- Page 1 INSTRUCTION MANUAL WDR Super High Resolution Day & Night Color Camera Model No: REVDN700-2 Vandal Proof dome Camera...
- Page 2 LIMITATION OF LIABILITY THE INFORMATION IN THIS PUBLICATION IS BELIEVED TO BE ACCURATE IN ALL RESPECTS, HOWEVER, WE CANNOT ASSUME RESPONSIBILITY FOR ANY CONSEQUENCES RESULTING FROM THE USE THEREOF. THE INFORMATION CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT NOTICE. REVISIONS OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO INCORPORATE SUCH CHANGES...
- Page 3 CE COMPLIANCE STATEMENT WARNING This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. PRECAUTIONS Before installation, carefully read the manual to ensure correct operation and setup, heeding all warnings and instructions.
-
Page 4: Table Of Contents
TABLE OF CONTENTS CONTENTS OF PACKAGE ------------------------------------------------------------------------- 4 INTRODUCTION --------------------------------------------------------------------------------------- 5 CAMERA CONNECTIONS -------------------------------------------------------------------------- 6 INSTALLATION ----------------------------------------------------------------------------------------- 7 LENS ADJUSTMENT --------------------------------------------------------------------------------- 9 CAMERA OVERVIEW -------------------------------------------------------------------------------- 10 CAMERA ADJUSTMENT ---------------------------------------------------------------------------- 11 EXTERNAL DIMENSION ---------------------------------------------------------------------------- 20 SPECIFICATIONS ------------------------------------------------------------------------------------- 22 CONTENTS OF PACKAGE Installation of the camera must be performed by qualified service personnel in accordance with all local and national electrical and mechanical codes. -
Page 5: Introduction
INTRODUCTION The camera provided high-quality image using SONY 1/3” CCD and digital signal processing LSIs. Features: 1/3" Super-HAD CCD Super high-resolution (700TVL) Wide Dynamic Range Day & Night(Auto, Manual, External, Filter delay, Change level adjust) 0.1Lux(Color), 0.01 Lux(BW) @ F1.2 50IRE... -
Page 6: Camera Connections
CAMERA CONNECTIONS Connection Cable Description COLOR Description AC24V/DC12V WHITE AC24V/DC12V BLUE RS485(-) GREEN RS485(+) YELLOW ALARM OUT GRAY DN EXT-IN BLACK&WHITE DN EXT-OUT BLACK SKY BLUE UTP+(Option) PINK UTP- (Option) 1) External Day/Night Control Select Day/Night mode using external equipment, by connecting control lines to the appropriate terminals. -
Page 7: Installation
INSTALLATION 1. Loosen the four torx screws located midway up the front of the housing leaving the screws intact in the front portion. (Fig. 1) 2. Drill the mounting location, using the Drilling guide. (Fig. 3) 3. Attach the housing to the ceiling using suitable fasteners, M6x35 tapping screws are supplied. -
Page 8: Lens Adjustment
LENS ADJUSTMENT Field of view: Adjust setting from Telephoto (T) to wide (W) field of View. Focus: Adjust lens focus from near (N) to infinity. DC AUTO IRIS LENS 2.6-6mm 4-9mm 2.8~12mm 6-50mm 1/3” CCD 1/3" CCD 1/3" CCD 1/3" CCD Image Size 2.6-6.0mm 4.0-9.0mm... -
Page 9: Camera Overview
CAMERA OVERVIEW Right Down Left Enter Test Video Output External AD Key Input BNC/UTP Switch External AD Key Control (optional) White / AD output D Key Terminal / Orange GND Terminal / Brown Black / GND <Remarks> 1) Menu: Represent present menu subject on top of screen. In case of used Multi-Camset, Represent CAM ID and “camset”... -
Page 10: Camera Adjustment
* There are 4 types of configuration area. Editing Area(No Save), Default(Read Only). Save Area(Use on Start), Backup * Don’t Power off while doing Save, Load, Backup, Overwrite CAMERA ADJUSTMENT <White Balance> 1) ATW/Wide Mode: No limits in the range of color temperature. 2) ATW/Indoor Mode: Suitable for low color temperature. - Page 11 improve this phenomenon. NOTE: * Motion is none : Noise removal mode. * Motion is occured: Fast screen update mode. 3) Low Light: If using UDF function, this function being disabled. - AGC: Boost the signal and adjusting the brightness. (Off/Low/Mid/High) - Sens-Up: By summing multiple fields, adjusting the proper brightness in low light conditions (2X~ 256X) - Apert : In low light conditions, reduce noise by lowing the sharpness value.
- Page 12 If you exit menu, doing Initialize started while 4~5 seconds the background. During initialization the background, it is good to be none of moving objects. When Day / Night mode is changed or Cam Set is changed, the background of the re- initialization performed.
- Page 13 Poly (Polygon) It you select one of “a,b,c,d”, the active point is displayed. Move the point with 4-arrow keys. Press [ENTER] key is to finish edit point. NOTE: * For more than 180 of interior angle is not permitted. Line: Select Start/End Point. It you select one of start/end, the active point is displayed.
- Page 14 *) Please don’t use as a signal for video recording start. *) In Simple mode is not supported. Detect different region to stored background. Rect, Poly Abandon/Abs *) Please don’t use as a signal for video recording start. *) In Simple mode is not supported. Detect object moving.
- Page 15 Rst Time (sec): Time for maintain event. After this, background will be update. Unfocus : Detection on/off of unfocused state/defocused state. - Windy Setup (Windy Area Detection Setup) : Not applied in Simple PVA mode Sens(Sensitivity) : Adjust sensitivity of windy object detection. Det Time (sec): Time for judge to windy object.
- Page 16 live mode. So not only reducing the recording data but also not to miss object movement. - No Motion(s): Adjust Interval while no motion. - Motion (0.1s): Adjust Interval while motion exists. <System Setup> 1) General - Cam Info: Display camera basic information. NOTE: * Cam ID/Baud rate/Protocol/Lens Type/CCD Type/Video System/Firmware Version - System Lock: System locking by 4-characters PID (Lock/Unlock)
- Page 17 * User can stop the proceeding while on operating. Done: Complete white pixel detection. View Detected WP: Print detected pixel on screen. Retry: Restart WPC process. Accept: Store WPC result, and return to precious menu. Dynamic Automated white pixel compensation for not compensated pixel by static method, No limits of compensation pixel number.
- Page 18 3) Lens : Select lens (DC lens/Video lens/Manual Lens) - Iris Speed: Only for DC/Video Lens, Adjust Iris speed. NOTE: * If iris speed is too high, it can occur AE hunting. * If iris speed is too low, IRIS adjusting operate too slowly. 4) LLC (Line Lock Control) Active only used AC Power.
-
Page 19: External Dimension
EXTERNAL DIMENSION 0.1 in. (2.5mm thick), impact-resistant P.C (LEXAN) Window Size 3.93 in. (10cm) diameter One 1" (25mm) opening holes Cable Entry 1.66 lb. (760 g) Weight – Unit: 2.11 lb. (960 g) Shipping:... -
Page 20: Specifications
DUAL(DC12V, AC24V) ±10% Power Consumption 3.5 Watts (300mA) Power Connector 2-Pin Terminal Block VIDEO Image Device 1/3" Sony EXview 960H CCD II Total Pixels 1020(H) x 508(V) 1020(H) x 596(V) Effective Pixels 976(H) x 494(V) 976(H) x 582(V) Scanning System 2:1 Interlace Sync. - Page 21 5030xxxxA...
