Summary of Contents for Invacare TheraPure 3752G
- Page 1 ® Invacare TheraPure™ Recessed Whirlpool Tubs Model 3752G Model 3802G User Manual This manual MUST be given to the user of the product. BEFORE using this product, read this manual and save for future reference.
-
Page 2: Table Of Contents
Minimum Floor Space and Clearance Requirements.................................. 12 Dimensions................................................13 INSTALLATION Preparing the Work Area ..........................................15 Electrical and Plumbing Hook-up Locations ....................................16 Electrical Installation............................................17 Plumbing Installation............................................18 Post Installation Checklist..........................................19 Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458... - Page 3 Water Temperature Setting..........................................28 Filling the Tub ..............................................29 Using the Shower/Massage Wand........................................29 Using the Whirlpool Function ......................................... 30 INSPECTION AND TROUBLESHOOTING Safety Inspection Checklists ..........................................31 Troubleshooting..............................................32 Maintenance Record............................................33 Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs...
-
Page 4: General
Caution indicates a potentially hazardous situation which, if not avoided, may result in property damage or minor injury or both. IMPORTANT Indicates a hazardous situation that could result in damage to property if it is not avoided. Gives useful tips, recommendations and information for efficient, trouble-free use. Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458... -
Page 5: Limited Warranty
This warranty gives you specific legal rights and you may also have other legal rights which vary from state to state. Invacare Continuing Care, Inc. (ICC1) warrants its bathing/whirlpool products to be free from defects in materials and workmanship for a period of three years from the date of purchase. -
Page 6: Safety
- otherwise, injury or damage may occur. ACCESSORIES WARNING Invacare products are specifically designed and manufactured for use in conjunction with Invacare accessories. Accessories designed by other manufacturers have not been tested by Invacare and are not recommended for use with Invacare products. - Page 7 Seek medical attention if symptoms or sickness persist. Check with the physician BEFORE using the tub again. Anyone under a doctor’s supervision, pregnant, or with poor health should check with a physician BEFORE using this tub. Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs...
-
Page 8: Overview
(Push-in once to auto-fill, push-in and hold to add additional water to tub) Shower/Massage ON/OFF Button Shower/Massage Wand Flow Control Valve Shower Spray Adjustment Adjustment for angle of wand in cradle Service Access Door Door Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458... - Page 9 Tub Fill Spout Overflow (Push-in once to auto-fill, push-in and hold to add additional water to tub) Shower Spray Adjustment Adjustment for angle of Shower/Massage wand in cradle ON/OFF Button Service Access Door Door Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs...
-
Page 10: Product Labeling
3 OVERVIEW Product Labeling Labels located inside the Service Access Door Label located on Interior Hardware Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458... -
Page 11: Typical Product Parameters
115 VAC, 60 Hz Current Rating 7 Amps Number of Jet Outlets: Tub Material: Double-wall gel coated fiberglass Thermometer: 2 inch dial, 75° to 120° F (25° - 50° C) Anti-Scald Water Regulator: Moen ExactTemp® Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... -
Page 12: Minimum Floor Space And Clearance Requirements
3 OVERVIEW Minimum Floor Space and Clearance Requirements Models 3752G or 3802G 12’ 4’ 11-1/2” TUB LENGTH HOT AND COLD WATER STUBS, 115 VOLT PUMP HOOKUP THIS END 2’ 7-1/2” ALLOW FOR A 40” DOOR SWING 9’ 5” 36” Invacare® TheraPure™ Recessed Whirlpool Tubs... -
Page 13: Dimensions
3 OVERVIEW Dimensions Models 3752G or 3802G 59.5” 17” 27” 34” 41-1/2” 31” 36” 6-1/2” 18” 3/4” Cold water stub with recommended shut off valve 2” Drain (floor drain recommended) 5-1/2” 47” 115V AC, 60 Hz, 15 A Input 3/4” Hot water stub with recommended shut off valve Allow for 40”... -
Page 14: Installation
Use extreme care during installation. After installation and before use ensure all parts are properly and securely installed. Ensure the bathroom floor is dry and free of obstructions before transporting or assembling the unit. Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458... -
Page 15: Preparing The Work Area
Ensure the cleats do not interfere with any components of the tub or restrict the installation in any way. Install a service access panel (minimum 16 by 14-inches on the wall (the back wall or right wall) to allow the tub components to be serviced. Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... -
Page 16: Electrical And Plumbing Hook-Up Locations
4 INSTALLATION Electrical and Plumbing Hook-up Locations Refer to Electrical Installation on page 17 and Plumbing Installation on page 18. Model 3752G shown below. Front View Top View Model Model 3752G 3752G F G H LETTER DESCRIPTION 3752G AND 3802G... -
Page 17: Electrical Installation
Use a 15 AMP GFCI breaker only. Ensure a 15 AMP GFCI breaker is installed to protect the unit. Insert the plug into a pre-installed GFCI protected hospital grade receptacle. Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... -
Page 18: Plumbing Installation
Invacare recommends you check local plumbing code requirements to determine if RPZs are required on your tub installation. RPZs are NOT supplied by Invacare and are to be provided by the customer if required. -
Page 19: Post Installation Checklist
ICCI skin care and cleaning products have been ordered. To place your order, call 800-668-2337. ❑ ICCI representative has been called to arrange for an In-Service on the tub. To schedule, call 800-668-2337. Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... -
Page 20: Operating Instructions
Anyone under a doctor’s supervision, pregnant, or with poor health should check with a physician BEFORE using this tub. Fill Button Shower/Massage Wand Whirlpool ON/OFF Button (Push-in once to auto-fill, push-in Flow Control Valve Water Temperature Control Valve and hold to add additional water to tub) Shower/Massage ON/OFF Button Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458... -
Page 21: Cleaning And Disinfecting
Methylene Blue. The use of these types of cleaners will cause the tub to stain. Use of unapproved cleaners will dry out the rubber seals and gaskets and the tub will not function properly. Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... - Page 22 Use a clean towel to dry all tub surfaces and all pieces in the footwell of the tub. Allow the waist straps to air dry. WARNING DO NOT put the waist straps in the dryer, otherwise damage to the straps may occur. Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458...
- Page 23 Removing Soap Film and Hard Water Deposits Use a commercially available cleaner such as Invacare Heavy Duty Cleaner. Remove the jet assemblies. Remove the impeller caps. Thoroughly spray the exposed surfaces, including the jet casings. Use a long handled soft brush or similar product to wipe down all surfaces and allow the heavy duty cleaner to remain in contact with the exposed surfaces for approximately ten minutes.
- Page 24 12 hours. Rinse off surfaces using the shower wand, adjusted to the spray position. Use the cleaner according to the manufacturer's instructions. Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458...
-
Page 25: Opening/Closing The Tub Door
Push down on the door handle to lock the door into position. Lift the door handle to ensure the safety pin has engaged the door properly. If the door handle lifts, repeat STEPS 1-3. Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... - Page 26 5 OPERATING INSTRUCTIONS Door Handle Safety Pin Door Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458...
-
Page 27: Waist Strap
Bring both ends of the waist strap around the resident. Secure the ends together with the plastic clasp. Adjust the straps for comfort as necessary. Strap attachment point Strap Attachment Waist Strap shown in place Point (attached to tub shell in two places) Tub Shell Strap Lead Plastic clasp Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... -
Page 28: Water Temperature Setting
Flow Water Thermometer - measures the temperature of water coming from the tub fill spout or shower/massage wand. Water Temperature Control Valve - sets and maintains constant temperature for all incoming water. Flow Water Thermometer Water Temperature Control Valve Cold (Blue) Hot (RED) Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458... -
Page 29: Filling The Tub
Adjust the flow of the water by turning the flow control. Adjust the shower spray by rotating the shower wand head. Turn the shower/massage off by pressing the ON/OFF button again. Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... -
Page 30: Using The Whirlpool Function
If the water level does not cover the whirlpool jets, push the tub fill button to auto-fill the tub. After the water level covers the whirlpool jets and after bathing the resident, add Invacare Defoamer to the bath water. Refer to the Defoamer bottle for directions. -
Page 31: Inspection And Troubleshooting
Verify the water flow temperature with a separate thermometer. ❑ Check that all labels are present and legible. Replace if necessary. ❑ Clean the Water Temperature Control Valve to remove lime deposit. Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... -
Page 32: Troubleshooting
Water temperature control valve Inspect and clean the water temperature control valve. Refer to the Moen service manual at www.moen.com. Search for Model 3371 ExactTemp Temperature Control Valve, Service Manual Number 153768. Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458... -
Page 33: Maintenance Record
6 INSPECTION AND TROUBLESHOOTING Maintenance Record DATE MAINTENANCE PERSON TYPE OF MAINTENANCE PERFORMED NOTES Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs... - Page 34 NOTES Notes Invacare® TheraPure™ Recessed Whirlpool Tubs Part No. 1167458...
- Page 35 NOTES Notes Part No. 1167458 Invacare® TheraPure™ Recessed Whirlpool Tubs...
- Page 36 ExactTemp is a registered trademark of Moen Incorporated. Betadine is a registered trademark of Purdue Pharma LP. For more information regarding Invacare products, parts, and Part No. 1167458 Rev C - 12/11 services, please visit www.invacare-cc.com. Invacare Continuing Care, Inc. is a subsidiary of Invacare Corporation...
