- Page 1 Wireless Video Security System Portable LCD Monitor & Indoor/ Outdoor Night Vision Camera Model# PHOENIX1 V 1.0 INSTRUCTION MANUAL...
- Page 2 Increase the viewing capabilities of your monitoring system with a PHOENIX1C additional camera. Look for it online or in participating retail outlets.
-
Page 3: Need Help
NEED HELP? PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE Please contact a DEFENDER customer support representative first regarding any additional information on product features, specifications or help with set-up. Please contact us via one of the methods below: Email: support@defender-usa.com... -
Page 4: Product Warranty Information
5. This warranty does not cover the shipping cost, insurance or any other incidental charges. 6. You MUST call Defender before sending any product back for repair. You will be sent a Return Authorization form with return instructions. When returning the product for warranty service, please pack it carefully in the original box with all supplied accessories, and enclose your original receipt or copy, and a brief explanation of the problem (include RA #). -
Page 5: Table Of Contents
PHOENIX1 TABLE OF CONTENTS TABLE OF CONTENTS ......................1 INTRODUCTION ......................2 WHAT IS INCLUDED .......................2 FEATURES ........................3 OPTIONAL ACCESSORIES ....................4 THINGS TO CONSIDER BEFORE INSTALLATION ..............4 AVOIDING INTERFERENCE ....................4 INSTALLATION ......................5 INSTALLING THE CAMERA (TRANSMITTER) .............5 NSTALLING AN ADDITIONAL CAMERA ..............5 SETTING THE CAMERA CHANNELS .................6... -
Page 6: Introduction
Congratulations on your purchase of the PHOENIX1! This system consists of a wireless camera, which transmits video and audio signals to a handheld color LCD monitor. The PHOENIX1 allows you to see and hear events which are happening in other areas of your home or business when you are not present. -
Page 7: Features
PHOENIX1 FEATURES PHOENIX1... -
Page 8: Optional Accessories
• To maximize viewing area, ensure there are no obstructions in the camera’s view. AVOIDING INTERFERENCE The PHOENIX1 utilizes Clear Signal Technology, meaning that it is designed to avoid the frequencies of common wireless devices. By doing so, the system does not receive interference from any of the standardized 2.4GHz or 5.8 GHz wireless devices within your home or business. -
Page 9: Installation
If you are using an additional camera (not included) they will need to be set on different channels. The PHOENIX1 is set by default to operate with one camera. If you will be using two cameras, follow the instructions on next page. -
Page 10: Setting The Camera Channels
PHOENIX1 SETTING THE CAMERA CHANNELS 1. Verify the camera’s channel setting by verifying the DIP switch settings. To do this, unscrew the front part of the camera to open the lens cover and adjust the DIP switches. PHOENIX1 cameras are set by default to Channel 1. 2. Use a pen or pointed object to flip the DIP switches up or down according to the image below. Make sure that one camera is set to the Channel 1 position and the other camera is set to the Channel 2 position. -
Page 11: Setting Up The Lcd Monitor (Receiver)
4. Turn on the PHOENIX1 by pressing the button. You will hear an audible beep and the sound indicator lights on the monitor will blink. -
Page 12: Connecting Directly To The Lcd Monitor
A red LED light on the side of the monitor will turn on to show that the unit is connected to power and the battery is charging. 3. Turn on the PHOENIX1 by pressing the button. You will hear an audible beep and the sound indicator lights on the monitor will blink. -
Page 13: Operation
PHOENIX1 OPERATION MONITOR FUNCTIONS PHOENIX1... -
Page 14: Powering On
PHOENIX1 POWERING ON Turn on the monitor by pressing the . You will hear an audible beep and the LED lights will blink. The screen will display video from your mounted camera. The red LEDs at the top of the monitor indicate the level of sound the microphone is detecting. The first two lights indicate a quiet sound level, the middle light indicates moderate, and the fourth and fifth lights indicate loud sounds taking place in the area you are monitoring. -
Page 15: Scan Mode
PHOENIX1 Use manual mode if you want to view continuous video with sound. You will also be alerted if there are any sound disturbances in the area you are monitoring. If you are using more than one camera, you will be able to choose which camera to view, and how long you wish to view it. -
Page 16: Auto Mode
PHOENIX1 SCAN MODE continued... 2. If the camera detects sound above the desired sound trigger level, the monitor will beep and will display video and sound from your monitoring location. The Channel 1 or Channel 2 indicator light will also turn on to let you know where your video is coming from 3. - Page 17 PHOENIX1 AUTO MODE continued... Use Auto mode if you want to be able to view video from both cameras and receive audio alerts if there are any sound disturbances in either monitoring areas. To disable this alert, turn down the (audio sensitivity) dial on the side of the monitor by pushing the dial down all the way.
-
Page 18: Changing The Cycle/Dwell Time In Auto Mode
When you are finished setting a new duration press the A button again to view video with your new dwell cycle time. Note: Every time you power off the PHOENIX1, the dwell/cycle defaults back to four seconds. CONNECTING TO A TV/VCR/DVR You can connect to a TV for viewing or to a VCR/ DVR for recording. -
Page 19: Lithium Battery Tips
PHOENIX1 LITHIUM BATTERY TIPS The rechargeable battery of the handheld monitor is a built-in lithium-polymer battery. Before using the monitor with battery power, please read the following in order to use the battery properly. 1. Under normal temperatures the battery can be recharged at least 300 times. -
Page 20: Connecting To Tv, Monitor, Vcr, Or Dvr
Monitor, VCR, or DVR. 3. Set your TV to the proper Video Input channel to view video from the PHOENIX1 monitor. If you do not know how to switch to the Video Input channel, refer to your TV’s instruction manual. - Page 21 PHOENIX1 Audio Issues/No Audio 1. Ensure the volume is turned up on the monitor (press the V+ button to increase volume) 2. Make sure that the sound is within microphone range 3. If the unit emits a loud screeching sound (feedback) try moving the camera away from the monitor or angle the monitor differently LCD monitor beeping and LEDs 1.
-
Page 22: Specifications
PHOENIX1 SPECIFICATIONS MONITOR Monitor Type ..........Color TFT-LCD Battery Life ..........Up to 4 Hours Screen Size ........2.25"Wireless Frequency Handheld ..............Yes Video On/Off Button ............No 900MHz Adjustable Brightness ..........Yes Channel Frequencies ..........910, 920 Operating Environment Number of Cameras Supported ........2 Output Terminal ........3.5mm A/V Port Operating Temperature ......14F~104F... - Page 23 DEFENDER SUPPORTS CRIME STOPPERS Crime Stoppers programs are operated as non-profit charities and are managed by a volunteer board of directors who raise funds and pay rewards to individuals who anonymously call with information that helps solve crime. Rewards are paid for tips that lead to the arrest and indictment of people charged with felony offenses, and to date Crime Stoppers statistics show a conviction rate of approximately 95%.
- Page 24 DEFENDER SUPPORTS CRIME STOPPERS To receive more information about Crime Stoppers or to make a charitable donation please fill in the fields below, cut on the dotted line an mail in. CRIME STOPPERS INTERNATIONAL Crime Stoppers International is an organization of community based civilian Crime Stoppers programs, which assist police in solving crime.
-
Page 25: Customer Information Card
NOTES Customer Information Card User’s Name: Company Name: Address: Postal Code: Phone Number: Email: Model Number of Product: Serial Number of Product: Purchase Date: Place of Purchase: NOTE: We recommend that you keep a record of your purchase receipt with your manual for any future returns or support issues. - Page 26 Model #: PHOENIX1 www.defender-usa.com...
