Tripp Lite SRCOOL12K Quick Manual

120V Portable Air Conditioning Unit for IT
Equipment in Small Server Rooms and Network
Closets
MODEL NUMBER: SRCOOL12K
Description
With 12,000BTU of cooling power, the 120V, 60 Hz SRCOOL12K is ideal for use in data centers, server and
wiring closets, IT environments, home and small business offices, conference rooms, warehouses,
entertainment centers or other venues with heat-sensitive equipment, particularly in areas that facility air
conditioning can't reach. The SRCOOL12K not only adjusts ambient room temperatures, but can also dehumidify
and filter the air, providing better air quality for enhanced equipment performance with minimal noise and power
consumption.
The SRCOOL12K has a built-in evaporator that expels the condensed water through the exhaust duct, so there
is no need for a drain tube, drain pan or water collection tank. Both a standard louvered vent (for general room
cooling) and a directional ducted cooling vent (to direct cold air where most needed) are provided. A directional
exhaust duct safely removes hot air from the room. SRCOOL12K comes equipped with an auto-restart feature
that retains all system settings and returns the unit back to its last operational state after AC power is restored. A
built-in timer enables the unit to be programmed for unattended start-up and shutdown. Controls and displays
are conveniently mounted on the top panel. With the optional added accessory of the SRCOOLNET, this
communication port allows users to monitor temperatures, receive alerts, review logs and control settings from
any location. Designed for quick and simple installation, the SRCOOL12K rolls into place on built-in casters and
plugs into a standard 5-15R outlet with no adapter required. An included window/drop ceiling kit provides multiple
installation options.
The SRCOOL12K uses environmentally friendly R410a refrigerant, which complies with EPA standards for 2010
and beyond, and is accepted worldwide. It contains zero, ozone depleting R22 refrigerant that has been banned
by the EPA for new equipment manufactured after January 1, 2010.
Features
1 / 4
Highlights
Compact, portable, self-contained
design reduces
maintenance—no water
collection tank or drain required
Rolls into place on built-in
casters; does not require an
external condenser, refrigerant
piping or hiring outside
contractors
Offers both hot-spot and general
room cooling with two
exchangeable vent styles
Filters and dehumidifies air to
protect equipment
Auto-restart feature retains all
system settings and returns unit
back to its last operational state
after AC power is restored
Allows users to remotely monitor
and control temperatures, alerts,
logs and settings from any
location with an Internet
connection (requires
SRCOOLNET accessory)
Applications
Supplemental cooling for confined
server rooms where the facility HVAC
is inadequate or unavailable.
Package Includes
SRCOOL12K cooling unit
Louvered front vent
Directional front vent
Cold Air directional delivery tube
Hot exhaust air removal tube
Dropped ceiling or window heat
ventilation kit
Warranty information
Instruction manual
