FAULT #1)
Fault 2 (FAULT #2)
Fault 3 (FAULT #3)
Fault 4 (FAULT #4)
Fault 5 (FAULT #5)
Fault 6 (FAULT #6)
Clear Fault History (CLEAR)
NOTE: Consecutively repeated faults are shown a maximum of 3 times
Submenu Item
Model Number (MOD NUM)
Serial Number (SER NUM)
Software (SOFTWARE)
Submenu Item
Outdoor Air Temperature
(AIR TMP)
Outdoor Coil Temperature
(COIL TMP)
Subm e nu Ite m
Cool Airflow Trim
(CL TRM)
Cool Airflow Profile
(CL PRFL)
Cool ON Delay
(CL ON)
Cool OFF Delay
(CL OFF)
Dehumidification Select
(DEHUM)
A C /H P
IR ONDITIONER EAT
CONFIGURATION
Indication (for Display Only; not User Modifiable)
Displays the number of air conditioning stages; applies to AC and
Displays the number of heat pump stages; applies to HP only.
Displays the air conditioning tonnage; applies to AC and HP.
DIAGNOSTICS
Indication/User Modifiable Options
Most recent AC/HP fault
Next most recent AC/HP fault
Next most recent AC/HP fault
Next most recent AC/HP fault
Next most recent AC/HP fault
Least recent AC/HP fault
NO or YES
IDENTIFICATION
Indication (for Display Only; not User Modifiable)
Displays the air conditioner or heat pump model number
Displays the air conditioner or heat pump serial number (Optional)
Displays the application software revision
SENSORS
User Modifiable Options
Displays the outdoor air
temperature
Displays the outdoor coil
temperature
COOL SET-UP
Use r Modifia ble Options
-10% to +10% in 2% increments,
default is 0%
A, B, C, or D, default is A
5, 10, 20, or 30 seconds, default
is 5 seconds
30, 60, 90, or 120 seconds,
default is 30 seconds
ON or OFF (default is OFF)
A F
UMP DVANCED EATURES
Sensor may or may not be available on an
air conditioner. Check air conditioner
instructions for details.
Required for heat pump operation.
Selects the airflow trim amount; applies to
air conditioner only.
Selects the airflow profile; applies to air
conditioner only.
Selects the indoor blower ON delay;
applies to air conditioner only.
Selects the indoor blower OFF delay;
applies to air conditioner only.
Selecting "OFF" disables dehumidification;
selecting "ON" enables dehumidification;
applies to air conditioner only.
12
M
ENUS
Comments
For display only
For display only
For display only
For display only
For display only
For display only
Selecting "YES" clears the fault
history
Comments
Com m e nts
