Technical Specifications; Dimensions And Weight; Power Specifications - Cisco UCS C210 M2 Spec Sheet

TECHNICAL SPECIFICATIONS

Dimensions and Weight

Table 29 UCS C210 M2 Dimensions and Weight
Parameter
Height
Width
Depth
Front Clearance
Side Clearance
Rear Clearance
Weight
Notes . . .
1. The system weight given here is an estimate for a fully configured system and will vary depending on the
number of peripheral devices and power supplies.

Power Specifications

The general power specifications for the C210 M2 server are listed in
Table 30 UCS C210 M2 Power Specifications
Description
AC input voltage
AC input frequency
Maximum AC input current
Maximum AC inrush current
Maximum output power for each
power supply
Power supply output voltage
Power supply efficiency
Cisco UCS C210 M2 General-Purpose Rack-Mount Server
1
Value
3.45 in. (8.76 cm)
17.39 in.(44.17 cm)
28.35 in. (72.01 cm)
3 in. (7.62 cm)
1 in. (2.54 cm)
6 in. (15.24 cm)
*
50.70 lbs (23 kg)
Specification
100 to 120 VAC nominal
200 to 240 VAC nominal
(Range: 90 to 264 VAC)
50 to 60 Hz nominal (Range: 47 to 63 Hz)
8 A at 100 VAC
30 A peak sub-cycle duration
650 W
Main power: 12 VDC
Standby Power: 5 VDC
92% Peak, complies with 80Plus Gold Standard
TECHNICAL SPECIFICATIONS
Table 30.
59
