Summary of Contents for Invacare 6302G
- Page 1 ® Invacare Model 6302G ® Invacare Model 6302GADH Supine Whirlpool Tubs User Manual DEALER: This manual MUST be given to the user of the product. USER: BEFORE using this product, read this manual and save for future reference.
-
Page 2: Table Of Contents
Preparing the Work Area ..........................................14 Tub Dimensions and Connection Details ..................................... 15 Securing the Tub ..............................................16 Leveling the Tub..............................................16 Electrical Installation............................................17 Plumbing Connection Details........................................... 18 Plumbing Installation............................................18 Post Installation Checklist..........................................20 Invacare® Supine Whirlpool Tubs Part No. 1167456... - Page 3 Adjusting the Tub Height - 6302GADH Only ..................................... 28 INSPECTION, MAINTENANCE AND TROUBLESHOOTING ....................29 Safety Inspection Checklists ..........................................29 Maintenance for 6302GADH Adjustable Height Rub Panels and Glide Pads........................30 Troubleshooting..............................................30 Maintenance Record............................................31 Part No. 1167456 Invacare® Supine Whirlpool Tubs...
-
Page 4: General
Caution indicates a potentially hazardous situation which, if not avoided, may result in property damage or minor injury or both. IMPORTANT Indicates a hazardous situation that could result in damage to property if it is not avoided. Gives useful tips, recommendations and information for efficient, trouble-free use. Invacare® Supine Whirlpool Tubs Part No. 1167456... -
Page 5: Limited Warranty
This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare Continuing Care, Inc. (ICC1) warrants its bathing/whirlpool products to be free from defects in materials and workmanship for a period of three years from the date of purchase. -
Page 6: Safety
ACCESSORIES WARNING Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. NOTICE THE INFORMATION CONTAINED IN THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. - Page 7 Seek medical attention if symptoms or sickness persist. Check with the physician BEFORE using the tub again. Anyone under a doctor’s supervision, pregnant, or with poor health should check with a physician BEFORE using this tub. Part No. 1167456 Invacare® Supine Whirlpool Tubs...
-
Page 8: Overview
Features Tub Raise and Lower Buttons (Model 6302GADH ONLY) Water Temperature Thermometer Whirlpool ON/OFF Button Fill Button (Push-in once to auto-fill, push-in and hold to add additional water to tub) Water Temperature Control Invacare® Supine Whirlpool Tubs Part No. 1167456... - Page 9 3 OVERVIEW Shower/Massage ON/OFF Button Shower/Massage Wand Fill Spout Overflow Shower Spray Adjustment Whirlpool Jet Flow Control Valve Part No. 1167456 Invacare® Supine Whirlpool Tubs...
-
Page 10: Product Labeling
3 OVERVIEW Product Labeling Labels located inside the Service Access Door Label located on Interior Hardware Invacare® Supine Whirlpool Tubs Part No. 1167456... -
Page 11: Typical Product Parameters
49 inches (1245 mm) Water Capacity Maximum 103 gallons (390 liters) with Tub occupied (average usage) 70-77 gallons maximum (265 to 292 liters) Water Fill Rate 17 gallons per minute (65 liters per minute) Part No. 1167456 Invacare® Supine Whirlpool Tubs... - Page 12 Class I, Type B Power 115 VAC, 60 Hz Current Rating 7 Amps Tub Material: Double-wall gel coated fiberglass Thermometer: 2 inch dial, 75° to 120° F (25° - 50° C) Anti-Scald Water Regulator: Moen ExactTemp® Invacare® Supine Whirlpool Tubs Part No. 1167456...
-
Page 13: Minimum Floor Space And Clearance Requirements
3 OVERVIEW Minimum Floor Space and Clearance Requirements Part No. 1167456 Invacare® Supine Whirlpool Tubs... -
Page 14: Installation
Carefully remove the tub from the carton and inspect for shipping damage. If damage is found, contact the carrier. Remove the tub from the shipping pallet by removing the screws from the leg mounting pads. Invacare® Supine Whirlpool Tubs Part No. 1167456... -
Page 15: Tub Dimensions And Connection Details
2” Drain (floor drain recommended) 10.5” (267 mm) from centerline 115V AC, 60 Hz 15 A Input 6.5” (165 mm) from centerline, 5.5” (140 mm) up from floor 3/4” Hot water stub (with recommended shut off valve) Part No. 1167456 Invacare® Supine Whirlpool Tubs... -
Page 16: Securing The Tub
Repeat STEPS 1 and 2 until the tub is level. Secure the legs to the floor using fasteners appropriate to the floor material and in keeping with local codes. Invacare® Supine Whirlpool Tubs Part No. 1167456... -
Page 17: Electrical Installation
Use a 15 AMP GFCI breaker only. Ensure a 15 AMP GFCI breaker is installed to protect the unit. Insert the plug into a pre-installed GFCI protected hospital grade receptacle. Part No. 1167456 Invacare® Supine Whirlpool Tubs... -
Page 18: Plumbing Connection Details
Invacare recommends you check local plumbing code requirements to determine if RPZs are required on your tub installation. RPZs are NOT supplied by Invacare and are to be provided by the customer if required. - Page 19 Check for leaks in supply or drain lines and check operation of tub. Refer to Operation on page 21. In House Water Service COLD Optional Pressure Regulator Mixing Valve Tub Spout Shower Control Valve Tub Fill Valve Shower/Massage Wand Backflow Preventor (located inside tub cabinet) Part No. 1167456 Invacare® Supine Whirlpool Tubs...
-
Page 20: Post Installation Checklist
ICCI skin care and cleaning products have been ordered. To place your order, call 800-668-2337. ICCI representative has been called to arrange for an In-Service on the tub. To schedule, call 800-668-2337. Invacare® Supine Whirlpool Tubs Part No. 1167456... -
Page 21: Operation
NOT to be used with the Supine Tub. Use the Traverse Lift Model 1200 to maintain resident safety and product utility. Refer to the lift owner’s manual for complete life operating and safety instructions. Part No. 1167456 Invacare® Supine Whirlpool Tubs... - Page 22 5 OPERATION Tub Raise and Lower Buttons (Model 6302GADH ONLY) Water Temperature Thermometer Whirlpool ON/OFF Button Fill Button (Push-in once to auto-fill, push-in and hold to add additional water to tub) Water Temperature Control Invacare® Supine Whirlpool Tubs Part No. 1167456...
-
Page 23: Cleaning And Disinfecting
Methylene Blue. The use of these types of cleaners will cause the tub to stain. Use of unapproved cleaners will dry out the rubber seals and gaskets and the tub will not function properly. Use the drain plug to close the drain. Part No. 1167456 Invacare® Supine Whirlpool Tubs... - Page 24 Allow the Dispatch™ Cleaner and Disinfectant to sit on the surfaces for one minute. Rinse all surfaces and pieces of the jet assemblies with water. Use a clean towel to dry all tub surfaces and all pieces of the jet assemblies. Invacare® Supine Whirlpool Tubs Part No. 1167456...
- Page 25 Removing Soap Film and Hard Water Deposits Assembly Use a commercially available cleaner such as Invacare Heavy Duty Cleaner. Remove the jet assemblies. Remove the impeller caps. Thoroughly spray the exposed surfaces, including the jet casings. Use a long handled soft brush or...
-
Page 26: Water Temperature Setting
Flow Water Thermometer - measures the temperature of water coming from the tub fill spout or shower/massage wand. Water Temperature Control Valve - sets and maintains constant temperature for all incoming water. Flow Water Thermometer Hot (RED) Cold (Blue) Water Temperature Control Valve Invacare® Supine Whirlpool Tubs Part No. 1167456... -
Page 27: Filling The Tub
The use of the Flow Control permits the reduction of water flow without the need for readjustment of water temperature during bathing. A trickle of water through the Flow Control when in the closed position is normal. Part No. 1167456 Invacare® Supine Whirlpool Tubs... -
Page 28: Using The Whirlpool Function
If the water level does not cover the whirlpool jets, push the tub fill button to auto-fill the tub. After the water level covers the whirlpool jets and after bathing the resident, add Invacare Defoamer to the bath water. Refer to the Defoamer bottle for directions. -
Page 29: Inspection, Maintenance And Troubleshooting
Clean the Water Temperature Control Valve to remove lime deposits. Refer to Removing Calcium Deposits, Scale and Lime Build-up on page 25. 6302GADH ONLY - Apply white lithium grease to Glide Pads. Refer to Refer to Maintenance for 6302GADH Adjustable Height Rub Panels and Glide Pads on page 30. Part No. 1167456 Invacare® Supine Whirlpool Tubs... -
Page 30: Maintenance For 6302Gadh Adjustable Height Rub Panels And Glide Pads
Restricted water flow Water temperature control valve Inspect and clean the water temperature control valve. Refer to the Moen service manual at www.moen.com. Search for Model 3371 ExactTemp Temperature Control Valve, Service Manual Number 153768. Invacare® Supine Whirlpool Tubs Part No. 1167456... -
Page 31: Maintenance Record
Replace damaged parts as necessary per local codes. Actuator overload Wait five minutes and try to adjust the height again. Actuator burned out Contact your Invacare Dealer. Obstacle in UP/DOWN travel path Inspect for and remove any obstacle. Maintenance Record... - Page 32 Maple Industries, LLC, d.b.a. Sanijet. ExactTemp® is a registered trademark of Moen Incorporated. For more information regarding Invacare products, parts, and Part No. 1167456 Rev A - 06/10 services, please visit www.invacare-cc.com. Invacare Continuing Care, Inc. is a subsidiary of Invacare Corporation...
