- Page 1 PA700 Rugged Handheld Computer User’s Manual Version 1.0...
-
Page 2: Table Of Contents
Table of content Table of content....................2 1. Package Contents ..................3 2. Getting started ................... 4 2.1 Device overview ................... 4 2.2 Assembly ....................6 Accessing battery, Micro SD card and SIM card ........6 2.3 Charging the battery ................7 2.4 Data Communicating with PC Device ........... -
Page 3: Package Contents
1. Package Contents USB cable PA700 (Standard USB to Micro USB) Charger Battery Power Plug Adapter Hand Strap Utility DVD... -
Page 4: Getting Started
2. Getting started Unitech PA700 is an Android platform device. Android platform device has great flexibility that allows you to make customized configurations and enhancements by install and remove Apps. With Android operation system, your device has limitless possibilities to update to latest features and improvements. - Page 5 13. Bar code Scan Engine 15. Volume Down button 14. Scan button 16. Volume Up button 17. Micro USB port 19. Power button 18. Phone jack 20. Scan button...
-
Page 6: Assembly
2.2 Assembly Accessing battery, Micro SD card and SIM card 1. Using a proper tool (ex. a coin) to loosen the two screws on the battery cover by turning anticlockwise. 2. Remove the back cover and pull the battery out. 3. -
Page 7: Charging The Battery
2.3 Charging the battery Connect PA700 to the charger, it will be charged automatically. 1. Connect the standard USB connector to the charger. 2. Connect the micro USB connector to the micro USB port at the bottom. 3. Plug the AC charger into a wall outlet. If needed, attach a plug converter onto the AC charger. -
Page 8: Led Status
2. Connect the micro USB connector to the micro USB port at the bottom. 2.5 LED status Green The battery is fully charged Lights Red The battery is charging. The battery level is between low and full Blue Message is received. 2.6 To check the battery level and to access the battery usage menu 1 From your Home screen, tap... - Page 9 2 Find and tap Settings. 3 Find and tap Battery.
-
Page 10: Basic Operation
3. Basic Operation 3.1 Accessing and using applications To open the Application screen From your Home screen, tap To browse the Application screen From the Application screen, flick right or left. To create a shortcut to an application on the Home screen 1 From your Home screen, tap 2 Touch and hold an application icon and then the Home screen opens. -
Page 11: Barcode Scanning (For Imager Version Only)
3.2 Barcode Scanning (For Imager Version only) 1. Tap the ScanService 2. Aim the Bar code Scan Engine to the barcode and press one of two scan buttons. -
Page 12: Rfid Sensing
3.3 RFID Sensing 1. Tap the NFC Reader... -
Page 13: Specification
4. Specification System Features TI OMAP 4470 1.5Ghz Dual Core Processor Memory 1GB Mobile DDR RAM 8GB eMMC Flash Android 4.1.1 Jelly Bean English, Simp. Chinese, Traditional Chinese, Japanese, Languages support Spanish, German, French Display Gorilla Glass II with 5-point capacitive touch panel 4.7"... - Page 14 Other Sensors eCompass Light & Proximity sensor G-sensor RFID/HF (Optional) Frequency: 13.56MHz Tag Support: ISO15693, ISO14443A , ISO14443B Support NFC 12 x 12 mm patch antenna Power Source Main Battery 11.9Wh 3.7V @3220mAh Li-Polymer battery pack Backup Battery capacity 1 hour Enclosure Weight 285g (with battery)
-
Page 15: Appendix Worldwide Support
Appendix Worldwide Support Unitech’s professional support team is available to quickly answer questions or assist with technical-related issues. Should an equipment problem occur, please contact the nearest Unitech regional service representative. For complete contact information please visit the Web sites listed below:...
