Kenmore 795.7620 Service Manual

Bottom freezer refrigerator
Hide thumbs Also See for 795.7620:
Table of Contents

Advertisement

Quick Links

See also: Use and Care Manual
BOTTOM FREEZER REFRIGERATOR
REFRIGERATOR
SERVICE MANUAL
CAUTION
BEFORE SERVICING THE PRODUCT
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
MODELS:
795.7620
795.6827
795.7827
color number
www.sears.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 795.7620 and is the answer not in the manual?

Questions and answers

Tommy
March 15, 2025

Why does it beep and how do I fix it

0

Related Manuals for Kenmore 795.7620

Summary of Contents for Kenmore 795.7620

  • Page 1 BOTTOM FREEZER REFRIGERATOR REFRIGERATOR SERVICE MANUAL CAUTION BEFORE SERVICING THE PRODUCT READ THE SAFETY PRECAUTIONS IN THIS MANUAL. MODELS: 795.7620 795.6827 795.7827 color number www.sears.com Sears Brands Management Corporation, Hoffman Estates, IL 60179 U.S.A.
