ASSEMBLY & OPERATING INSTRUCTIONS FOR
WARNING
To reduce the risk of fire, burn
hazard or other injury, read the Care
and Use Manual carefully and
complete before using your grill.
PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE
DO NOT RETURN TO PLACE OF PURCHASE
OUTDOORGAS GRILL
®
Model : 820-0002
H16Y06P-1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Nexgrill 820-0002
Summary of Contents for Nexgrill 820-0002
- Page 1 WARNING To reduce the risk of fire, burn hazard or other injury, read the Care and Use Manual carefully and Model : 820-0002 complete before using your grill. H16Y06P-1 PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE DO NOT RETURN TO PLACE OF PURCHASE...
- Page 2 DANGER If you smell gas: 1. Shut off gas to the appliance 2. Extinguish any open flame. 3. Open lid 4. If door continues, keep away from the appliance and immediately call you fire department. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury or death DANGER 1.
-
Page 3: Table Of Contents
SAVE THESE INSTRUCTIONS TABLE OF CONTENTS Safety Instruction… … … … … … … … … Illustrated Parts Breakdown………………. Parts List…...……………………………….. Assembly Instruction……………………….. Lighting Instruction……………………….. Lighting Rod Assembly Instruction……… Care and Maintenance…………………….. Cooking Instruction……………………….. Trouble Shooting………………………….. Limited Warranty……………………………. Read this Care and Use Manual carefully and completely before using your grill to reduce the risk of fire, burn hazard or other injury. -
Page 4: Safety Instruction
Safety Instructions READ THE FOLLOWING INSTRUCTIONS CAREFULLY AND BE YOUR GRILL IS PROPERLY INSTALLED, ASSEMBLED AND MAINTAINED. FAILURE TO FOLLOW THESE INSTRUCTION MAY RESULT IN SERIOUS BODILY INJURY AND/ OR PROPERTY DAMAGE. IF YOU HAVE QUESTIONS CONVERNING ASSEMBLY OR OPERATION, CALL OUR SERVICE CENTER AT 1-800-913-8999 LP –... - Page 5 The Fuel System Gas grills are used safely by millions of people when following simple safety precautions. The items in the fuel system are designed for operation with the Charmglow Table top grill. They must not be replaced with any other brand. (See parts list for replacement items.) GAS BURNER: The gas burner is constructed of tubular stainless steel and should not require maintenance other than inspection for insects/nests inside the air intake slots.
- Page 6 connection for access directly to the gas regulator supplied with this appliance. Care should be taken when threading the cylinder to the regulator to engage threads correctly to achieve the proper and intended connection. When disconnecting or connecting the gas cylinder, be careful that the regulator does not strike the grill, the ground, or any other surfaces.
-
Page 7: Illustrated Parts Breakdown
H16Y06P-1 ILLUSTRATED PARTS BREAKDOWN MODEL 820-0002 TABLE-TOP GRILL REF# Description Main lid 1 PCS Logo 1 PCS Door latch 1 SET Main lid handle 1 PCS Firebox heat shield 1 PCS Main burner bowl assembly 1 PCS Grease tray latch... -
Page 8: Assembly Instruction
Assembly Instruction PLEASE READ THE INSTRUCTION CAREFULLY AND FOLLOW STEP BY STEP. Your Charmglow Table Top Grill is pre-assembled. The only part that you need to assemble is to connect gas regulator into your grill. The estimated time for one person to assemble to tabletop grill is 5 to 8 minutes. -
Page 9: Lighting Instruction
Lighting Instructions Make sure the regulator is properly secured into the burner end. Make sure the propane cylinder is tightly threaded into the regulator-hand-tighten only. Place stacks in up position. Open lid. Always open lid when lighting. Allow five minutes to get air out. Locate lighting access hole on right side of the panel. -
Page 10: Lighting Rod Assembly Instruction
Lightning Rod Assembly Instructions TURNING GRILL OFF Open lid. Turn regulator control knob to “OFF”. Caution: Do not attempt to re-light without following all lighting instructions. 4. Allow grill body to cool at least 30 minutes before attempting to move or transport. PLEASE READ THE INSTRUCTION CAREFULLY AND FOLLOW STEP BY STEP. - Page 11 2. Please attach the match to the front end of the lightning rod, and stick the lightning rod into the access to manual lighting hole to light the fire as indicated in below picture. Access to manual lighting H16Y06P-1...
-
Page 12: Care And Maintenance
Care & Maintenance There is very little care and maintenance needed. The Charmglow Table Top Grill is designed and made of materials that will last many years with normal use. Following these instructions will improve the longevity and quality of cooking. To ensure safe operation of your grill, the area of cooking should always be kept free of combustible materials of any type, such as gasoline or other flammable vapors or liquids. -
Page 13: Cooking Instruction
Cooking Instructions Allow grill to warm up with lid closed for 20-30 minutes prior to cooking. This Charmglow Table Top Grill model is equipped with an adjustable HIGH/MED/LOW burner control. This allows for complete flexibility in cooking temperatures. HIGH setting has a cooking temperature of approximately 450 degrees F. MED is approximately 400 degrees F. -
Page 14: Trouble Shooting
TROUBLE SHOOTING WARNING Spiders and insects can nest inside the burners of the grill and disrupt gas flow. This very dangerous condition could cause a fire behind the valve panel, therby damaging the grill and making it unsafe for operation. Inspect the grill at least twice a year When to Look for Spiders You should inspect the burners at least twice a year or immediately after any of the following conditions occur:... -
Page 15: Limited Warranty
Our obligation under this warranty is limited to repair or replacement, at our option, of the product during the warranty period. The extent of any liability of Nexgrill Industries, Inc under this warranty is limited to repair or replacement. This warranty does not cover normal wear of parts, discoloration of the stainless steel parts, or damage resulting from any of the following: negligent use or misuse of the product, use on improper fuel/gas supply, use contrary to operating instructions, or alteration by any person other than our factory service center.
