American Standard Silhouette 7185.011 Specification Sheet

SILHOUETTE™ 18" ISLAND SINK
• Americast brand engineered material
®
• Single bowl design
• Titanium enamel - heat resistant up to 1000°
• Acid-resisting glossy porcelain finish
• Tile edge installation
• Silicone sealant supplied
• Available in 1 or 3 faucet hole configuration
• Customized hole punchings available
(See page G56)
Tile Edge:
❏ 7185.011 Center hole only
❏
7185.813 3 hole

Nominal Dimensions:

457 x 447 x 216mm
(18" x 18" x 8-1/2")

Bowl sizes:

375mm (14-3/4") wide
375mm (14-3/4") front to back
203mm (8") deep

Compliance Certifications -

Meets or Exceeds the Following Specifications:
• ASME A112.19.4M for Americast Plumbing Fixtures
• ASTM E162 for Flammability
• NFPA 258 for Smoke Density

To Be Specified:

❏ Color:
❏ Faucet*:
❏ Faucet Finish:
❏ Basket Strainer: 4331.013
❏ Soap Dispenser: 4503.115, Color:
❏ Trap:

Optional Accessories:

❏ Small Wood Cutting Board: 9000.185
❏ Colander for Cutting Board: 8102.100, Color:
* See faucet section for available models
© 2008 AS America Inc.
Shown with 7100.271H Heritage Bar Faucet with
Wrist Blade Handle (not included)
SEE REVERSE SIDE FOR ROUGHING-IN DIMENSIONS
G39
SILHOUETTE™ 18"
ISLAND SINK
AMERICAST
Revised 2/08
®
