Removal and Replacement Procedures
5. Remove the TM2.5 × 5.0 screw 1 that secures the display
video cable ground loop (Figure 5-21).
6. Remove the display video cable 2 from the routing channel
in the heat spreader.
Figure 5-21. Removing the Display Video Cable
Ground Cable
5–26
Maintenance and Service Guide
