VEI-30 Dinion Infrared Imager
www.boschsecurity.com
The Dinion Infrared Imager is a rugged, active infrared
surveillance camera designed to master perimeter
surveillance and other outdoor low-light applications.
The IR Imager provides best-in-class images day and
night covering up to 160 meters (525 feet) with
unrivaled illumination quality throughout the field of
view.
From the most challenging daylight conditions to zero
lux night environments, the VEI-30 gives you the
details you need. Our Dinion 2X technology provides
optimal 20-bit imaging in natural and artificial light,
giving you a powerful wide dynamic range camera
solution capable of handling the most demanding
lighting situations, 24 hours a day.
Variable Field Illumination allows IR beam pattern
adjustments in the field, allowing for wide area
coverage and greatly reducing maintenance and setup
time and effort. Variable Field Illumination also
provides even illumination not only across the field of
view but also from foreground to background. To
ensure this performance never fades over time, the IR
Imager features Constant Light technology, using
closed loop feedback to control infrared performance
throughout the life of the unit.
Certified all-weather active IR surveillance camera
u
specifically designed for perimeter surveillance and
other outdoor low-light applications
Dinion 2X imaging with wide dynamic capability to
u
handle the most demanding lighting situations
Variable Field Illumination technology provides
u
unmatched low-light and no-light performance
Integrated junction box, remote control, and
u
complete external adjustments minimize installation
time and cost
The IP67-rated junction box and the camera can be
hung and connected in seconds, reducing time and
energy on the ladder. The Bilinx (up-the-coax) remote
control further reduces time needed for adjustments
during and after installation by allowing for
adjustments to be made remotely on the ground.
Functions
DCRI Zero Lux Performance
850 nm
Range Horizontal
Field of
Illumination
Detectio 160 m 28 m
n (525 ft) (90 ft)
Classific 120 m 21 m
ation (390 ft) (70 ft)
Recognit 90 m 16 m
ion (295 ft) (50 ft)
Identific 50 m 9 m
ation (165 ft) (30 ft)
940 nm
Range Horizontal
Field of
Illumination
80 m 14 m
(260 ft) (45 ft)
60 m 10 m
(195 ft) (35 ft)
45 m 8 m
(150 ft) (25 ft)
25 m 4 m
(80 ft) (15 ft)
