Optica B204 User Manual

B204
1080P HD Outdoor Bullet Network Camera
Full HD 1080P - 3-9mm VF Lens - Day/Night w/IR to 25m
The B204 bullet is a professional day/night, outdoor-
ready network camera, able to deliver best-in-class
quality HD 1080P video at a full 30 frames per second,
and see up to 25m in complete darkness (0 lux).
A 3-9mm vari-focal lens allows for camera placement
flexibility, providing a field of view between 34 and
103 degrees. The IP66 rated weather-proof camera
housing is constructed with a cable management
bracket, facilitating easy, secure installation.
As with all Optica cameras, the B204 bullet comes with
a limited Two Year Warranty and free OpticaCMS software,
capable of recording and viewing 64 camera channels.
Advanced camera features found in all Optica cameras
include H.264 Quad Streams, Wide Dynamic Range,
PoE/PoE+ Power, 3D Noise Cancellation, Tamper
Detection, Network Failure Detection, MicroSD on-board
recording, Vertical View mode, Privacy Masks, Digital
Zoom, and more.
www.opticavideo.com

Features

HD 1080P Resolution at 30 fps
•
3-9mm Vari-Focal Lens
•
Wide Dynamic Range
•
IR Cut Filter for True Day/Night
•
Video
IR illuminators with 25m range
•
Weather-Proof Housing
•
MicroSD On-Board Recording
•
H.264 / MJPEG video compression
•
