Friedrich M18YJ Service Manual page 14

Model: MW24C3J
MW24C3J
Loc No.
131410
149303
346810
135500A
359011
342800
354212
354210
35211B
149304
249951
W6640
268711C
263230B
263230A
135311
147581
147582
145200A
145200B
146811B
W50400
135316
135313
152301
268711F
135511
135090
135500C
733010
352150
131111
268711E
146811A
267110
135500B
P/N_FRD Description
67601001 Chassis Assembly
67602705 Holder,Tubing
67603329 Motor,DC
67601508 Cover
67602107 Fan Assembly,Cross Flow
67606700 Bearing
67602005 Evaporator Assembly,Final
67602012 Evaporator Assembly,First
67605001 Tube Assembly,Tubing
67602702 Holder,Evaporator
67600939 Case Assembly,Control(Indoor)
67601404 Connector,Terminal Block
67603947 PCB Assembly,Main
67604808 Thermistor Assembly,NTC
67604801 Thermistor Assembly
67602501 Grille Assembly,Discharge(Indoor)
67603202 Louver,Horizontal
67603205 Louver,Vertical
67603001 Link
67603000 Link
67603320 Motor Assembly,DC,Stepping
67601700 Damper
67602531 Grille Assembly,Front(Indoor)
67602530 Grille Assembly,Inlet
67602210 Filter,Deodorizing
67603924 PCB Assembly,Sub
67601601 Cover Assembly,Control(Indoor)
67601801 Decor Assembly
67601507 Cover
67604001 Plate Assembly,Installation
67602806 Hose Assembly,Drain
67600923 Case Assembly,Indoor
67603949 PCB Assy Option
67603317 Motor Assembly,DC,Stepping
67604309 Remote Controller Assembly
67601511 Cover
- 14 -
Qty
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
12
1
1
1
2
1
1
2
1
1
1
1
1
1
1
1
1
1
1
