Vortex Summit XLT Manual

- 1 -
Our ultimate field-packing tripod, the Summit
of size, weight, rugged build and fast operation. No other tripod can get out
of your pack and on target quicker than a Summit.
Compact Ball Head
Bubble Levels
Center Column
Safety Latch and
Lever Lock
Anodized
Aluminum
Legs
Removable
Rubber
Center Column
Feet
Section
Attachable

Balance Hook

- 3 -
is the perfect combination
TM
Quick-Release Plate
Leg Angle
Release Tabs
Twist Locks

Features

5-section legs for maximum height with minimum
packing length.
Light weight for an easy carry.
Twist leg locks for variable height adjustment and
reduced bulk.
Compact ball head with quick-release plate and
locking mechanism.
Variable leg angle adjustments allow for flexible
positioning.
Balance hook holds extra weight for greater
stability in windy conditions.
Rubber feet stand sure-footed on slick surfaces.

Specifications

Height Range 7.6–64.1"
Maximum Load 11 pounds
Leg Sections 5
Leg Angles 3
Weight 3.6 pounds
Folded Height 18.1"
Folded Width 4.0"

Adjusting the ball head

The Ball Head can be adjusted to any angle. Loosen or tighten the
Positioning Knob to
adjust the plate angle.
To attach or detach the
quick-release plate, pull
the Throw Lever out.
Attach the quick-release Positioning Knob
plate to the desired optic
or camera.
Bubble Levels
If desired, reference the Bubble Levels to
ensure tripod plate is level.
Multiple Bubble Levels
Balance Hook
To help stabilize the tripod in windy conditions, attach the Balance
Hook and hang a weight (not supplied) from it.
- 2 -
QR Plate
Quick-Release
Throw Lever
- 4 -
