Summary of Contents for Daewoo KOR-63ND5S
- Page 1 MICROWA VE OVEN KOR-63ND5S OPERATING INSTRUCTIONS & COOK BOOK Before operating this oven, please read these instructions completely.
-
Page 2: Table Of Contents
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE WARNING : To prevent fire, burns, electric shock and other warnings: Listed below are, as with all appliances, certain rules to follow and safeguards to assure high performance from this oven: 11. -
Page 4: Earthing Instructions
EARTHING INSTRUCTIONS This appliance must be earthed. In the event of an IMPORTANT NOTE electrical short circuit, earthing reduces the risk of The wires in this mains lead fitted to this appliance are electric shock by providing an escape wire for the cloured in accordance with the following code. -
Page 5: Specifications
SPECIFICATIONS POWER SUPPLY 230V~ / 50Hz, SINGLE PHASE WITH EARTHING POWER CONSUMPTION 1200 W MICROWAVE OUTPUT POWER 800 W FREQUENCY 2450 Mhz FREQUENCY RANGE 87.5Mhz ~ 108Mhz FM RADIO SPEAKER 4ohm, 0.5 W OUTSIDE DIMENSIONS (W x H x D) 465 x 279 x 360 mm CAVITY DIMENSIONS (W x H x D) 290 x 220 x 306 mm... - Page 6 FEATURES DIAGRAM PRESET TUNED DEF. LOCK START/ DEFROST EASY COOK STOP/CLEAR CLOCK MEMORY RADIO AUTO COOK 1. Dinner Plate 2. Saup 3. Beverage 4. Fresh Vegetable 5. Popcorn Preset UP/ Preset DOWN DOWN TUNING DIGITAL RADIO 1 Safety interlock system-Prevents the oven 5 Door seal-The door seal surfaces prevent from operating while the door is opened.
-
Page 7: Features Diagram
FEATURES DIAGRAM ( continued ) PRESET TUNED DEF. LOCK START/ DEFROST EASY COOK STOP/CLEAR CLOCK MEMORY RADIO AUTO COOK 1. Dinner Plate 2. Saup 3. Beverage 4. Fresh Vegetable Preset UP/ Preset DOWN DOWN TUNING DIGITAL RADIO 9 DISPLAY - Cooking time, power level, t AUTO COOK - Used to cook and to reheat indicators and present time are displayed. -
Page 8: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a 230V 50Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking. -
Page 9: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash “ :0” and a tone will sound. If the AC power ever turns off, the display shows “ :0” when the power comes back on. 1. -
Page 10: Time Defrosting
TIME DEFROSTING When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of alternating defrost and stand times by cycling on and off. 1. Press MW/DEFROST button The DEF. indicator appears and “ : 0” is 7 times. -
Page 11: Easy Cook
EASY COOK EASY COOK allows you to reheat for 30 seconds at 100% (full power) by simply pressing the EASY COOK button. By repeatedly pressing the EASY COOK button, you can also extend reheating time to 5 minutes by intervals of 30 seconds. 1. -
Page 12: Radio
RADIO This function allows you to listen to FM radio broadcasts from 87.5Mhz to 108Mhz. Tuning stations 1. Press RADIO button. If RADIO function is selected, FM indicator is RADIO turned on. If you would like to clear RADIO function, Press RADIO button again. And then FM indicator is going to be turned off. - Page 13 Programming Station Preset You can store up to 20 stations. 1. Tune in the radio station you Refer to "Tuning stations". wish to preset. 2. Press MEMORY button. The last stored channel is blinking. MEMORY 3. While the preset number is blinking in the display, turn the PRESET PRESET UP/DOWN KNOB to...
-
Page 14: Child Safety Lock
CHILD SAFETY LOCK The CHILD SAFETY LOCK prevents unwanted oven operation such as by small children. To set, press and hold the STOP/CLEAR button for 3 seconds, the LOCK indicator appears and a beep sounds. To cancel, press and hold the STOP/CLEAR button for 3 seconds, the LOCK indicator disappears and a beep sounds. ABOUT THE OTHER FEATURES •... -
Page 15: Care Of Your Microwave Oven
CARE OF YOUR MICROWAVE OVEN Turn the oven off before cleaning. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher. Keep the inside of the oven clean. When food spatters or spilled liquids adhere to oven walls, wipe with a damp cloth. -
Page 16: Questions And Answers
QUESTIONS AND ANSWERS * Q : Why do eggs sometimes pop? * Q : Is it normal for the turntable to turn in either * A : When baking or piaching eggs, the yolk may direction? pop due to steam build-up inside the yolk * A : Yes. -
Page 17: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. * The oven doesn’t work : * Sparking in the cavity : 1. Check that the power cord is securely 1. Check utensils. Metal containers or dishes with plugged in. -
Page 18: Cooking Instructions
COOKING INSTRUCTIONS Utensil Guide Only use utensils that are suitable for use in microwave ovens. To cook food in the microwave oven, the microwaves must be able to penetrate the food, without being reflected or absorbed by the dish used. Care must therefore be taken choosing the utensil. If the utensil is marked microwave-safe, you do not need to worry. -
Page 19: Use Your Microwave Oven Safely
USE YOUR MICROWAVE OVEN SAFELY General Use Do not attempt to defeat or tamper with safety Do not operate the oven if door seals or sealing interlocks. surfaces are damaged; or if door is bent; or if hinges Do not place any object between the oven front frame are loose or broken. -
Page 20: Microwaving Principles
MICROWAVING PRINCIPLES Microwave energy has been used in this country to cook and reheat food since early experiments with RADAR in World War ll. Microwaves are present in the atmosphere all the time, both naturally and manmade sources. Manmade sources include radar, radio, television, telecommunication links and car phones. -
Page 21: Cooking Techniques
COOKING TECHNIQUES STANDING TIME STARTING TEMPERATURE Dense foods e.g. meat, jacket potatoes and cakes, The colder the food, the longer it takes to heat up. require standing time(inside or outside of the oven) Food from a fridge takes longer to reheat than food after cooking, to allow heat to finish conducting to at room temperature. -
Page 22: Defrosting Guide
DEFROSTING GUIDE ¢ º Do not defrost covered meat. Covering might allow ¢ º When defrosted, food should be cool, but softened in all areas. If still slightly icy, return to microwave oven cooking to take place. Always remove outer wrap and tray. -
Page 23: Cooking & Reheating Chart
COOKING & REHEATING CHART Cooking chart Power Cooking Time Item Special Instruction Level Per lb./450g MEAT - Chilled meat and poultry should be removed from Beef joint -Rare P-80 7-9 min. the refrigerator at least 30 minutes before cooking. -Medium P-80 7-9 min. -
Page 24: Reheating Chart
Reheating chart • Baby food particularly needs to be checked carefully before serving to prevent burns. • When heating pre-packaged ready-cooked foods, always follow the pack instructions carefully. • If you freeze foods which were bought from the fresh or chilled counters, remember that they should be thoroughly thawed before following the heating instructions on the packed. -
Page 25: Vegetable Chart
VEGETABLE CHART Use a suitable glass pyrex bowl with lid. Add 30-45ml cold water(2-3 tbsp.) for every 250g unless another water quantity is recommended - see table. Cook covered for the minimum time - see table. Continue cooking to get the result you prefer. Stir once during and once after cooking. Add salt, herbs or butter after cooking. -
Page 26: Recipes
RECIPES TOMATO & ORANGE SOUP 1. Melt the in a large bowl at High for 1 minute. 1 oz.(25g) butter 2. Add the onion, carrot and potato and cook on P-HI for 1 medium onion, chopped 5 minutes. stir halfway through cooking. 1 large carrot &... -
Page 27: White Sauce
BLUE CHEESE & CHIVE JACKETS 1. Prick each potato in several places. Cook on P-HI for 2 baking potatoes, 10-12 minutes. Halve and scoop the flesh into a bowl, (approx.9 oz.(250g) each) add the butter, cheese, chives, mushrooms, salt and 2 oz.(50g) butter pepper, mix thoroughly. - Page 28 SCRAMBLED EDD 1. Melt the butter in a bowl on P-HI for 1 minutes. oz.(15g) butter 2. Add the eggs, milk and seasoning and mix well. 2 eggs 3. Cook on P-HI for 3 minutes, stirring every 30 seconds. 2 tbsp(30ml) milk salt &...
