QuickSpecs
Overview
W h a t ' s N e w
Intel Pentium 4 processors –
up to 2.2 GHz; Intel Celeron
processors – up to 1.5 GHz
400-MHz bus
4X AGP Graphics
MultiPort wireless communication
options
Choice of Touchpad or Dual
Pointing Device
At A Glance
Intel Pentium 4 processors – up to
2.2 GHz; Intel Celeron processors
– up to 1.5 GHz
15-inch XGA, SXGA+ and
14.1-inch XGA display
Configurations as light as
6.6 lb/3.0 kg weight
(14-inch panel)
1.55 in/3.95 cm thin
256-MB DDR SDRAM (266 MHz),
Upgradeable to 1024 MB
Up to 40-GB SMART hard drives
Mini PCI modem and integrated
NIC
Full-size keyboard
Microsoft Windows XP Pro and
Microsoft Windows 2000
Includes a One-year, Worldwide
Warranty. —Certain restrictions
and exclusions apply. Consult
the Compaq Customer Support
Center for details.
W h a t ' s S p e c i a l
Intel Pentium 4 processors
All-in-one convenient design
Latest USB interface
Wireless features thru award-
winning MultiPort
Common Docking Options
DA-11371
World Wide — Version 6 — October 3, 2002
Compaq Evo Notebook N1000v
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the N1000v and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Compaq N1000v

Summary of Contents for Compaq N1000v

  • Page 1 W h a t ’ s S p e c i a l Intel Pentium 4 processors All-in-one convenient design Latest USB interface Wireless features thru award- winning MultiPort Common Docking Options DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v...

  • Page 2: Standard Features

    Standard/Maximum 256 MB (266 MHz) DDR SDRAM (256 MB SODIMM in slot 1) M e m o r y NOTE: Due to the non-industry standard nature of some third-party memory modules, we recommend Compaq C o m m u n i c a t i o n s 10/100 NIC is integrated on the system board Type III Mini PCI 56K (V.92) modem...
  • Page 3 Compaq Security Management Safety and Comfort Guide Acrobat Reader Reference Guide Norton Internet Security Compaq Easy Access Button Software DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v One Type II 1 (4 Mb/s support) (IrDA 4 MB compliant.
  • Page 4 B a t t e r y Standard 8-cell Lithium-Ion battery. The Evo Notebook N1000v provides over 2 hours of battery life using the standard 8-cell Lithium-Ion battery.. NOTE: Actual results may vary with product model, configuration, and individual usage. Compaq results of 2:20 NOTE: This test was performed without independent verification by eTesting Labs Inc.
  • Page 5 QuickSpecs Compaq Evo Notebook N1000v Standard Features N a m i n g C o n v e n t i o n The Etymology of a Model name: DA-11371 World Wide — Version 6 — October 3, 2002...
  • Page 6 Video Memory Audio Operating System Warranty DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 15-inch color TFT SXGA+ 2.2 GHz Intel Pentium 4 processor 512-KB, L2 Cache Standard 256 MB (266 MHz) DDR SDRAM...
  • Page 7 Video Memory Audio Operating System Warranty DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 15-inch color TFT SXGA+ 2.2 GHz Intel Pentium 4 processor 512-KB, L2 Cache Standard 256 MB (266 MHz) DDR SDRAM...
  • Page 8 Video Memory Audio Operating System Warranty DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 14.1-inch color TFT XGA 2.0 GHz Intel Pentium 4 processor 512-KB, L2 Cache Standard 256 MB (266 MHz) DDR SDRAM...
  • Page 9 Video Memory Audio Operating System Warranty DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 14.1-inch color TFT XGA 1.5 GHz Intel Celeron processor 256-KB, L2 Cache Standard 256 MB (266 MHz) DDR SDRAM Maximum...
  • Page 10 Video Memory Audio Operating System Warranty DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 14.1-inch color TFT XGA 1.5 GHz Intel Celeron processor 256-KB, L2 Cache Standard 256 MB (266 MHz) DDR SDRAM Maximum...
  • Page 11 Video Memory Audio Operating System Warranty DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 15-inch color TFT XGA 2.0 GHz Intel Pentium 4 processor 512-KB, L2 Cache Standard 128 MB (266 MHz) DDR SDRAM...
  • Page 12 Video Memory Audio Operating System Warranty DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 14-inch color TFT XGA 1.5 GHz Intel Celeron processor 256-KB, L2 Cache Standard 128 MB (266 MHz) DDR SDRAM Maximum...
  • Page 13 470036-628 470036-631 470036-619 470036-620 470036-629 470036-630 470036-689 470036-690 470036-694 470036-695 470036-698 470036-699 Compaq Evo Notebook N1000v 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA 256 MB 256 MB 128 MB 30 GB 40 GB 20 GB 32 MB 32 MB 32 MB...
  • Page 14 8-cell 4.0Ah 470036-702 470036-703 470036-709 470036-708 470036-632 470036-633 470036-710 470036-711 470036-717 470036-716 Compaq Evo Notebook N1000v 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA 256 MB 256 MB 128 MB 30 GB 40 GB 20 GB 32 MB 32 MB 32 MB...
  • Page 15 8-cell 4.0Ah 470036-718 470036-719 470036-725 470036-724 470036-727 470036-728 470036-735 470036-734 470036-736 470036-737 Compaq Evo Notebook N1000v 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA 256 MB 256 MB 128 MB 30 GB 40 GB 20 GB 32 MB 32 MB 32 MB...
  • Page 16 8-cell 4.0Ah 470036-745 470036-744 470036-746 470036-747 470036-753 470036-752 470036-754 470036-755 470036-761 470036-760 Compaq Evo Notebook N1000v 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA 256 MB 256 MB 128 MB 30 GB 40 GB 20 GB 32 MB 32 MB 32 MB...
  • Page 17 Comm Modem/NIC Modem/NIC Input Touchpad Touchpad Battery 8-cell 4.0Ah 8-cell 4.0Ah 470036-762 470036-763 470036-769 470036-768 Compaq Evo Notebook N1000v 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA 256 MB 256 MB 128 MB 30 GB 40 GB 20 GB 32 MB 32 MB...
  • Page 18 Touchpad Battery 8-cell 4.0Ah 8-cell 4.0Ah 470036-616 470036-622 470036-625 470036-626 470036-617 470036-623 470036-624 470036-627 Compaq Evo Notebook N1000v 15.0-inch SXGA+ 15.0-inch SXGA+ 15.0-inch XGA 256 MB 256 MB 128 MB 30 GB 40 GB 20 GB 32 MB 32 MB...

  • Page 19: Wireless Connectivity

    USB Disk-on-Key – 8 MB Connectivity Compaq Type III Mini PCI 56K (V.90) Modem Compaq Type III Mini PCI 56K (V.90) Modem plus 10/100 NIC Combo 100BaseTX Ethernet Upgrade 1394 PC Card NOTE: Designed only to allow faster downloads from V.90 compliant sources. Maximum achievable download Wireless Connectivity 802.11b MultiPort Wireless LAN module...

  • Page 20: Useful Accessories

    Options Security Biometric PC Card Security Cable Lock Compaq Smart Card PC Card Reader Useful Accessories Compaq iPAQ Microportable Projector MP1200 Compaq iPAQ Microportable Projector MP3800 Compaq iPAQ Microportable Projector MP4800 Lamp Module L20 for MP1200 Lamp Module L30 for MP3800...
  • Page 21 NOTE: This chart does not represent all possible memory configurations. Due to the non-industry standard nature of some third-party memory modules, we strongly recommend using only Compaq branded memory modules to ensure compatibility. Following are memory options available from Compaq:...
  • Page 22 40-GB SMART Hard Drive 30-GB SMART Hard Drive 20-GB SMART Hard Drive DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v Dedicated optical drive Primary Hard drive Dedicated disk drive Drive Supported Dedicated Disk Drive...

  • Page 23: Technical Specifications

    Vibration Maximum Altitude (unpressurized) DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 15-inch and 14.1-inch TFT 1.55 x 12.89 x 10.53in/3.95 x 32.75 x 26.75 cm panel displays With P4 processor 14 inch : LCD, DVD or CD-...
  • Page 24 Pixel Resolution Backlight Character Display Total Power Consumption DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 11.22 x 8.46 in/28.5 x 21.5 cm 14.1 in/35.81 cm Internal Panel Supports, Side Mounted Up to 16.8M 150:1...

  • Page 25: Hard Drives

    (typical reads, including settling) Rotational Speed Logical Blocks Operating Temperature DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 0.21 lb/95 g 40 GB 0.374 in / 9.5 mm 2.75in / 70 mm ATA-5 Synchronous (maximum)

  • Page 26: Diskette Drive

    Access Times Weight External AC Adapter Power Supply (Input) DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 0.21 lb/95 g 20 GB 0.374 in / 9.5 mm 2.75 in / 70 mm ATA-5 Synchronous (maximum)

  • Page 27: Dvd/Cd-Rw Drive

    (typical, including settling) Start-up Time Stop Time DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 4.95 x 3.46 x 0.80 in/12.5 x 8.8 x 2.0 cm 0.96 lb/0.43 kg Voltage 14.8 V Amp-hour capacity Minimum 3.7 Ah...

  • Page 28: Dvd-Rom Drive

    Data Transfer Rate (typical, including settling) Start-up Time Stop Time DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v 0.59 in/1.5 cm 12 cm/8 cm 1.2 mm 0.74 µm Random (typical) < 125 ms DVD Media Full-Stroke (typical) <...
  • Page 29 Media Access Protocol OS Support Protocols Supported LED Activity DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v Compaq MultiPort 0.22 lb/100 g (maximum) Operating 14 to 149 F/–10 to 65 C Non-operating –40 to 176 F/–40 to 80 C...
  • Page 30 Channels Data Rates and throughput 1 Mbps Antenna type Range Profile Support DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v Data Rate Operating Distance 11 Mbps 5.5 Mbps 1 Mbps Compaq MultiPort 1.1 Compliant 2.2 x 6.6 x 0.55 in/5.6 x 16.7 x 1.4 cm...

  • Page 31: Protocols Supported

    OS Support Protocols Supported LED Activity Certifications DA-11371 World Wide — Version 6 — October 3, 2002 Compaq Evo Notebook N1000v Service Discovery (determine what Bluetooth devices are within range and support authorization) Synchronization: PDAs to PCs Portable to Desktop File Transfer: File and directory browsing and navigation on another Bluetooth device.
  • Page 32 Technical Specifications Form Factor Type III Mini PCI 56K (V.92) Modem Power Management Support APM Revision 1.2, ACPI, Compaq Power Management Extensions for Microsoft Approvals/Certifications Data Mode Capabilities Fax Mode Capabilities Command Set DA-11371 World Wide — Version 6 — October 3, 2002...
  • Page 33 U.S. and other countries. All other product names mentioned herein may be trademarks of their respective companies. Compaq shall not be liable for technical or editorial errors or omissions contained herein. The information is provided as is without warranty of any kind and is subject to change without notice.
