  • Page 1 OWNER’S MANUAL Installation & Operating Instructions WHIRLPOOL BATH J-DREAM 90 Shower System Right Hand & Left Hand Models...

  • Page 2: Dimensions In Inches

    J-DREAM 90 (LEFT HAND SHOWN) DIMENSIONS IN INCHES...

  • Page 3: Important Safety Information

    READ ALL INSTALLATION INSTRUCTIONS Jacuzzi Whirlpool Bath does not recommend prolonged periods of use of the steamer. Prolonged use of the steam system can raise the internal human body temperature excessively and impair the body's ability to regulate its internal temperature (resulting in hyperthermia).

  • Page 4: Electrical Requirements

    Providing natural or forced ventilation of the room will help maintain comfort and minimize moisture damage to the building. Jacuzzi Whirlpool Bath is not responsible for damages resulting from excess moisture or water spillage. Consult an architect or engineer for aid in designing your installation.

  • Page 5: Options Available

    Providing natural or forced ventilation of the room will help maintain comfort and minimize moisture damage to the building. Jacuzzi Whirlpool Bath is not responsible for damages resulting from excess moisture or water spillage. Consult an architect or engineer for aid in designing your interior structure. Do not install heat lamps directly above shower unit. The clear top will deform from excess heat.
  • Page 6 Installation & Operating Instructions (Left Hand Model) 16" WASHING BOILER MACHINE DRAIN OUTLET BOX VALVES (2) CONNECT #8 GAUGE (10mm 2 ) 1/2 " HOT MINIMUM SOLID COPPER BOND & COLD WIRE TO THE HOUSE WATER ELECTRICAL PANEL OR SUPPLY APPROVED LOCAL GROUND.
  • Page 7 Installation & Operating Instructions (Right Hand Model) 16" WASHING BOILER MACHINE DRAIN OUTLET BOX VALVES (2) CONNECT #8 GAUGE (10mm 2 ) 1/2 " HOT & COLD MINIMUM SOLID COPPER BOND WATER WIRE TO THE HOUSE SUPPLY ELECTRICAL PANEL OR APPROVED LOCAL GROUND.

  • Page 8: Power Cord With Plug

    Installation & Operating Instructions Bonding CONNECT #8 GAUGE (10mm 2 ) MINIMUM SOLID COPPER BOND WIRE TO THE HOUSE ELECTRICAL PANEL OR APPROVED LOCAL GROUND. APPROVED GROUND MAY BE AN 8 FOOT LONG GROUND ROD (3 METER LONG EARTH ROD), A PLATE ELECTRODE, OR OTHER ACCEPTABLE BOND...
  • Page 9 Completing the Installation for J-Dream 90 • Connect hot and cold water supply hoses. • Plug in electric line cord. • Move J-90 into final position. • Install drain, connect to stub-out using band seal coupling provided. • Adjust the leveling screws in the base frame feet and lock them into position.
  • Page 10 Operating Instuctions for J-Dream 90 System control is provided by the electronic display located inside the shower cabin (see Fig. 2) The display is used to start up the four functions of the unit: the shower, the cascade, the hydromassage and the steam bath.

  • Page 11: Starting The Hydromassage

    Starting the Hydromassage The J-Dream II allows you to enjoy the benefits of a real hydromassage. The hydromassage is created by the combined action of 16 water jets (four sets of four) under the pressure of an electrically powered pump. The action of each group of four jets is alternated according to a programmed sequence which can be changed as desired.

  • Page 12: Ordinary Maintenance Operations

    (Figure 2) reading (--). In case of power failure while the J-Dream 90 is operating, any function will be completely cancelled. When power is restored, the self test will activate and any desired function can be reset at this time.

  • Page 13: Electrical Diagram

    Electrical Diagram NOTE: Double -pole cable -Nylon terminals are used. 0,75 mm H 0,5 - Length of cable refers (length = 3100 mm) to distance from press with fast terminals connectors (*) of electronic box. (12V) ELECTRICAL DIAGRAM Sol. valve, drainage Sol.
  • Page 14 USE INSTALLATION INSTRUCTIONS SUPPLIED WITH PRODUCT. Jacuzzi Whirlpool Bath has obtained applicable code (standards) listings generally available on a national basis for products of this type. It is the responsibility of the installer/owner to determine specific local code compliance prior to installation of this product. Jacuzzi Whirlpool Bath makes no representation or warranty regarding, and will not be responsible for any code compliance.
