- Page 1 Optica HD Dome Network Camera Installation Guide Indoor/Outdoor Ver. 1.3...
-
Page 2: Table Of Contents
Table of Contents 1. Indoor Camera Installation ..................... 3 1.1 Hard Ceiling ........................3 2. Outdoor Camera Installation with Sunshield Housing & Pendant Mount ....... 13 2.1 Standard/Compact Pendant Mounting ................ 13 3. Cable Gland Installation ....................... 18 ... -
Page 3: Indoor Camera Installation
Indoor Camera Installation Hard Ceiling The Dome IP Camera can be installed directly on a wall or ceiling. Please note that the wall or ceiling must have enough strength to support the IP Dome Camera. Items Needed: Vandal Proof/Indoor Dome IP Camera Ethernet Cable DC Jack Cable (supplied;... - Page 4 Follow the steps below to install the IP Dome Camera: Step 1: Unpack the Vandal Proof/ Indoor Dome IP Camera package and take out the IP Dome Camera. Step 2: Release the 2 captive Security Screws with the supplied Security Torx and open the Dome Cover.
- Page 5 Step 3: Press both sides of the Inner Cover and remove it from the Camera Module. Step 4: Unscrew the Module-fastened Screw, as indicated in the figure, with the screw driver.
- Page 6 Step 5: Press the sides of the Snap-on Camera Module, as indicated in the figure, and detach from Dome Camera’s Housing/ Plate. Step 6: Mark the positions of the four screw holes on the base of the Dome Camera at the chosen installation location.
- Page 7 Step 7: In the marked locations, drill each hole slightly smaller than the supplied Screw Anchors. Step 8: Put supplied Anchors into these drilled holes. Step 9: Fasten the Dome Camera’s Housing/ Plate with the four supplied Self-tapping Screws. NOTE: Be sure to fix the Self- tapping Screws with the Rubber Washers.
- Page 8 Connect the Cable(s) to the Unit Connect the ports (on the Camera Module) with their cables/wires respectively, as shown in the figures. Step 11: Vandal Proof Attach the Snap-on Camera Module into/ on the Dome Camera Housing/ Plate, and screw the Module-fastened Screw tightly with the screw driver to secure the Camera Module.
- Page 9 Step 12: Connect the power and network outputs. NOTE: The Power Cable is omitted if using PoE. STEP 13: Access the Camera Browser-viewer for viewing images. Please refer to User’s Manual for further details. Users can also use the Camera’s BNC Connector for video output while choosing BNC as one streaming in advance.
- Page 10 Adjust the Zoom Ring Screw to set the desired zoom; subsequently, modifying the Focus Ring Screw to set the desired focal length. Step 15: Adjust the Camera’s Pan/Tilt holder to a desired angle, as shown below. Pan adjustment range is nearly 360°; rotation angle range approaches to 270°. Tilt is adjustable between ﹣10°...
- Page 11 STEP 16: Put the Inner Cover back to the Camera Module. STEP 17: Vandal Proof Replace the Dome Cover back. For Vandal Proof IP Dome Camera, please align the arrow mark on the Dome Cover with the one on the Housing as shown in the top figure.
- Page 12 STEP 18: Screw on the two Torx Screws on the side of the Dome Cover tightly to fasten the Dome Cover. Camera installation is complete.
-
Page 13: Outdoor Camera Installation With Sunshield Housing & Pendant Mount
Outdoor Camera Installation with Sunshield Housing & Pendant Mount The Vandal Dome Network Camera (DV104, DV204M) can be mounted on the wall with the Standard / Compact Pendent Mount for monitoring convenience. The Outdoor Sunshield Housing accessory is required in addition to either the Standard &... - Page 14 Compact Pendant Mount Dimension: Tools Needed: Tool for drilling Tool for screwing Security Torx (supplied) Follow the steps below to install the Standard/ Compact Pendant Mount: Step 1: Unscrew the Security Torx Screws with the supplied Security Torx Driver and open the Dome Cover.
- Page 15 Step 3: Unscrew Module-fastened Torx Screw, as indicated in the figure. Step 4: Press the sides of the Snap-on Camera Module, as indicated in the figure, and detach it from the Dome Camera’s Housing. Step 5: Fasten the Standard/ Compact Pendant Mount onto the wall securely Run the Ethernet cable through the Standard/ Compact Pendant Mount as shown in...
- Page 16 Step 6: Thread the Ethernet cable through the entry of the Dome Camera’s Housing. Step 7: Rotate the joint of Dome Camera Housing into the entry of the Pendant Mount, aligning the screw hole of the joint with the one of the Pendent Mount. Step 8: Fix the camera housing with the supplied M8x16 Hex Head Stainless Steel Screw...
- Page 17 Step 10: Connect the RJ-45 cable to the Camera Module to access the camera for viewing video, and then adjust the Dome Camera lens to a desired angle. NOTE: The zoom level and focal length might be different with the Dome Cover on, in this case, adjusting zoom level and focal length through the Dome Cover is recommended.
-
Page 18: Cable Gland Installation
Cable Gland Installation When mounting the Vandal Dome indoors, the cable connection can be protected from water damages by installing the all-in-one cable with a cable gland. Cable Gland Installation Kit: 1. Silicone Rubber Ring 2. Cable Gland First insert the silicone rubber ring into the cable gland body from the top, as shown on the right, for later use. - Page 19 Step 2. Insert the all-in-one cable to the cable gland body from the bottom, starting from the biggest size connector to the smallest size connector as well. Step 3. Twist in the thread-lock sealing nut a little bit back to the cable gland body.
- Page 20 Step 4. Insert the all-in-one cable to the side conduit entry, again starting from the biggest size connector to the smallest size connector. Step 5. Attach the Snap-on Camera Module into the Dome Camera Housing, screw Module-fastened Screw tightly with the screw driver to secure the Camera Module.
