SERVICE MANUAL
CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
P/No. MFL47912404 (Last Revision: March. 10. 2008)
Model #s:
795.78712.801
795.78713.801
795.78719.801
795.78722.801
795.78723.801
795.78729.801

Advertisement

Table of Contents
loading

Related Manuals for Kenmore 795.78712.801

Summary of Contents for Kenmore 795.78712.801

  • Page 1 SERVICE MANUAL CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. Model #s: 795.78712.801 795.78713.801 795.78719.801 795.78722.801 795.78723.801 795.78729.801 P/No. MFL47912404 (Last Revision: March. 10. 2008)

  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS ............................... 2 1. SPECIFICATIONS................................3 2. PARTS IDENTIFICATION ..............................4 3. DISASSEMBLY................................5-12 DOOR ....................................5-8 TO REMOVE THE DISPENSER ............................8 FAN AND FAN MOTOR ..............................8 DEFROST CONTROL ASSEMBLY ............................ 9 LAMP ....................................9 CONTROL BOX-REFRIGERATOR ............................ 9 MULTI DUCT ..................................

  • Page 3: Specifications

    1. SPECIFICATIONS 1-1 DISCONNECT POWER CORD BEFORE 1-7 REPLACEMENT PARTS SERVICING 21 cuft 795. 78712.801 795. 78722.801 IMPORTANT – RECONNECT ALL 795. 78713.801 795. 78723.801 795. 78714.801 795. 78724.801 GROUNDING DEVICES All parts of this appliance capable of conducting electrical Relay current are grounded.

  • Page 4: Dimensions

    1-9 DIMENSIONS Description 795.787** Depth w/ Handles 30 in. Depth w/o Handles 27 1/2 in. Depth w/o Door 23 5/8 in. Depth (Total with Door Open) 42 1/4 in. Height to Top of Case 68 3/8 in. Height to Top of Door Hinge 69 3/4 in.

  • Page 5: Parts Identification

    2. PARTS IDENTIFICATION Water Filter Dairy Bin Refrigerator Light Utility/Egg Box Refrigerator Shelves Modular Door Bins Door Bins Humidity Bottle Holder Controlled (795.7855** Crisper Models Only) Modular Water Tank Door Bins Cover Wide Pantry Drawer Pull-Out Drawer Adjusta Cube Ice Maker Ice Bin Tilt-Out Door Basket...

  • Page 6: Disassembly

    3. DISASSEMBLY 3-1 REMOVING AND REPLACING REFRIGERATOR DOORS To remove the left refrigerator door: To remove the right refrigerator door: IMPORTANT: CAUTION : WARNING Explosion Hazard IMPORTANT: - 6 -...

  • Page 7: Door

    3-2 DOOR Door Gasket Replacement 1. Insert gasket bracket clips Door Gasket Removal 1) Insert gasket bracket edge beneath door frame edge. 1. Remove door frame cover 2) Turn upper gasket bracket spring so that the spring Starting at top of cover and working down, snap cover ends are in the door channel.

  • Page 8: To Remove The Dispenser

    2) Press gasket into channels on the three remaining 2. Pry off cover dispenser. sides of door. Figure 6 Figure 9 3. Replace door frame cover Starting at top of cover and working down, snap cover Disconnect wire harness. back into door. 3.

  • Page 9: Fan And Fan Motor

    3-5 FAN AND FAN MOTOR 4. Make sure the bulbs are cool to the touch. Turn bulbs counterclockwise to remove. 1. Remove the freezer shelf. (If your refrigerator has an 5. Assemble in reverse order by snapping the Lamp Cover icemaker, remove the icemaker first) in, engaging the rear tabs followed by the front tabs.

  • Page 10: How To Remove And Reinstall The Pullout Drawer

    3-10 HOW TO REMOVE AND REINSTALL THE PULLOUT DRAWER 3-10-1 FOLLOW STEPS TO REMOVE Step 1) Open the freezer door. Step 2) Remove the lower basket. Step 3) Remove the two screws from the guide rails (one Step 4) Lift the freezer door up to unhook it from the rail from each side).
  • Page 11 3-10-2 FOLLOW STEPS TO REINSTALL Step 1) Reinstall the right side gear into the clip. Step 2) Insert the rail into the right side gear. Gears do not Step 3) Insert the rail into the left side gear, and insert the need to be perpendicular to each other.
  • Page 12 3-10-3 PULL OUT DRAWER To separate the drawer, push the front left and right hooks in direction to pull up and remove. Then gently lift the gear part of rear left and right side of the drawer and pull it out in direction.
  • Page 13 3-11 TRIM KIT ASSEMBLY AND AISASSEMBLY METHOD (795.77719,77729 MODELS ONLY) 3-11-1 ASSEMBLY AND DISASSEMBLY METHOD OF LEFT DOOR GLASS AND DISPLAY OF THE REFRIGERATOR 1. Remove the 2 screws on the top refrigerator door trim, circled in Photo # 1. 2.
  • Page 14 3-11-2 ASSEMBLY AND DISASSEMBLY METHOD OF FREEZER DOOR AND GLASS 1. Fully open the freezer drawer as shown in photo # 1. 2. Lift out the freezer basket as shown in photo # 2. 3. Remove the 2 screws (one on each side shown in photo # 3. 4.
  • Page 15 3-11-2 ASSEMBLY AND DISASSEMBLY METHOD OF FREEZER DOOR AND GLASS 8. Pull off the bottom cover as shown in photo # 8. 9. Remove one of the side trim pieces by pulling it out slightly the up to remove it from the top door trim. As shown in photo # 9.
  • Page 16 6-4 SERVICE DIAGNOSIS CHART COMPLAINT POINTS TO BE CHECKED REMEDY No Cooling. • Is the power cord unplugged from the outlet? • Plug into the outlet. • Check if the power switch is set to OFF. • Set the switch to ON. •...

  • Page 17: Adjustment

    4. ADJUSTMENT 4-1 COMPRESSOR 4-1-1 Role 4-2-3 TSD-Applied circuit diagram Starting method for the motor The compressor intakes low temperature and low pressure gas from the evaporator of the refrigerator and compresses this gas to high-temperature and high-pressure gas. It then ELECTRICAL AND DIMENSION DIAGRAM delivers the gas to the condenser.

  • Page 18: Olp (Overload Protector)

    4-3 OLP (OVERLOAD PROTECTOR) 4-3-1 Definition of OLP (1) OLP (OVERLOAD PROTECTOR) is attached to the Compressor and protects the Motor by opening the circuit to the Motor if the temperature rises and activating the bimetal spring in the OLP. (2) When high current flows to the Compressor motor, the Bimetal works by heating the heater inside the OLP, and the OLP protects the Motor by cutting off the...

  • Page 19: Circuit Diagram

    5. CIRCUIT DIAGRAM CIRCUIT DIAGRAMS - 18 -...

  • Page 20: Compressor And Electric Components

    6-1 COMPRESSOR AND ELECTRIC COMPONENTS (Rated voltage Remove TSD-Starter Power source. ±10%)? from compressor and measure voltage between terminal C of compressor and terminal 5 or 6 of TSD. OLP disconnected? No voltage. Replace OLP. Check connection condition. Reconnect. Applied voltage isn't Advise customer that in acceptable range.
  • Page 21 6-2 TSD AND OLP Normal operation of Separate TSD-Starter Observation value is compressor is from compressor and 120V /60Hz : 6.8Ω±30% impossible or poor. measure resistance between No. 5 and 6 of TSD-Starter with a Tester. (Figure 20) Replace TSD- The resistance value Starter.

  • Page 22: Other Electrical Components

    6-3 OTHER ELECTRICAL COMPONENTS Not cooling at all Check for open short or Compressor Cause incorrect resistance readings doesn't run. in the following components a. Starting devices Short, open, or broken. Poor contact b. OLP or shorted. Coil open or shorted. c.

  • Page 23: Refrigeration Cycle

    6-5 REFRIGERATION CYCLE Troubleshooting Chart TEMPERATURE STATE OF STATE OF THE CAUSE REMARKS OF THE THE UNIT EVAPORATOR COMPRESSOR PARTIAL Freezer Low flowing sound of A little higher • Refrigerant level is low due LEAKAGE compartment and refrigerant is heard and than ambient •...
  • Page 24 6-5-1 SEALED SYSTEM DIAGNOSIS Not Cooling Complaint All components operating, No airflow problems, Not frosted up as a defrost problem problem has been isolated to sealed system area Frost None Partial Pattern? Equalization Equalization Test Test Very Fast Very Slow Very Slow Very Fast Fast...

  • Page 25: Operation Principle And Repair Method Of Icemaker

    7. OPERATION PRINCIPLE AND REPAIR METHOD OF ICEMAKER 7-1 OPERATION PRINCIPLE 7-1-1 Operation Principle of Icemaker Power On Start Position Start Position Icemaking Mode Harvest Mode Fill Icemaking Mode Park Position Fill Key Test Mode Harvest Fill Icemaking 1. Turning the icemaker stop switch off (O) stops the icemaking function. 2.
  • Page 26 7-2 ICE MAKER FUNCTIONS 7-2-1 Start Position 1. After POWER OFF or power outage, check the EJECTOR's position with MICOM initialization to restart. 2. How to check if it is in place: - Check HIGH/LOW signals from HALL SENSOR in MICOM PIN. 3.
  • Page 27 7-2-4 Fill/Park Position 1. Once a normal harvest mode has been completed, the water solenoid will be activated. 2. The amount of water is adjusted by pressing the fill key repeatedly. This changes the time allowed for fill as illustrated in the table below.
  • Page 28 7-2-5 Function TEST 1. This is a compulsory operation for test, service, cleaning, etc. It is operated by pressing and holding the fill key for 3 seconds. 2. The test works only in the icemaking mode. It cannot be entered from the harvest or fill mode. (If there is an ERROR, it can be checked only in the test mode.) 3.

  • Page 29: Description Of Function And Circuit Of Micom

    8. DESCRIPTION OF FUNCTION & CIRCUIT OF MICOM 8-1 FUNCTION 8-1-1 Function 1. When the appliance is plugged in, it is set to 37 for Refrigerator and 0 for freezer. You can adjust the Refrigerator and the Freezer control temperature by pressing the ADJUST button. 2.
  • Page 30 8-1-6 CONTROL OF FREEZER FAN MOTOR 1. Freezer fan motor has high and standard speeds. 2. High speed is used at power-up, for Ultra Ice, and when refrigerator is overloaded. Standard speeds is used for general purposes. 3. To improve cooling speed, the RPM of the freezer fan motor change from normal speed to high. 4.
  • Page 31 8-1-10 Buzzer Sound When the button on the front Display is pushed, a Ding~ Dong~ sound is produced. 8-1-11 Defrost cycle 1. A defrost cycle will be initiated after 4 hours of accumulated compressor run time after the initial power up or a power failure.
  • Page 32 8-1-13 Automatic Diagnosis Function 1. Automatic diagnosis makes servicing the refrigerator easy. 2. When an error occurs, the buttons will not operate; but the tones. such as ding. will sound. 3. When the error CODE removes the sign, it returns to normal operation (RESET). 4.
  • Page 33 8-1-14 TEST Mode 1. The test mode allows checking the PCB and the function of the product as well as finding out the defective part in case of an error. 2. The test mode is operated by pressing test buttons at main PCB controller. 3.
  • Page 34 8-2 PCB FUNCTION 8-2-1 Power Circuit The secondary part of the TRANSFORMER is composed of the power supply for the display, the BLDC FAN Motor drive (15.5 V), the relay drive (12 Vdc) and the MICOM and IC (5 Vdc). The voltage for each part is as follows: PART VA 1...
  • Page 35 8-2-2 Oscillation Circuit This circuit generates the base clock for calculating time and the synchro clock for transmitting data from and to the inside logic elements of the IC1 (MICOM). Be sure to use specified replacement parts, since calculating time by the IC1 may be changed.
  • Page 36 8-2-2 Load / Buzzer Drive & Open Door Detection Circuit 1. Load Drive Condition Check Circuit Pin Number Pin Number Output Voltage Compressor Con1 pin1 Con1 pin3 115 VAC Defrost heater Con2 pin1 Con1 pin3 115 VAC F,R-lamp Con2, pins 3 and 5 Con1 pin3 115 VAC Water valve...
  • Page 37 3. Open Door Detection Circuit Check 8-2-3 Temperature Sensor Circuit The upper circuit reads refrigerator temperature, freezer temperature, and defrost sensor temperature for defrosting and the indoor temperature for compensating for the surrounding temperature into MICOM. Opening or short state of each temperature sensor are as follows: SENSOR CHECK POINT NORMAL (-30°C ~ 50°C)
  • Page 38 8-2-4 Refrigeration Compartment Stepping Motor Damper Circuit A reversible DC motor is used to open and close the damper. To open the damper, push test button once. To close the damper, push test button twice. 8-3 RESISTANCE SPECIFICATION OF SENSOR RESISTANCE OF FREEZER RESISTANCE OF REFRIGERATOR &...
  • Page 39 8-3 TROUBLESHOOTING PROBLEM INDICATED BY CHECK CHECKING METHOD CAUSE SOLUTION POWER 1. The whole 1. FREEZER/ Check if POWER SOURCE is Use boosting TRANS. SOURCE is DISPLAY LCD is REFRIGERATOR. FREEZER/REFRIGERA poor. poor. off. TOR DOOR IS OPEN and check display. 2.
  • Page 40 PROBLEM INDICATED BY CHECK CHECKING METHOD CAUSE SOLUTION COOLING is 1. If FREEZER Check is FREEZER Make sure the DOOR poor. REFRIGERATOR TEMPERATURE is TEMPERATURE is too isattached. TEMPERATURE normal. low. is too low. 2. If amount of cool air Make sure that the FAN MOTOR is poor.
  • Page 41 8-4 MAIN PWB ASSEMBLY AND PARTS LIST 8-4-1 Main PWB Assembly Connector4 Connector6 Connector5 Test Switch Connector1 Connector3 Connector2 - 41 -...
  • Page 42 For the replacement parts, accessories and owner s manuals that you need to do-it-yourself. refrigerator is found on the serial plate inside. 795.78712.801 For Sears professional installation of home appliances and items like garage door openers and water heaters. 795.78713.801 All repair parts listed are available 795.78719.801...
  • Page 43 CASE PARTS CAUTION: Use the part number to order part, not the position number. 607A 207B 626A 402A 624D 103B 624C 103A 271A 410A 207A 271B 409D 624A 406D 501F 402A 120A 271C 610D 282F 503D 610B 271D 145A 610A 500A 120B 409B...
  • Page 44 CASE PARTS Loc No. 787*9(WB) 787*3(ST) 787*2(SW) Description 103A 3650JA2113N 3650JA2061X 3650JA2061B Handle,Rear Handle, Rear 103B 3650JA2113P 3650JA2061W 3650JA2061A Handle,Rear Handle, Rear 103C ACQ55957503 ACQ55957504 ACQ55957501 Cover Assembly, Lower 105A 5251JA3003D 5251JA3003D 5251JA3003D Tube Assembly,Drain 106A 4779JJ2001B 4779JJ2001B 4779JJ2001B Leg Assembly, Adjust 120B MCZ47932701 MCZ47932701...
  • Page 45 CASE PARTS LOC No. 787*9(WB) 787*3(ST) 787*2(SW) Description 4000W4A003A 4000W4A003A 4000W4A003A Screw,Customized 1STZJA3004G 1STZJA3004G 1STZJA3004D Screw,Customized 1BZZJA2002A 1BZZJA2002A 1BZZJA2002A Bolt,Common 4J00415D 4J00415D 4J00415D Screw ,Customized 4J00415D 4J00415D 4J00415D Screw,Customized 4J00415D 4J00415D 4J00415D Screw,Customized 1SZZJJ3005E 1SZZJJ3005E 1SZZJJ3005E Screw,Customized 4J00415D 4J00415D 4J00415D Screw,Customized 1SBZJA3004L 1SBZJA3004L...
  • Page 46 REFRIGERATOR PARTS CAUTION: Use the part number to order part, not the position number. 147C 141A 147A 141E 141A 142B 142A 141E 142B 142A 141A 140A 141E 142D 142B 142B 141D 161C 142A 142A 161B 154A 151B 151A 146E 161A 145E 162B 145D...
  • Page 47 REFRIGERATOR PARTS Loc No. 787*9(WB) 787*2(SW) 787*3(ST) Description AHT36706708 AHT36706708 AHT36706708 141A Shelf Assembly, Refrigerator 5027JJ2012L 5027JJ2012L 5027JJ2012L 141E Shelf, Refrigerator 141C 5027JJ2012E 5027JJ2012E 5027JJ2012E Shelf Assembly, Net 141D 4890JL1012B 4890JL1012B 4890JL1012B Cover, Glass 145D 4974JA1153B 4974JA1153B 4974JA1153B Tray Assembly, Fresh Room 145E 3550JL1011B 3550JL1011B...
  • Page 48 DOOR PARTS (78719, 78729) CAUTION: Use the part number to order part, not the position number. 230B 241A 230A 231B 241C 233B 233C 241B 231A 233D 233A 220D 241D 220D 220E 220E 220D 220D 204A 206C 234C 234D 234A 206B 206A 234B 220E...
  • Page 49 DOOR PARTS (78719, 78729) CAUTION: Use the part number to order part, not the position number. 249A 276A=206A+206B+244B+244C+236A+236B 249E 249G 250B 205C 250A 203A 201A 249J 236A 212G 205B 212E 212F 249K 250B 220E 212D 220D 236B 204C 220E 220E 220D 249H 206H...
  • Page 50 DISPENSER PARTS (78719, 78729) CAUTION: Use the part number to order part, not the position number. 295A 279A 616A 290A 291A 279B 403A 293A 292A 294A 279C L/No. 78719(WB) 78729(WB) Descrption 279A EBR36499201 EBR36499201 PCB Assembly, Display 279B MCK38084101 MCK38084101 Cover, Dispenser 279C MCR38202401...
  • Page 51 DOOR PARTS (787*3, 787*2) CAUTION: Use the part number to order part, not the position number. 241A 241C 241B 230B 230A 241D 231B 233B 233C 233D 233A 231A 212G 234B 234A 234D 234D 241D 241D 244A 244A 241D 241D 243C 241E 243C 312C...
  • Page 52 DOOR PARTS L/No. 787*3(ST) 787*2(SW Descrption 2200A ADC57012004 ADC57012005 Door Assembly, Freezer 201A ADD34126202 ADD34126201 Door Foam Assembly, Freezer 203A MDS38201401 MDS38201401 Gasket, Door 205B 5006JJ2013A 5006JJ2013A Cap, Cover 205C 5006JJ2013B 5006JJ2013B Cap, Cover 212D 3651JA2279K 3651JA2279J Handle Assembly 212G 3846JD1019B 3846JD1019B Name Plate...
  • Page 53 DISPENSER PARTS (787*3, 787*2) CAUTION: Use the part number to order part, not the position number. 295A 279A 616A 290A 279B 291A 293A 403A 292A 294A 279C L/No. 787*3(ST) 787*2(SW) Descrption 279A EBR36499201 EBR36499201 PCB Assembly, Display 279B 3550JA1492B 3550JA1492A Cover, Dispenser 279C 3806JJ2053E...
