Cisco UCS C210 M2 Spec Sheet page 18

CONFIGURING the SERVER
Table 6 Available RAID Options (continued)
Product ID (PID)
R2XX-PL003
RAID Battery Backup Option (not available with mezzanine card)
R2XX-LBBU2
RAID Configuration (note: Mezzanine card supports only RAID 0, 1, and 1E)
R2XX-RAID0
R2XX-RAID1
R2XX-RAID5
R2XX-RAID6
R2XX-RAID10
.
18
PID Description
LSI MegaRAID SAS 9261-8i (RAID 0, 1, 5, 6, 10)
Takes up one of five available PCIe slots (must be installed in slot #4)
■
Supports up to eight internal SAS or SATA drives with the factory default SAS
■
Extender installed. You can mix SAS and SATA drive types, but you cannot mix
HDD and SSD drive types.
Supports up to 16 internal SAS or SATA drives with the optional SAS Expander
■
installed. You can mix SAS and SATA drive types, but you cannot mix HDD and
SSD drive types.
Includes 512 MB of write cache
■
Battery backup option available (see the battery backup PID section in this
■
table)
Factory-configured RAID options: RAID 0, 1, 5, 6, 10 (see the RAID PIDs
■
section in this table)
Battery Backup
Factory pre-configured RAID striping option
Enable RAID 0 Setting. Requires a minimum of 1 hard drive.
Factory pre-configured RAID mirroring option
Enable RAID 1 Setting. Requires exactly 2 drives, with same size, speed, capacity.
Factory pre-configured RAID option
Enable RAID 5 Setting. Requires minimum 3 drives of same size, speed, capacity.
Factory pre-configured RAID option
Enable RAID 6 Setting. Requires minimum 4 drives of same size, speed, capacity.
Factory pre-configured RAID option
Enable RAID 10 Setting. Requires an even number of drives (minimum 4 drives) of
same size, speed, capacity.
NOTE: No RAID option can be chosen if you have one of the following configurations:
• A mix of SAS and SATA drives
• No drives
Cisco UCS C210 M2 General-Purpose Rack-Mount Server
