Dvd Mt Pcb Assy(6/6) - Pioneer DV-300-K Service Manual

1

10.6 DVD MT PCB ASSY(6/6)

DVD MT PCB ASSY (6/6) (A2K008A130)
• POWER PORT BLOCK
A
B
C
FROM/TO POWER
CP4003 (CP502)
A2001WV2-14P
1 GND
2 P.CON+12V
3 AT+12V for MUTE
D
4 GND
5 P.CON+5V
6 P.CON+6V
7 GND(M)
8 AT+3.3V
9 AT+3.3V
10 P.ON-H
11 GND(D)
12 FL DC-
13 FL DC+
14 -28V
E
F
ATTENTION
:LES PIECES REPAREES PAR UN
56
1
2
DANGEREUSES AN POINT DE VUE SECURITE
N'UTILISER QUE CELLS DECRITES
DANS LA NOMENCLATURE DES PIECES
2
3
REG+1.8V IC
IC4006
LM1117S-ADJ
TP4002
CAUTION
ETANT :SINCE THESE PARTS MARKED BY
CRITICAL FOR SAFETY,USE ONES
DESCRIBED IN PARTS LIST ONLY
DV-300-K
3
4
VIN VOUT ADJ
3 2 1
3.3 1.8 0.6
W820
R4011 R4012
15 68 +-1%
ARE
4
