Optica HD Indoor Dome Network Camera
Model: D122
User's Manual
Ver. 1.3

Advertisement

Table of Contents
loading

Related Manuals for Optica D122

Summary of Contents for Optica D122

  • Page 1 Optica HD Indoor Dome Network Camera Model: D122 User’s Manual Ver. 1.3...

  • Page 2: Table Of Contents

    Setup Video Resolution ......................11 Configuration Files Export / Import ..................12 Appendix A: Technical Specifications ..................13 Appendix B: Delete the Existing Optica Viewer ................. 15 Appendix C: Setup Internet Security ..................16 Appendix D: Video Resolution ....................17 D122 - Quad Streams ......................

  • Page 3: Overview

    Overview The D122 HD Indoor Dome Network Camera is an easy setup camera with PoE supported to reduce complicate cabling. Up to 720P Megapixel Resolution is offered for providing high definition images. Quad Streams Compression (H.264 Baseline / Main / High Profile + MJPEG) are supported for efficient bandwidth and storage management.

  • Page 4: Package Contents

    Package Contents The package should contain the items listed below. If any item is missing or has defects, please contact the dealer for assistance. D122 HD Dome Camera D122 Power Terminal Block HD Dome Camera Self Tapping Screws (x3) Plastic Screw Anchors (x3)

  • Page 5: Dimensions

    Dimensions The dimensions of the IP Camera are shown below. D122...

  • Page 6: Connectors

    Connectors The positions of the IP Camera’s connectors are shown in the below diagram. Definition for each connector is also given as follows. Connector Definition Remarks 10/100 Mbps Ethernet / PoE RJ-45 AC 24V: Power-1 DC 12V: Power Power Power AC 24V: GND DC 12V: Reserved connection...

  • Page 7: Camera Cabling

    Camera Cabling Follow the instructions below to complete IP Camera connection. Connect Power For power connection, please refer to section Connectors. Alternatively, users can power the camera by PoE. Refer to the section below to connect the Ethernet Cable for PoE connection. NOTE: If PoE is used, make sure Power Sourcing Equipment (PSE) is in used in the network.

  • Page 8: System Requirements

    System Requirements To perform the IP Camera via web browser, please ensure the PC is in good network connection, and meet the system requirements as described below. Items System Requirement ® ® 1. Intel Pentium M, 2.16 GHz or ® Intel Core 2 Duo, 2.0 GHz...

  • Page 9: Access Camera

    Access Camera For initial access to the IP Camera, users can search the camera through the installer program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the supplied CD. Accessing Device Search Software Step 1: Double click on the program Device Search.exe. After its window appears, click on the <Device Search>...
  • Page 10 IP Camera. Installing Optica Viewer Software Online For the initial access to the IP Camera, a client program, Optica Viewer, will be automatically installed to the PC when connecting to the IP Camera. If the Web browser doesn’t allow Optica Viewer installation, please check the...
  • Page 11 The download procedure of Optica Viewer software is specified as follows. Step 1: In the Optica Viewer installation window, click on <Next> to start the installation. Step 2: A status bar will be displayed to show the installation progress. After the installation is completed, click on <Finish> to exit the installation process.

  • Page 12: Setup Video Resolution

    Video Format can be found under this path: Streaming> Video Format. The default values of the Video Resolution are as below. H.264- 1280 x 720 (30 fps) + MJPEG – 640 x 480 D122 For more Video Resolution combination details, please refer to chapter Appendix D: Video...

  • Page 13: Configuration Files Export / Import

    Configuration Files Export / Import To export / import configuration files, users can access the Maintenance page on the user-friendly browser-based configuration interface. The Maintenance setting can be found under this path: System> Maintenance. Users can export configuration files to a specified location and retrieve data by uploading an existing configuration file to the IP Camera.

  • Page 14: Appendix A: Technical Specifications

    Appendix A: Technical Specifications Camera Image Sensor 1/2.8” Sony Progressive CMOS Effective Pixels 1280 (H) x 720 (V) Shutter Speed 1 ~ 1/10000 sec. Lens Lens Board Focal Length 3.6 mm F Number F1.8 Operation English / French / German / Italian / Japanese / Korean / Portuguese / Multiple Languages Russian / Simplified Chinese / Spanish / Traditional Chinese Backlight Compensation...
  • Page 15 Mechanical Working Distance Up to 25 m Built-in IR Wavelength 850 nm Illuminator Number of LEDs LED Indicator Power / Link / ACT Alarm 4 of 8 Pin Terminal Block (Female) Power 3 Pin Terminal Block Connectors Ethernet RJ-45 Audio 4 of 8 Pin Terminal Block (Female) General Operating Temperature...

  • Page 16: Appendix B: Delete The Existing Optica Viewer

    Appendix B: Delete the Existing Optica Viewer For users who have installed the Optica Viewer in the PC previously, please remove the existing Optica Viewer from the PC before accessing to the IP Camera. Deleting the Optica Viewer In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove Programs>.

  • Page 17: Appendix C: Setup Internet Security

    Appendix C: Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>. Step 3: Click on the <Security>...

  • Page 18: Appendix D: Video Resolution

    Appendix D: Video Resolution D122 - Quad Streams H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (15 fps) 352 x 240 (30 fps) 1280 x 1024 (15 fps) 640 x 480 (15 fps)
  • Page 19 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 (15 fps) 640 x 480 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 800 x 600 (15 fps) 640 x 480 (30 fps) 800 x 600 (30 fps)
  • Page 20 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 (15 fps) 640 x 480 (30 fps) 1280 x 720 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 1280 x 720 (15 fps) 800 x 600 (30 fps)
  • Page 21 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 640 x 480 (30 fps) 352 x 240 (30 fps) 1024 x 768 (30 fps) 352 x 240 (30 fps) 352 x 240 (30 fps) 800 x 600 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps)

  • Page 22: D122 - Triple Streams

    D122 - Triple Streams H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 800 x 600 (15 fps) 720 x 480 (15 fps) 1280 x 1024 (15 fps) 640 x 480 (15 fps) 352 x 240 (30 fps)
  • Page 23 H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 1280 x 720 (30 fps) 352 x 240 (30 fps) 1024 x 768 (30 fps) 352 x 240 (30 fps) 800 x 600 (30 fps) 720 x 480 (30 fps) 800 x 600 (30 fps) 640 x 480 (30 fps) 352 x 240 (30 fps)

  • Page 24: D122 - Dual Streams

    D122 - Dual Streams H.264-1 + H.264-2 / MJPEG H.264-1 H.264-2 / MJPEG BNC SUPPORT 1280 x 1024 (15 fps) 1280 x 720 (30 fps) 1024 x 768 (30 fps) 1920 x 1080 (15 fps) 800 x 600 (30 fps) 720 x 480 (30 fps) √...
