Summary of Contents for Vortex Summit SS-P
- Page 2 TRIPOD KIT The Summit SS-P combines a 3-way quick-release pan head for smooth Features handling with a compact size to provide solid support for your optics. 5-section legs for maximum height with minimum packing length. Light weight for an easy carry. Twist leg locks for variable height adjustment and reduced bulk.
- Page 3 TRIPOD KIT Adjusting the 3-way pan head Adjusting the tripod height Column Height Grasp the Control Arm and rotate counter-clockwise to adjust the pan Loosen and tighten the Column Height Adjustment Knob head position, then rotate clockwise to secure in place. To detach the Adjustment Knob to raise or lower the quick-release plate, flip the Plate Release Lever out and slide the quick- center column.
- Page 4 Set the legs of the Summit SS-P to one of three angles. To adjust the leg This tripod is warranted to be free of defects in materials and angle, slide the Release Tab to the right and pivot the leg outward to the workmanship for three years after purchase.
