Page 1: Microwave Oven
S/M No. : R63U50S001 Service Manual Microwave Oven Model: KOR-63U50S KOR-63V50S KOR-63W50S KOR-63X50S KOR-63Y50S DAEWOO ELECTRONICS CO., LTD. http : //svc.dwe.co.kr Mar. 2002... -
Page 2: Table Of Contents
PRECAUTIONS TO BE OBSERVED BEFORE AND DURING SERVICING TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not operate or allow the oven to be operated with the door open. (b) Make the following safety checks on all ovens to be serviced before activating the magnetron or other micro- wave source, and make repairs as necessary: (1) Interlock operation, (2) Proper door closing, (3) Seal and sealing surfaces (arcing, wear, and other damage), (4) Damage to or loosening of hinges and latches, (5) Evidence of dropping or abuse. -
Page 3: Safety And Precautions
SAFETY AND PRECAUTIONS 1. FOR SAFE OPERATION Damage that allows the microwave energy (that cooks or heats the food) to escape will result in poor cooking and may cause serious bodily injury to the operator. IF ANY OF THE FOLLOWING CONDITIONS EXIST, OPERATOR MUST NOT USE THE APPLIANCE. (Only a trained service personnel should make repairs.) (1) A broken door hinge. -
Page 4: Specifications
SPECIFICATIONS MODEL KOR-63U50S/63V50S/63W50S/63X50S POWER SUPPLY 230V, 50Hz, SINGLE PHASE WITH EARTHING MICROWAVE 1200 W POWER CONSUMPTION GRILL COMBINATION MICROWAVE ENERGY OUTPUT 800W MICROWAVE FREQUENCY 2450MHz OUTSIDE DIMENSIONS (W X H X D) 465 x 279 x 360 mm (18.3 x 11.0 x 14.2 in.) CAVITY DIMENSIONS (W X H X D) 290 x 220 x 306 mm (11.4 x 8.7 x 12.0 in.) -
Page 5: External View
EXTERNAL VIEW 1. OUTER DIMENSION... -
Page 6: Feature Diagram
2. FEATURE DIAGRAM 1. SAFETY INTERLOCK SYSTEM 2. DOOR VIEWING SCREEN Allows viewing of food. The screen is designed so that light can pass throught, but not the microwave. 3. DOOR HOOK When the door is closed, it will automatically shut. If the door is opened while the oven is operating, the magnetron will immediately stop operating. -
Page 7: Installation
This appliance is supplied with cable of special type, which, if damaged, must be repaired with cable of same type. Such a cable can be purchased from DAEWOO and must be installed by a Qualified Person. 6. Examine the oven after unpacking for any damage such as: A misaligned door, broken door or a dent in cavity. -
Page 8: Operations And Functions
OPERATIONS AND FUNCTIONS 1. Connect the main lead to an electrical outlet. NOTE 2. After placing the food in a suitable container, open the oven 1. When setting timer for less than 2 min- door and put it on the glass tray. The glass tray must always utes, turn the timer past 2 minutes and be in place during cooking. -
Page 9: Disassembly And Assembly
DISASSEMBLY AND ASSEMBLY Cautions to be observed when trouble shooting. Unlike many other appliances, the microwave oven is high-voltage, high-current equipment. It is completely safe during normal operation. However, carelessness in servicing the oven can result in an electric shock or possible danger from a short circuit. You are asked to observe the following precautions carefully. - Page 10 1. To remove cabinet 1) Remove three screws on cabinet back. 2) Push the cabinet backward. 2. To remove door assembly 1) Remove a screws which secure the stopper hinge top. 2) Remove the door assembly from top plate of cavity. 3) Reverse the above for reassembly.
- Page 11 3. To remove door parts. REF NO. PART CODE PART NAME DESCRIPTION Q’TY REMARK 3512202040 FRAME DOOR ABS SG-175, SG-0760D KOR-63U50S 3512202010 FRAME DOOR ABS SG-175, SG-0760D KOR-63V50S 3512202070 FRAME DOOR ABS SG-175, SG-0760D KOR-63W50S 3512202030 FRAME DOOR ABS SG-175, SG-0760D...
- Page 12 (1) Remove the gasket door from door weld as. (2) Remove the barrier screen inner from door weld as. (3) Remove the door frame from door weld as. (4) Remove the stopper hinge top from door weld as. (5) Remove the spring and the hook. (6) Remove the supporter barrier screen outer from door frame.
- Page 13 3513402690 KNOB VPC ABS XR-401, PA-777B/D KOR-63W50S 3513402680 KNOB VPC ABS XR-401, PA-777B/D KOR-63Y50S 3516709850 CONTROL PANEL ABS XR-401, PA-777B/D KOR-63U50S 3516709810 CONTROL PANEL ABS XR-401, PA-777B/D KOR-63V50S 3516709870 CONTROL PANEL ABS XR-401, PA-777B/D KOR-63W50S 3516709840 CONTROL PANEL ABS XR-401, PA-777B/D...
- Page 14 6. To remove high voltage capacitor. 1) Remove a screw which secure the grounding ring terminal of the H.V. diode and the capacitor holder. 2) Remove the H.V. diode from the capacitor holder. 3) Reverse the above steps for reassembly. High voltage circuit wiring 7.
- Page 15 8. To remove wind guide assembly. 1) Remove a screw which secure the wind guide assembly. 2) Remove the noise filter from the wind guide. 3) Remove a screw which secure the wind guide assembly. 4) Draw forward the wind guide assembly. 5) Pull the fan from the motor shaft.
-
Page 16: Interlock Mechanism And Adjustment
INTERLOCK MECHANISM AND ADJUSTMENT The door lock mechanism is a device which has been specially designed to completely eliminate microwave radiation when the door is opened during operation, and thus to perfectly prevent the danger resulting from the leakage of microwave. (1) Primary interlock switch When the door is closed, the hook locks the oven door. -
Page 17: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE Following the procedure below to check if the oven is defective or not. 1. Check grounding before trouble checking. 2. Be careful of the high voltage circuit. 3. Discharge the high voltage capacitor. 4. When checking the continuity of the switches, fuse or high voltage transformer, disconnect one lead wire from these parts and check continuity with the AC plug removed. - Page 18 Does the fan motor work when you shut the door and turn the timer? Does the oven lamp light? Replace primary, secondary interlock switch and interlock Does the thrutable turn? monitor switch. Normal reading should be approx. 0Ω NO Continuity If microwave do not Replace high Check continuity filament...
-
Page 19: Measurement And Test
MEASUREMENT AND TEST 1. MEASUREMENT OF THE MICROWAVE POWER OUTPUT Microwave output power can be checked by indirectly measuring the temperature rise of a certain amount of water exposed to the microwave as directed below. PROCEDURE 1. Microwave power output measurement is made with the microwave oven supplied at rated voltage and operated at its maximum microwave power setting with a load of 1000±5cc of potable water. -
Page 20: Microwave Radiation Test
2. MICROWAVE RADIATION TEST CAUTION : 1. Make sure to check the microwave leakage before and after repair of adjustment. 2. Always start measuring of an unknown field to assure safety for operating personnel from microwave energy. 3. Do not place your hands into any suspected microwave radiation field unless the safe density level is known. 4. -
Page 21: Component Test Procedure
3. COMPONENT TEST PROCEDURE • High voltage is present at the high voltage terminal of the high voltage transformer during any cooking cycle. • It is neither necessary nor advisable to attempt measurement of the high voltage. • Before touching any oven components or wiring, always unplug the oven from its power source and discharge the capacitor. -
Page 22: Wiring Diagram
WIRING DIAGRAM... -
Page 23: Exploded View And Parts List
EXPLODED VIEW AND PARTS LIST 1. DOOR ASSEMBLY Refer to Disassembly and assembly. 2. CONTROL PANEL ASSEMBLY Refer to Disassembly and assembly. 3. TOTAL ASSEMBLY... - Page 24 PART CODE PART NAME DESCRIPTION SUPPLY REMARK 3511707950 DOOR AS KOR-63U50S 3511706020 DOOR AS KOR-63V50S 3511710210 DOOR AS KOR-63W50S 3511707940 DOOR AS KOR-63X50S 3511707990 DOOR AS KOR-63Y50S 3516711390 CONTROL PANEL AS KOR-63U50S 3516711330 CONTROL PANEL AS KOR-63V50S 3516719620 CONTROL PANEL AS...
- Page 25 DAEWOO ELECTRONICS CO., LTD. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” S/M NO. : R63U50S001 PRINTED DATE: Mar, 2002...
