Summary of Contents for Vortex Radian Carbon
- Page 1 Radian ™ CARBON PRODUCT MANUAL...
-
Page 2: Specifications
Radian ™ CARBON SPECIFICATIONS Bubble Level Leg Angle Stop Latch Leg Material Carbon Fiber Quick-Release Locking Latch Maximum Operating Height 62.9" (1600mm) Minimum Operating Height 3.9" (100mm) Quick-Release Button Folded Length 24.6" (625mm) Weight 5.4 lbs. (2.4kg) Number of Leg Sections 4 Sections Spiked feet can be installed if needed. -
Page 3: Basic Adjustments
Radian ™ CARBON Adjusting Leg Section Length BASIC ADJUSTMENTS Each of the four tripod leg sections can be extended to Twist Leg Lock Adjusting Leg Angles adjust the tripod’s height. to loosen Each of the four tripod leg sections can be adjusted out to To adjust the length of a leg section: or tighten. - Page 4 Radian ™ CARBON Attaching/Removing a Head To mount a head to the tripod: 1. Lift the Quick-Release Locking Latch on the tripod. VIP WARRANTY 2. Press and hold the Quick-Release Button and fully OUR UNCONDITIONAL PROMISE TO YOU. seat head into the tripod. Once seated, the head We promise to repair or replace the product.
- Page 5 M-00299-0 © 2020 Vortex Optics ® Registered Trademark and TM Trademark of Vortex Optics.
