American Standard Ovalyn 0495.221 Specification Sheet

BARRIER FREE
OVALYN™ UNDERCOUNTER SINK
• Classic oval undermount sink
• Made from vitreous china
• Front overflow
• Supplied with mounting kit (047194-0070A)
and template
❏ 0495.221 Unglazed rim
435 x 359mm
(17-1/8" x 14-1/8")
❏
0495.300 Glazed underside
Bowl size:
382mm (15-1/16") wide
306mm (12-1/16") front to back
140mm (5-1/2") deep
❏
0496.221 Unglazed rim
489 x 413mm
(19-1/4" x 16-1/4")
❏ 0496.300 Glazed underside
Bowl size:
432mm (17") wide
356mm (14") front to back
140mm (5-1/2") deep
❏ 0497.221 Unglazed rim
546 x 441mm
(21-1/2" x 17-3/8")
❏ 0497.300 Glazed underside
Bowl size:
483mm (19") wide
391mm (15-3/8") front to back
140mm (5-1/2") deep
Compliance Certifications -
Meets or Exceeds the Following Specifications:
• ASME A112.19.2M for Vitreous China Fixtures
• CAN/CSA B45 series
To Be Specified:
❏ Color: ❏ White ❏ Bone ❏ Linen
❏ Silver ❏ Fawn Beige ❏ Black
❏ Faucet*:
❏ Faucet Finish:
❏ Supplies:
❏ 1-1/4" Trap:
* See faucet section for additional models available
© 2008 AS America Inc.
UNDERCOUNTER SINK
SEE REVERSE FOR ROUGHING-IN DIMENSIONS
J53
OVALYN™
VITREOUS CHINA
Revised 2/08
