Rotel RSP-1098 Command List

Rs232 controller command list
Hide thumbs Also See for RSP-1098:
1
2
3
4
5
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
Table: RSP 1098 Waveform format expected:
Baud Rate
Parity
19200
Table: RSP 1098 expected format of a request by RS 232 controller:
Start
Count
Device ID
0xFE
0x03
0xa0

Table 1: Type 10 Primary Command List

NOTE: The values in the table below show the exact byte sequence of all requests. The device
will expect the bytes only - no spaces, no delimiter, etc. The controlling device may implement its
own method to download each command sequence. The numerical values in the first column are
Hexadecimal.
RSP 1098 HEX
FE 03 A0 10 00 B3
FE 03 A0 10 01 B4
FE 03 A0 10 02 B5
FE 03 A0 10 03 B6
FE 03 A0 10 04 B7
FE 03 A0 10 05 B8
FE 03 A0 10 06 B9
FE 03 A0 10 07 BA
FE 03 A0 10 08 BB
FE 03 A0 10 09 BC
FE 03 A0 10 0A BD
FE 03 A0 10 0B BE
FE 03 A0 10 0C BF
FE 03 A0 10 0D C0
FE 03 A0 10 0E C1
FE 03 A0 10 0F C2
FE 03 A0 10 10 C3
FE 03 A0 10 11 C4
FE 03 A0 10 12 C5
FE 03 A0 10 13 C6
FE 03 A0 10 14 C7
FE 03 A0 10 15 C8
FE 03 A0 10 16 C9
FE 03 A0 10 17 CA
FE 03 A0 10 18 CB
FE 03 A0 10 19 CC
FE 03 A0 10 1A CD
FE 03 A0 10 1B CE
FE 03 A0 10 1C CF
RSP 1098
RS232 Controller Command List
Valid Data Bits
N
8
Type
Key
0x10
0xXX
Command
RMC Vol+
RMC Vol-
CD
Tuner
Tape
Video 1
Video 2
Video 3
Video 4
Video 5
Power
Vol+
Vol-
Treble+
Treble-
Bass+
Bass-
Stereo
3 Stereo
Pro Logic
DSP
Multi
Dynamic
Rec
OSD Menu
OSD Enter
OSD Right (+)
OSD Left (-)
OSD Up
Stop Bit Value
Handshaking
1
Checksum
0xXX
Command Description
Remote Volume Up
Remote Volume Down
Source CD
Source Tuner
Source Tape
Source Video 1
Source Video 2
Source Video 3
Source Video 4
Source Video 5
Power Toggle
Volume Up
Volume Down
Treble Up
Treble Down
Bass Up
Bass Down
Stereo
Dolby 3 Stereo
Dolby Pro Logic
DSP Music
Multi Input
Dynamic Range
Record
OSD Menu
OSD Enter
OSD Right
OSD Left
OSD Up
Data Type
None
String

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RSP-1098 and is the answer not in the manual?

Questions and answers

Related Manuals for Rotel RSP-1098

Summary of Contents for Rotel RSP-1098

  • Page 1 RS232 Controller Command List Table: RSP 1098 Waveform format expected: Baud Rate Parity 19200 Table: RSP 1098 expected format of a request by RS 232 controller: Start Count Device ID 0xFE 0x03 0xa0 Table 1: Type 10 Primary Command List NOTE: The values in the table below show the exact byte sequence of all requests.
  • Page 2 RSP 1098 HEX FE 03 A0 10 1D D0 OSD Down / Dynamic FE 03 A0 10 1E D1 Mute FE 03 A0 10 1F D2 Digital In Select FE 03 A0 10 22 D5 Surround+ FE 03 A0 10 23 D6 Zone 2 / Main FE 03 A0 10 4A FD Power Off...
  • Page 3 Table 3: Type 14 Main Zone Command List NOTE: These commands are duplicate functions of the primary commands in the table above bearing the same name, but are discrete for the main zone only. For multi-zone installation applications, it is recommended that the below commands be used rather than the type 10 commands to avoid zone conflicts.
  • Page 4 RSP 1098 HEX FE 03 A0 16 0A C3 Zone 2 Power FE 03 A0 16 1E D7 Zone 2 Mute FE 03 A0 16 4A 03 Zone 2 Power Off FE 03 A0 16 4B 04 Zone 2 Power On FE 03 A0 16 6B 24 Zone 2 Source FE 03 A0 16 6C 25...
  • Page 5 RSP 1098 HEX FE 03 A0 32 04 D9 Zone 2 Volume 4 FE 03 A0 32 05 DA Zone 2 Volume 5 FE 03 A0 32 06 DB Zone 2 Volume 6 FE 03 A0 32 07 DC Zone 2 Volume 7 FE 03 A0 32 08 DD Zone 2 Volume 8 FE 03 A0 32 09 DE...
