3-Phase Monitored & Switched
0U Power Distribution Units
208V MONITORED MODELS
PDU3EVN3L2130
PDU3EVN10L2130
PDU3EVN3L2120
PDU3EVN6L2120
PDU3EVN10L2120
PDU3EVN6L2130
208V SWITCHED MODELS
PDU3EVSR6G60A
PDU3EVSR6H50A
200 – 240V MONITORED MODELS
PDU3EVN6G30B
PDU3EVN10G30B
PDU3EVN3G60B
PDU3EVN6G60B
PDU3EVN10G60B
PDU3EVN3H50B
PDU3EVN6H50B
PDU3EVN6H50BA
PDU3EVN10H50B
PDU3EVN3L1520
PDU3EVN6L1520
PDU3EVN10L1520
PDU3EVN3L1530B
PDU3EVN6L1530B
PDU3EVN10L1530B
PDU3EVN3L2130B
PDU3EVN6L2130B
PDU3EVN10L2130B
PDU3EVN2
PDU3EVN6G60C
