OUTDOOR TABLE TOP GAS GRILL MODEL# 820-0002A SERIAL # ____________________ MFG. DATE _____________ PURCHASE DATE: ____________ This instructions manual contains important information necessary for the proper assembly and safe use of the appliance. Read and follow all warnings and instructions before assembling and using the appliance.
TABLE OF CONTENTS Table of contents & Warning………………2 Operation Instructions…………………..7-8 Safety Information…………………..3-5 Care and maintenance………………….….. 9 Package Contents List……………………..5 Trouble shooting……..……………………..10 Preparation………………………….……..5 Replacement Parts List…………..…..11 Assembly Instructions……………………...6 Warranty……….………………………….…12 DANGER If you smell gas: 1. Shut off gas to the appliance. 2.
SAFETY INFORMATION Please read the following instructions carefully before attempting to assemble, operate or install the product. Failure to follow these instructions may result in serious bodily injury and/or property damage. If you have questions regarding the product please call customer service at 1-800-913-8999, 7 a.m.-6 p.m., PST, Monday-Friday.
Page 4
Gas grills are used safely by millions of people when following simple safety precautions. The items in the fuel system are designed for operation with the Nexgrill grill. They must not be replaced with any other brand. (See parts list for replacement items.)
The LP gas cylinder shall be used only outdoors in a well-ventilated space and not in a building, garage, or any other enclosed area. The Nexgrill Table Top Grill may be stored indoor if the LP gas cylinder is removed and stored outdoor.
ASSEMBLY INSTRUCTIONS Fig. 1 1.Locate the gas regulator (1-1). Grasp the regulator (1-1) with (1-3) the knob (1-2) facing directly up. Line up the collar on the regulator (1-1) with the open end of the burner tube (1-3) as shown in fig. 1. (1-1) (1-2) 2.
OPERATION INSTRUCTIONS BURNER VALVE / REGULATOR The burner control operates in the following positions indicated by the pointer at the top of the regulator as installed on the grill: OFF – This stops the flow of gas to the burner. PUSH TO TURN ON –...
Page 8
OPERATION INSTRUCTIONS TURNING THE GRILL OFF 1. Open the lid. 2. Turn the regulator control knob to the “OFF” position. Caution: Do not attempt to re-light the grill without following all the lighting instructions. 3. Allow the grill body to cool at least 30 minutes before attempting to move or transport. FLAME CHARACTERISTICS Flames should be blue and stable with no yellow tips, excessive noise or lifting.
CARE AND MAINTENANCE There is very little care and maintenance needed. The Nexgrill Table Top Grill is designed and made of materials that will last many years with normal use. Following these instructions will improve the longevity and quality of cooking. To ensure safe operation of your grill, the area of cooking should always be kept free of combustible materials of any type, such as gasoline or other flammable vapors or liquids.
TROUBLE SHOOTING WARNING Spiders and insects can nest inside the burners of the grill and disrupt gas flow. This very dangerous condition could cause a fire behind the valve panel, thereby damaging the grill and making it unsafe for operation. Inspect the grill at least twice a year. When to Look for Spiders You should inspect the burners at least twice a year or immediately after any of the following conditions occur:...
Edited by Foxit Reader Copyright(C) by Foxit Software Company,2005-2007 REPLACEMENT PARTS LIST For Evaluation Only. For replacement parts, call our customer service department at 1-800- 913-8999, 7 a.m.-6 p.m., PST, Monday-Friday, 8 a.m.-12 p.m. Saturday. REF# Description Main Lid 1 PC Logo 1 PC Door latch...
LIMITED WARRANTY (Model # 820-0002A) Nexgrill warrants to the original consumer-purchaser only that this product (Model #820-0002A) shall be free from defects in workmanship and materials after correct assembly and under normal and reasonable home use for the periods indicated below beginning on the date of purchase.
