LevelOne FSW-0513 Specifications

4-Port High Power PoE +
1 FE Switch
H/W Version: 1
FSW-0513 (-Z) is a 10/100Mbps Fast Ethernet Switch
with 4 High-Power Power over Ethernet ports and one
uplink port. With a total power budget of 120W, FSW-
0513 (-Z) is excellent for deploying network devices
that require high-power such as outdoor security
dome cameras and access points. And with high-
power PoE, the reach of devices can be extended
hundreds of meters.
With 4 dip switches, each PoE port can be manually
set for On-Off control. The internal PoE power supply
Key Features
- IEEE 802.3af PoE compatible to simplify deployment
and installation
- Supports auto-negotiation and auto-MDI/MDI-X
cable detection on each port
- Store-and-Forward architecture to ensure error-free
communications
- IEEE 802.3x flow control protects against lost packets
for reliable data transmission
- Simple Plug and Play installation
- Total PoE power budget: 120W, up to 48W per port
- Control Per PoE port on-off by dip switch
- Power protection: OVP/OCP/OTP
2
1 2 3
can send up to 48 Watts to a single port. FSW-0513 (-Z)
is compact in size, making it ideal for desktop users
with limited space. You also have option of installing
several FSW-0513 (-Z) in a 19" chassis (POC-6000) for a
large-scale rack-mount PoE solution.
Power Protection
FSW-0513 (-Z) supports power protections as
OVP (Over Voltage Protection), OCP (Over Current
Protection), robust short-circuit protection and surge
protection.
4 5
Works well with
FSW-0513 (-Z)
1. LED Indicators
2. PoE On-Off dip Switch
3. 10/100Mbps RJ-45 Uplink Port
4. External power socket
5. 10/100Mbps RJ-45 PoE Ports
POC-6000
8-Bay High Power PoE Chassis for
FSW-0503(-Z) / FSW-0513(-Z) &
GEP-0520(-Z)
FCS-4041
2-Megapixel P/T/Z PoE Plus Speed
Dome Outdoor Network Camera
