Summary of Contents for Honda HARMONY HRM215K2SDA
- Page 2 The information and specifications included in this publication were in effect at the time of approval for printing. Honda Power Equipment Mfg., Inc. reserves the right, however, to discontinue or change specifications or design at any time without notice and without incurring any obligation whatever..
- Page 3 Congratulations on your selection of a Honda lawn mower! We are certain you will be pleased with your purchase of one of the finest lawn mowers on the market. We want to help you get the best results from your new mower and to operate it safely.
-
Page 4: A Few Words About Safety
Of course, it is not practical or possible to warn you about all the hazards associated with operating or maintaining a lawn mower. You must use your own good judgment. You will find important safety information in a variety of forms, including: - on the lawn mower. -
Page 5: Table Of Contents
Turn to the beginning of each chapter for a complete list of subjects. MOWER SAFETY ....... . . Important information about some specific hazards, and what you can do to prevent injury. -
Page 7: Mower Safety
This chapter explains what you need to know to operate your mower safely. IMPORTANT SAFETY INFORMATION Avoid Rotating Blades ... Clear Mowing Area ... Keep Shields in Place ... Refuel with Care..Wear Protective Clothing..Turn Engine,Off When Not Mowing..IMPORTANT MESSAGE TO PARENTS SAFETY LABEL LOCATIONS. -
Page 8: Important Safety Information
MOWER SAFETY IMPORTANT SAFETY INFORMATION Most accidents with walk-behind mowers can be prevented if you follow all instructions in this manual and on the mower. The most common hazards, according to accident statistics, are discussed below, along with the best way to protect yourself and others. Avoid Rotating Blades Rotating blades can cause serious cuts and even amputate fingers, hands, toes, or feet. -
Page 9: Important Message To Parents
YOUR CHILDREN’S SAFETY IS VERY IMPORTANT to Honda. That’s why we urge you to read this message before letting your youngster operate this lawn mower. Lawn mowers are tools, not toys. As with any equipment, bad judgments can result in serious injuries. -
Page 10: Safety Label Locations
MOWER SAFETY SAFETY LABEL LOCATIONS The labels shown here contain important safety information. Please read them carefully. These labels are considered permanent parts of your mower. So if a label comes off or becomes hard to read, contact an authorized Honda dealer for a replacement. (HRB215) UNDER NORMAL... -
Page 11: Controls
This chapter shows the locations of controls and other important parts of your mower, and it tells you how the controls work. COMPONENT IDENTIFICATION DESCRIPTION FuelValve ... Throttle Lever..Flywheel Brake Lever ... Drive Clutch Lever (SDA)..Shift Lever (SDA) Cutting Height Adjustment Levers. -
Page 12: Component Identification
CONTROLS COMPONENT lDENTlFlCATlOlN HANDLEBAR RECOIL STARTER GRIP GRASS BAG ?i.s@A\ REAR CUlTlNG HEIGHT ADJUSTMENT LEVER OIL FILLER CAP HRB215K2PDA: Manually propelled, high-lift blade, and grass bag. HRB215K2SDA: Self-propelled, high-lift blade, and grass bag. HRM215K2PDA: Manually propelled, mulching blades, and mulching plug. HRM215K2SDA: Self-propelled, mulching blades, and mulching plug. - Page 13 ENGINE SERIAL NUMBER (on back of engine) FRONT CUTrING HEIGHT ADJUSTMENT LEVERS Record the frame and engine serial numbers in the space below. You will need these serial numbers when ordering parts and when making technical or warranty inquiries (see page 77). Frame serial number: Engine serial number: SHIFT LEVER...
-
Page 14: Description Of Controls
CONTROLS DESCRIPTION OF CONTROLS Fuel Valve The fuel valve opens and closes the fuel passage from the fuel tank to the carburetor. Throttle Lever CHOKE -- FAST --- SLOW--- For starting a cold engine. For restarting a warm engine and for mowing. For idling the engine. -
Page 15: Flywheel Brake Lever
Flywheel Brake Lever This lever is connected to the engine flywheel brake and the ignition switch. The engine will not start unless this lever is pulled back. Drive Clutch Lever (WA) The drive clutch lever engages and disengages the transmission that drives the rear wheels. -
Page 16: Shift Lever (Sda)
CONTROLS Shift Lever (SDA) The shift lever selects and controls the mower’s drive speed. 1 (SLOW) - For mowing thick grass or maneuvering in small areas. 2 (FAST)- For maximum self-propelled speed in large, open areas, and for transport. Cutting Height Adjustment There are six settings to choose from, as shown in the illustration. -
Page 17: Before Operation
This chapter explains how to fuel and check your mower to be sure it is ready, and it tells you how to prepare your lawn and yourself before you begin mowing. ARE YOU READY TO MOW? ... CHECK YOUR LAWN ... Objects ... -
Page 18: Are You Ready To Mow
BEFORE OPERATUON ARE YOU READY TO MOW? Be sure to wear protective clothing. Long pants and eye protection can lower your risk of injury from thrown objects. Wear footwear that protects your feet and won’t let you slip if you mow on slopes or uneven ground. -
Page 19: Before Operation
A worn or damaged blade can break, causing blade pieces to be thrown from the mower. When a blade needs sharpening or replacement take the lawn mower to an authorized Honda servicing dealer. .Or, if you have a torque wrench, you can remove and install the blade(s) yourself (see pages 56 - 57). -
Page 20: Engine Oil Level
BEFORE OPEWATlON Engine Oil Level Check the engine oil level with the engine stopped and the mower on a level surface. 1. Remove the oil filler cap, and wipe the dipstick clean. 2. Insert and remove the dipstick without screwing it into the filler neck. -
Page 21: Fuel
Fuel Fuel tank capacity: 0.26 US gal (1.0 P) Refuel in a well-ventilated area before starting the engine. If the engine has been running, allow it to cool. Refer to page 51 for fuel recommendations and page 78 for information about oxygenated fuels. -
Page 22: Air Cleaner Inspection
BEFORE OPERATION Air Cleaner Inspection Check that the air filters are clean and in good condition. Dirty air filters will restrict air flow to the carburetor, reducing engine performance. Refer to page 47 for air cleaner service. AIR CLEANER HOUSING PAPER FILTER COVER KNOB... -
Page 23: Handlebar Height Adjustment
BEFORE OPERATION Handlebar Height Adjustment Adjust handlebar height for a comfortable operating position. 1. Loosen the handlebar locking knobs. 2. Spread the lower ends of the handlebars to rel,ease the locating pins. 3. Move the handlebar up or down, so the locating pins engage the other holes on the handlebar mounting brackets. -
Page 24: Grass Bag (Hrb215)
BEFORE OPERATION Grass Bag (HRB215) A lawn mower works like a vacuum cleaner; it blows air through the bag, which traps the grass clippings. Always empty the grass bag before it becomes filled to the limit of its capacity. Bagging performance will diminish after the bag becomes about 90% filled. -
Page 25: Mulching Plug (Hrm215)
Mulching Plug (HRM215) The mulching plug contours the mower deck for efficient mulching. You can quickly remove the plug to install a grass bag or side-discharge chute, which are available as optional equipment. Raise the discharge guard to remove or install the mulching plug. -
Page 27: Operation
This chapter tells you how to operate the mower safely and effectively. MOWING PRECAUTIONS STARTING THE ENGINE ... OPERATING THE CONTROLS FOR MOWING ThrottleLever ... Flywheel Brake Lever ... Drive Clutch Lever (SDA)..Shift Lever (SDA) STOPPING THE ENGINE ... SAFE MOWING PRACTICES ... -
Page 28: Mowing Precautions
OPERATION MOWING PRECAUTIONS Before operating the mower for the first time, please review the IMPORTANT SAFETY INFORMATION previous chapter, titled Even if you have operated other mowers, take time to become familiar with how this mower works and practice in a safe area until you build up your skills. -
Page 29: Starting The Engine
STARTING THE ENGINE The blade turns when you operate the starter. It is easiest to start the engine in a clear or mowed area where the blade can turn freely. 1. Turn the fuel valve to the ON position. 2. Move the throttle lever to the proper starting position. COLD ENGINE: Move the throttle lever to the CHOKE position. - Page 30 OPERATION 4. Pull back on the flywheel brake lever and hold it against the handlebar. 5. Pull the starter grip lightly until you feel resistance, then pull briskly. Return the starter grip gently. Keep your hands and feet away from the mower deck at all times when starting and running the engine.
-
Page 31: Operating The Controls For Mowing
OPERATING THE CONTROLS FOR MOWING Throttle Lever For best cut quality, always mow with the throttle lever in the FAST position. When the blade(s) rotates at the preset fast speed, it creates a strong fan action that lifts and cuts grass more efficiently. -
Page 32: Drive Clutch Lever (Sda)
OPERATION Drive Clutch Lever (SDA) Pull the drive clutch lever up to propel the mower forward. Release the drive clutch lever to stop the mower’s forward movement. Always release the drive clutch lever before starting the engine. If the drive clutch is engaged, the mower will move forward when you operate the starter. -
Page 33: Stopping The Engine
OPERATION STOPPING THE ENGINE 1. Move the throttle lever to the SLOW position. THROTTLE LEVER 2. Release the flywheel brake lever and the drive clutch lever (SDA). DRIVE CLUTCH LEVER FLYWHEEL BRAK LEVER 3. When the mower is not in use, turn the fuel valve to the OFF position. -
Page 34: Safe Mowing Practices
OPERATION SAFE MOWING PRACTICES For your safety, keep all four wheels on the ground, and be careful to avoid losing your footing and your’ control of the mower. Keep a firm grip on the handlebar, and walk, never run, with the mower. Be very careful when mowing uneven or rough ground. -
Page 35: Obstacles
Obstacles Use the side of the mower to cut close to large obstacles, such as fences or walls. Release the drive clutch lever to disengage the drive when mowing around trees and other obstacles. Push the mower around obstacles for better directional control. Be careful when mowing over obstacles embedded in the lawn, such as sprinkler heads, paving, edging, etc. -
Page 36: Mowingtips
OPERATION MOWING TIPS When to Mow Most grasses should be mowed when they have grown l/z to 1 inch above their recommended height. More frequent mowing is required for mulching than for bagging. For best results, you may need to mow the lawn twice a week during the growing season. -
Page 37: Bladespeed
Blade Speed The blade must spin very fast to cut properly. Always use the FAST throttle setting, and keep the engine running at maximum rpm. If engine speed drops, it could mean the engine is being overloaded by the blade trying to cut too much grass. Mow a narrower swath, move the mower slower, or raise the cutting height. -
Page 38: Mowing Patterns
OPERATION Mowing Patterns Your Honda mower will work most efficiently if you use the following mowing patterns as much as possible. Mower deck and equipment design, and the direction in which the blade rotates, cause these mowing patterns to give the best results. Mulching (HRB215 requires optional mulching kit) -
Page 39: How To Load And Carry Your Mower Safely
TRANSPORTING This chapter explains how to load and carry your mower safely. BEFORE LOADING ......LOADING AND UNLOADING. -
Page 40: Before Loading
BEFORE LOADING If the engine has been running, allow it to cool for at least 15 minutes before loading the mower on the transport vehicle. A hot engine and exhaust system can burn you and can ignite some materials. Turn the fuel valve to the OFF position. This will prevent carburetor flooding and reduce the possibility of fuel leakage. -
Page 41: When And How To Perform Routine Inspection, Service
This chapter explains when and how to perform routine inspection, service, and adjustments for do-it-yourself maintenance. More difficult maintenance tasks should be done by your dealer. Your dealer is best equipped and staffed to provide the level of service and safety you and your mower deserve. -
Page 42: The Importance Of Maintenance
MAINTENANCE THE IMPORTANCE OF MAINTENANCE Good maintenance is essential for safe, economical, and trouble-free operation. It will also help reduce <sir pollution. Improper maintenance, or failure to correct a problem before operation, can cause a malfunction in which you can be seriously hurt or killed. -
Page 43: Maintenance Safety
MAINTENANCE SAFETY Some of the most important safety precautions follow. However, we cannot warn you of every conceivable hazard that can arise in performing maintenance. Only you can decide whether or not you should perform a given task. Failure to properly follow maintenance instructions and precautions can cause you to be seriously hurt or killed. -
Page 44: Emission Control System Information
MAINTENANCE EMISSION CONTROL Source of Emissions The combustion process produces carbon monoxide, oxides of nitrogen, and hydrocarbons. Control of hydrocarbons and oxides of nitrogen is very important because, under certain conditions, they react to form photochemical smog when subjected to sunlight. Carbon monoxide does not react in the same way, but it is toxic. -
Page 45: Replacement Parts
Replacement Parts The emission control systems on your new Honda engine were designed, built, and certified to conform with EPA and California emission regulations. We recommend the use of genuine Honda parts whenever you have maintenance done. These original-design replacement parts are manufactured to the same standards as the original parts, so you can be confident of their performance. -
Page 46: Maintenance Schedule
MAINTENANCE MAINTENANCE SCHEDULE REGULAR Perform at every indicated interval Blade condition and blade bolt tightness Grass bag (HRB215) Check Engine oil zz+-l-%--I- Air Cleaner zfz--H+ J--j-+ (optional equipment) ‘lean Idle speed Flywheel brake cable Flywheel brake pad Drive clutch (SDA) cable 1 Shift cable (SDA) 1 Throttle cable... -
Page 47: Engine Maintenance
ENGINE MAINTENANCE Engine Oil Change Drain the used oil while the engine is warm. Warm oil drains quickly and completely. 1. Turn the fuel valve to the OFF position to reduce the possibility of fuel leakage (see page 31). 2. Wipe the oil filler area clean, then remove the oil filler cap/dipstick. 3. - Page 48 MAINTENANCE Using nondetergent oil can shclrten the engine’s service life, and using 2-stroke oil can damage .the engine. SAE 1 OW-30 is recommended for general use. Other viscosities shown in the chart (previous page) may be used when the average temperature in your area is within the indicated range.
-
Page 49: Air Cleaner Service
Air Cleaner Service Dirty air filters will restrict air flow to the carburetor, reducing engine performance. If you operate the mower in very dusty areas, clean the air filters more often than specified in the MAINTENANCE SCHEDULE. 1 NOTICE Operating the engine without air filters, or with damaged filters, will allow dirt to enter the engine, causing rapid engine wear. -
Page 50: Spark Plugservice
MAINTENANCE 5. Wipe dirt from the inside of the air cleaner housing and cover, using a moist rag. Be careful to prevent dirt from entering the air duct that leads to the carburetor. 6. Reinstall the filters and cover. Tighten the cover screw securely. Spark PlugService RECOMMENDED SPARK PLUGS DENS0... - Page 51 2. Remove the spark plug with a 13/j6 in (21 mm) spark plug wrench. 3. Inspect the spark plug. Replace it if the electrodes are worn, or if the insulator is cracked or chipped. Clean the spark plug with a wire brush if you are going to reuse it.
-
Page 52: Carburetor Adjustment
MAINTENANCE Carburetor Adjustment 1. Start the engine outdoors, and allow it to warm up to normal operating temperature. Set the throttle lever in the SLOW position. Turn the throttle stop screw to obtain the standard idle speed. Standard idle speed: 2,100 +150 rpm Carburetor Modification... -
Page 53: Fuelrecommendations
Fuel Recommendations Use unleaded gasoline with a pump octane rating of 86 or higher. This engine is certified to operate on unleaded gasoline. Unleaded gasoline produces fewer engine and spark plug deposits and extends exhaust system life. Never use stale or contaminated gasoline or an oil/gasoline mixture. Avoid getting dirt or water in the fuel tank. -
Page 54: Control Cable Adjustments
MAINTENANCE CONTROL CABLE ADJUSTMENTS Flywheel Brake Cable Adjustment Measure free play at the top of the lever. Free play should be 3/1s-g/1s in (5-l 5 mm). If adjustment is necessary: 1. Loosen the lock nuts with a 10 mm wrench, and move the adjuster up or down as required. -
Page 55: Drive Clutch Cable Adjustment (Sda)
Drive Clutch Cable Adjustment Measure free play at the top of the lever, as shown. Free play should be l/l6 - 3/16 in (1 - 4 mm). If adjustment is necessary: 1. Loosen the lock nuts with a 10 mm wrench, and move the adjuster up or down as required. -
Page 56: Shift Cable Adjustment (Sda)
MAINTENANCE Shift Cable, Adjustment Shift cable adjustment is necessary if the shift lever does not operate smoothly or does not shift properly into a gear. With the transmission in 1st gear, pull the shift lever all the way back and release it; the lever should be approximately centered on the number “1”... -
Page 57: Throitle Cable Inspection
THROTTLE CABLE INSPECTION Throttle cable adjustment is necessary if the throttle lever does not operate the choke properly. You can inspect choke operation by observing the movement of the choke arm, which is located on top of the carburetor. 1. Move the throttle lever to the CHOKE position. -
Page 58: Blade Removal And Installation
MAINTENANCE BLADE REMOVAL AND INSTALLATION If you remove the blade(s) for sharpening or replacement, you will need a torque wrench for installation. Wear heavy gloves to protect your hands. BLADE SHARPENING: To avoid weakening the blade(s), or causing imbalance or poor cutting, the blade(s) should be sharpened by trained staff at an authorized Honda servicing dealer. -
Page 59: Blade Installation
Blade Installation 1. Clean dirt and grass from around the blade mounting area. 2. Install the blade(s) using the two blade bolts and special washers as shown. Be sure to install the special washers with the concave side toward the blade(s) and the convex side (marked OUT) toward the bolt heads. The blade bolts and special washers are specially designed for this application. -
Page 60: Grass Bag Cleaning A&D Replacement (Hrb215)
MAINTENANCE GRASS BAG CLEANING AND REPLACEMENT (HRB215) Grass Bag Cleaning Wash the bag with a garden hose, and allow it to dry completely before use; a wet bag will clog quickly. Grass Bag Replacement Replace a worn or damaged bag with a Honda replacement bag or its equivalent. -
Page 61: What To Check If You Have A Problem With Your Mower
TROUBLESHOOTING This chapter shows what to check if you have a problem with your mower. ENGINE PROBLEMS Engine will not start ... Lossofpower ... VIBRATION PROBLEMS MOWING AND BAGGING PROBLEMS. -
Page 62: Troubleshoouing
TROUBLESHOOUING ENGINE PROBLEMS Engine Will Not Start 1. Check control positions. 2. Check fuel. 3. Remove and inspect spark plug. 4. Take mower to an authorized Honda servicing dealer, or refer to shop manual. Loss of Power 1. Check throttle position. 2. -
Page 63: Mowing And Bagging Problems
VIBRATION PROBLEMS Excessive Vibration 1. Check mower deck and blade(s). 2. Take mower to an authorized Honda servicing dealer for repair. MOWING AND BAGGING PROBLEMS Poor Cut Quality or Poor Mowing/Bagging Performance 1. Check that the throttle lever is in the FAST position. -
Page 65: Storage
This chapter explains how to protect your mower from rust and corrosion, and ensure that it will start easily when you want to use it again. STORAGE PREPARATION Cleaning ... Engine.. MowerDeck ... Grass Bag (HRB215)..Fuel ... Adding fuel stabilizer to extend fuel storage life ... Draining the Fuel Tank and Carburetor. -
Page 66: Storage Preparation
Cleaning Wash the lawn mower, including the underside of the mower deck. Engine Wash the engine by hand, and be careful to prevent water from entering the air cleaner. - Page 67 4. Stop the engine and allow it to cool. 5. After the lawn mower is clean and dry, touch up any damaged paint, and coat other areas that may rust with a light film of oil.
-
Page 68: Fuel
STORAGE Fuel Gasoline will oxidize and deteriorate in storage. Old gasoline will cause hard starting, and it leaves gum deposits that clog the fuel system. If the gasoline in your mower deteriorates during storage, you may need to have the carburetor and other fuel system components, serviced or replaced. -
Page 69: Draining The Fuel Tank And Carburetor
Draining the Fuel Tank and Carburetor 1. Remove the carburetor drain bolt with a 10 mm.wrench, and drain the carburetor bowl fuel into an approved container. Gasoline is highly flammable and explosive. You can be burned or seriously injured when handling fuel. -
Page 70: Engine Cylinder
STORAGE Engine Cylinder Remove the spark plug (see page 49). Pour a tablespoon (5 - 10 cc) of clean engine oil into the cylinder. Pull the starter rope several times to distribute the oil in the cylinder. Reinstall the spark plug. Pull the starter rope slowly until resistance is felt then return the starter grip gently. -
Page 71: Handlebar Folding
Handlebar Folding The handlebar can be folded for storage or transport by loosening the handlebar locking knobs. 1. Remove the grass bag, if so equipped. You can place it on top of the engine, with the bag opening to the front. 2. -
Page 72: Placing In Storage
STORAGE PLACING IN STORAGE If your mower will be stored with gasoline in the fuel tank and carburetor, it is important to reduce the hazard of gasoline vapor ignition. Select a well-ventilated storage area away from any appliance that operates with a flame, such as a furnace, water heater, or clothes dryer. - Page 73 This chapter gives dimensions, capacities, and other technical information. MOWER MODELS DIMENSIONS, WEIGHTS, AND CAPACITIES ENGINE DESIGN AND PERFORMANCE TRANSMISSION MAINTENANCE TUNEUP ‘....... DESIGN AND PERFORMANCE...
-
Page 74: Mower Models
SPECIFICATIONS MOWER MODELS HRB215K2PDA: Manually propelled, high-lift blade and grass bag HRB215K2SDA: Self-propelled, high-lift blade and grass bag HRM215K2PDA: Manually propelled, mulching blades and mulching plug HRM215K2SDA: Self-propelled, mulching blades and mulching plug DIMENSIONS, WEIGHTS, AND CAPACITIES Maximum Length (handlebar extended) Minimum Length (handlebar folded) Width at Mower Deck... -
Page 75: Specifications
ENGINE DESIGN AND PERFORMANCE Engine Model Engine Type Displacement Bore and Stroke Ignition System Maximum Horsepower Maximum Torque TRANSMISSION DESIGN AND PERFORMANCE I Transmission Type Mower Ground Speed (with engine at 3,300 ram) GXVl40Kl 4-stroke, overhead-valve, single cylinder, forced air-cooled 6.2 cu in (135 cc) 2.52 x 1.65 in (64 x 42 mm) 5.0 bhp (3.7 kW) at 3,600 rpm... -
Page 76: Maintenance
SPECIFICATIONS MAINTENANCE Fuel Engine Oil Transmission Oil (SDA) Spark Plug Type Maximum Governed Speed Flywheel Brake Cable Drive Clutch Cable (SDA) Shift Cable (SDA) Throttle Cable Blade Bolt Torque TUNEUP Spark Plug Gap Idle Speed Valve Clearance (cold) Other Specifications Unleaded gasoline with a pump octane rating of 86 or higher SAE low’-30, API SF, SG, or... -
Page 77: Additional Information, Honda Publications Available To
ADDITIONAL This chapter contains additional information, Honda publications available to you, and tells you how to contact us if you have a question or a warranty repair problem. HONDA PUBLICATIONS ShopManual... Parts Catalog ........WARRANTY SERVICE INFORMATION OXYGENATED... -
Page 78: Honda Publications
HONDA PUBLICATIONS These publications will give you additional information for maintaining and repairing your mower. You may order them from your Honda lawn mower dealer. Shop Manual This manual covers complete maintenance and overhaul procedures. It is intended to be used by a skilled technician. -
Page 79: Warranty Service Information
WARRANTY SERVICE INFORMATION Honda Power Equipment dealership personnel are trained professionals. They should be able to answer any question you may have. If you encounter a problem that your dealer does not solve to your satisfaction, please discuss it with the dealership’s management. - Page 80 When you write or call, please provide the following information: • Model and serial numbers • Name of the dealer who sold the Honda power equipment to you • Name and address of the dealer who services your equipment •...
-
Page 81: Additional Information
ADDITIONAL INFORMAT’ION OXYGENATED FUELS Some conventional gasolines are being blended with alcohol or an ether compound. These gasolines are collectively referred to as oxygenated fuels. To meet clean air standards, some areas of the United States and Canada use oxygenated fuels to help reduce emissions. -
Page 82: Spark Arrester Service (Optional Equipment)
SPARK ARRESTER SERVICE (optional equipment) Your lawn mower engine is not factory-equipped with a spark arrester. In some areas, it is illegal to operate an engine without a spark arrester. Check local laws and regulations. An optional USDA approved spark arrester is available from an authorized Honda servicing dealer. -
Page 84: Index
Air Cleaner Inspection..20 Air Cleaner Service..47 Blade(s): Inspection ......17 Installation . - Page 85 INDEX Handlebar Height Adjustment.21 Handlebar Folding..69 High Altitude Operation..50 Inspection Before Mowing: Lawn..16 Mower..17 Introduction ... 1 Lawn: Inspection Before Mowing .16 Mowing Tips..34 Safe Mowing Practices.. Leaves; Bagging ..35 Maintenance: Blade Removal and Installation ...
- Page 86 Transmission Design and Performance ....73 Tuneup ....... 74 Weights .
-
Page 87: Quick Reference Information
QUICK REFERENCE Type Fuel Capacity Engine Oil Capacity Type Spark Plug Blade bolts Torque Idle speed Carburetor Before each Maintenance First 20 hours Subsequent INFORMATION Unleaded gasoline with pump octane rating of 86 or higher (page 51). 0.26 US gallons (1 .O 0) SAE 1 OW-30, API SF, SG, or equivalent (page 45) 0.63 US quarts (0.6 4) Regular: NGK - BP5ES...
