5. Have a second person hold the Upright (13) near
the Front Frame (23) as shown.
Locate the wire tie in the Upright (13). Tie the
wire tie to the Main Wire Harness (45) in the
Front Frame (23). Then, pull the upper end of
the wire tie until the Main Wire Harness is routed
through the Upright.
6. Tip: Avoid pinching the Main Wire Harness
(45). Slide the Upright (13) onto the Front Frame
(23). Attach the Upright with three M10 x 60mm
Bolts (61) and three M10 Locknuts (48); make
sure that the Locknuts are in the hexagonal
holes. Do not fully tighten the Bolts yet.
5
6
Avoid pinching
the Main Wire
Harness (45)
8
Wire Tie
13
Wire
45
Tie
23
13
Hexagonal
Holes
48
45
23
61
