LevelOne FSW-0507TX Datasheet

LevelOne's FSW-0507TX Fast Ethernet Switch is designed for
easy installation and high performance in an environment where
traffic on the network and the number of user increase
continuoulsy. This switch is equipped with 5 Fast Ethernet ports
and reaching the highest bandwidth up to 200Mbps for each
port to provide workstations with a congestion-free data pipe for
simultaneous access to the server.
This FSW-0507TX combines dynamic memory allocation with a
store-and-forward switching architecture to ensure that the
buffer is effectively allocated for each port. It also controls the
data flow between transmit and receive nodes to guarantee
against all possible packet loss. With Auto-MDIX function for
each port, this switch is expandable by cascading two or more
switches together by uplinking directly without cable selection
hassle.
The switch with small and compact size is specially designed to
fit in space-limited locations and for small to middle workgroup.
With the accessory kits, the device can be standable on the
desk or mounted on the wall. Users can immediately access
any of the features of this product simply by attaching the cables
and turning on the power. For instant error detection, the switch
is equipped with a full range of LEDs to help you monitor and
troubleshoot problems on your network.
5-port 10/100 Mbps Gigabit Switch
Complies with IEEE 802.3, 802.3u and 802.3x
Supports Nway auto-negotiation for speed and
duplex modes for each port
Auto MDIX function for unlinking at each port
Store-and-Forward switching architecture
Front-panel diagnostic LEDs
IEEE 802.3x flow control for full-duplex
Back pressure flow control for half-duplex
Datasheet_FSW-0507TX
5-port 10/100 Mbps Switch
Key Features
FSW-0507TX
Standable Wall-Mountable
