Rotel RSP-1066 Technical Manual

T echnical
Manual
Table of Contents
Specification......................................1
Parts List...........................................2~11
Upgrade Procedure..........................12
Wiring................................................13
Specifications
Audio
Total Harmonic Distortion
<0.05%
Intermodulation Distortion (60 Hz: 7kHz)
<0.05%
Frequency Response
10 Hz - 95 kHz, ±1 dB (line level)
10 Hz - 20 kHz, ±0.3 dB (digital level)
Signal to Noise Ratio (IHF A-weighted)
95 dB (Stereo) Analog
92 dB (Dolby Digital, dts) 0dBFs
Input Sensitivity/Impedance
Line Level: 200 mV/47 kohms
Tone Controls (Bass/Treble)
±8 dB at 100 Hz/10 kHz
Preamp Output Level
1.2 V (200 mV Input)
Video
Frequency Response
3 Hz – 10 MHz, ± 3 dB
Signal to Noise Ratio
45 dB
Input Impedance
75 ohms
Output Impedance
75 ohms
Output Level
1 volt
THE ROTEL CO., LTD.
SHINSEN-BLD. 4F 10-10 SHINSEN-CHO, SHIBUYA-KU,
TOKYO 150-0045, JAPAN
Quality Uncompromised
General
Power Consumption:
40 watts
Power Requirements (AC)
115 volts, 60Hz (USA version)
230 volts, 50Hz (CE version)
Weight
7.6 Kg/16.7 lb.
Dimensions (W x H x D)
432 x 122 x 341 mm
17" x 4
Front Panel Height r
(feet removed/for rack mount)
109 mm / 4
®
SURROUND SOUND PROCESSOR
RSP-1066
PCB Assembly..................................14~18
Schematic Diagram ..........................19~32
" x 13 "
7/8 1/2
"
5/16
Serial. NO.
Beginning
Y-359A-0207/W
