Front Panel
1 2
Input
Tone
3
1.
Input Knob and LED
Adjust the Input Knob so that while you sing, the LED
beside it flashes green, sometimes orange but never red.
2.Tone Button
This engages the Live Engineer Effects which
automatically modifies your voice and makes it sound
smoother and brighter. When engaged, this effect is
always on your voice, even in Bypass.
12
3 4 5
Guitar FX Harmony
Auto
3. Guitar Mix Knob
Controls your guitar volume when it's routed to the main
outputs (when the Guitar Thru jack is not used).The center
Auto detent position automatically balances your guitar
volume with your voice. Adjusting above or below the Auto
position removes the automatic guitar level feature.
4. FX (Effects) Level Knob
Raises or lowers the mix level of the effect selected with
the FX button.
5. Harmony Level Knob
Adjusts the mix levels of the harmony and double effects.
