Tripp Lite PDU3MV6H50 Brochure & Specs

3-Phase Metered PDU, 12.6 kW, 45 208V outlets (36
C13, 9 C19), 6 ft Hubbell CS8365C 50A input
connection
MODEL NUMBER: PDU3MV6H50
Description
Tripp Lite 3 phase Metered PDU / Power Distribution Units offer real-time local reporting of current levels in amps
via set of 3 built-in digital meters. Enables visual monitoring of PDU current levels to preserve proper loading
balance and prevent circuit overloads as additional equipment is added. Offers reliable rackmount multi-outlet
power distribution from any protected UPS, generator or mains input power source. High quality design includes
rugged all-metal housing and secure rackmount installation with included mounting accessories.
Features
12.6kW 3 phase 208V Metered Power Distribution Unit / PDU
Set of 3 built-in current meters continuously report load current in amps for all 3 output phases
Attached Hubbell CS8365C 50A (3P+E) 208V 3 phase input plug with 6 ft. / 1.8m cord
0U, 70 in. / 178cm vertical form factor supports installation in 2 or 4 post equipment racks
45 total 208V outlets (36 C13, 9 C19) arranged in three breakered single phase output load banks
Included cord retention brackets keep vital network equipment plugged in and continuously powered
Toolless mounting supported in button-mount compatible racks, plus nut-and-bolt mounting brackets for other mounting applications (set of 2 9mm
buttons pre-installed, 2 9mm and 4 6mm spare buttons included)
TAA Compliant Version Available - Order Tripp Lite PDU3MV6H50TAA

Specifications

OVERVIEW
PDU Type
OUTPUT
Metered
1 / 3
Highlights
Metered 12.6kW 3 Phase 208V
PDU; 70 in. / 178cm 0U vertical
rackmount
Reports load current per-phase
via set of 3 built-in current meters
Hubbell CS8365C 50A (3P+E)
208V 3 phase input; 6 ft. / 1.8m
line cord
45 208V outlets total (36 C13, 9
C19)
Toolless button-mount
installation; cord retention
brackets included
Applications
Ideal for 3 phase network
configurations in datacenters and
heavily configured equipment racks
Package Includes
Metered PDU with pre-installed
mounting buttons
Cord retention brackets
Spare installation buttons (2 9mm
/ 4 6mm)
Rack mounting brackets
Owner's manual
