Chapter 1. About the dock

This chapter contains product description, connector and control locations, and system requirements for the
®
ThinkPad
Basic USB 3.0 Dock (hereafter called the dock).

Product description

The dock is a portable expansion module that enables you to easily connect your notebook computer to the
Ethernet and multiple devices, such as a headset, a microphone, and Universal Serial Bus (USB) devices.
The dock supports a Digital Visual Interface - Integrated (DVI-I) monitor with the maximum resolution of 1920
x 1200 pixels or a Video Graphics Array (VGA) monitor with the maximum resolution of 2048 x 1152 pixels.
The dock provides two USB 2.0 connectors and two USB 3.0 connectors for higher bandwidth and better
performance. The dock also supports Gigabit Ethernet speed when you connect it to networks.
You can set up your work area by connecting your notebook computer to the dock with the provided USB
3.0 cable, connecting multiple devices to the dock, and setting the dock on your notebook computer; then,
you are ready to use the multiple devices each time you connect your notebook computer to the dock.
Your option package includes the following:
• ThinkPad Basic USB 3.0 Dock
• Power adapter
• Power cord
• USB 3.0 cable
• DVI-I to VGA adapter
• Warranty poster
Contact your place of purchase if any item is missing or damaged. Be sure to retain your proof of purchase
and packing material. They might be required to receive warranty service.
© Copyright Lenovo 2013
1
