Elo TouchSystems 3239L User Manual

32” lcd touchmonitor
Hide thumbs Also See for 3239L:
Table of Contents

Advertisement

Quick Links

Download this manual
3239L 32" LCD Touchmonitor User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3239L and is the answer not in the manual?

Questions and answers

Related Manuals for Elo TouchSystems 3239L

Summary of Contents for Elo TouchSystems 3239L

  • Page 1 3239L 32” LCD Touchmonitor User Guide...

  • Page 2: User Guide

    Elo TouchSystems 3239L Touchmonitor User Guide Revision A P/N E842524 Elo TouchSystems 1-800-ELOTOUCH www.elotouch.com...
  • Page 3 Elo TouchSystems to notify any person of such revisions or changes. Trademark Acknowledgments IntelliTouch, SC (Surface Capacitive), APR (Acoustic Pulse Recogni- tion), Elo TouchSystems, TE Logo, and Tyco Electronics are trade- marks. Other product names mentioned herein may be trademarks or registered trademarks of their respective companies. Elo TouchSystems claims no interest in trademarks other than its own.

  • Page 4: Table Of Contents

    Clock ............................19 Phase............................19 Color ............................19 Input Select ..........................19 OSD ............................19 OSD H-Position ........................19 OSD V-Position ........................19 OSD Timeout ..........................19 Language ........................... 19 Recall ............................20 Miscellaneous ..........................20 Elo TouchSystems 3239L User Guide 4...
  • Page 5 Care and Handling of Your Touchmonitor ................24 Appendix B ...................... 25 Technical Specifications ................25 3239L Specifications ......................26 3239L 32” LCD Touchmonitor Dimensions ............... 28 Regulatory Information ....................... 29 Warranty ........................... 32 Elo TouchSystems 3239L User Guide 5...

  • Page 6: Introduction

    C H A P T E R INTRODUCTION About the Product Your new 3239L Elo TouchSystems Touchmonitor combines the reliable performance of touch technology with the latest advances in Liquid Crystal Display (LCD) design. The monitor comes with the following features: •...

  • Page 7: Installation And Setup

    C H A P T E R INSTALLATION AND SETUP This chapter discusses how to install and set up your LCD touchmonitor and how to install Elo TouchSystems driver software.

  • Page 8: Unpacking Your Touchmonitor

    Check that the following items are present and in good condition: Power cable Touchmonitor DVI-D cable USB Cable Video cable (not included with 3239L-xxEx models) Serial Cable OSD Control Box CD and Quick Install Guide (not included with 3239L-Axxx models) Elo TouchSystems 3239L User Guide 8...

  • Page 9: Interface Connection

    Tighten by turning the two thumb screws clockwise to ensure proper grounding. Connect the other end to your computer. Press the power button on the rear panel to turn the monitor on. Connect the OSD control box to the monitor. Elo TouchSystems 3239L User Guide 9...

  • Page 10: Installing The Touch Driver

    Insert the Elo CD-ROM in your computer’s CD-ROM drive. If Windows XP, Windows 2000, Windows 98, or Windows Me start the Add New Hardware Wizard, follow these steps (if it does not open, follow steps 1a through 2a): Elo TouchSystems 3239L User Guide 10...
  • Page 11 2a Follow the directions on the screen to complete the driver setup for your version of Windows. If the AutoStart feature is not active: Click Start > Run. Click the Browse button to locate the EloCd.exe program on the CD-ROM. Elo TouchSystems 3239L User Guide 11...
  • Page 12 Click Open, then OK to run EloCd.exe. Follow the directions on the screen to complete the driver setup for your version of Windows. Elo TouchSystems 3239L User Guide 12...

  • Page 13: Monitor Mounting Orientation

    Alternatively, the monitor may be mounted in the portrait orientation. For this orientation, the cable connection panel may be on either side, as shown in the illustrations below. Rear View of Monitor—Portrait Orientation Elo TouchSystems 3239L User Guide 13...
  • Page 14 Mounting Orientation Angle Landscape Views The mounting orientation can be up to a 90° angle, as shown in the illustrations below. 90º 90º Elo TouchSystems 3239L User Guide 14...
  • Page 15 Monitor Orientation Angle Portrait Views The mounting orientation can be up to a 90° angle, as shown in the illustrations below. 90° 90° Elo TouchSystems 3239L User Guide 15...

  • Page 16: Operation

    Note: Do not operate the touchmonitor if you see the OOR mes- sage, or LCD damage may result. If you see the OOR message, set the video mode to one within the allowable vertical frame rate range. Elo TouchSystems 3239L User Guide 16...

  • Page 17: On-Screen Display (Osd) Control Box

    2) Decreases value of OSD adjustment choice AUTO/SEL 1) Automatically adjusts the image on the screen (this function not available for 3239L-xxEx models) 2) Selects adjustment choices from the OSD menus. After adjusting the values, the monitor will automatically save the changes.

  • Page 18: Osd Lock/Unlock

    Continue to hold the buttons down for another 2 seconds and the window toggles to “Power Lock.” NOTE: By default, the OSD screen will disappear if no input activities are detected for 30 seconds. Elo TouchSystems 3239L User Guide 18...

  • Page 19: Osd Control Options

    OSD Timeout • Adjusts amount of time that the OSD menu is displayed. Language • Selects the language used for the OSD menu from English, French, German, Spanish, Italian, Traditional Chinese, Simplified Chinese, or Japanese. Elo TouchSystems 3239L User Guide 19...

  • Page 20: Recall

    • Restores original factory settings for all other parameters and video inputs, except language (VGA and DVI). Miscellaneous Sharpness • Adjusts sharpness of video. Display Information • Frequency of the input horizontal/vertical synchronizing signal is indicated. Elo TouchSystems 3239L User Guide 20...

  • Page 21: Preset Display Modes

    The monitor comes with preset settings for commonly used video modes. It will automatically adjust the picture size and centering for any of the video modes listed in Appendix B, 3239L Specifications table, under “Preset Display Modes.” If you make any adjustments to the H-position, V-Position, Clock and...

  • Page 22: Chapter 4

    See Chapter 3 and Appendix B for more information on allowable video modes. Touch doesn’t work Make sure the USB or serial cable is securely attached at both ends. Elo TouchSystems 3239L User Guide 22...

  • Page 23: Appendix A

    Do not block or insert anything inside the venti- lation slots. It is important that your touchmonitor remains dry. Do not pour liquid into or onto your touchmonitor. If your touchmonitor be- comes wet do not attempt to repair it yourself. Elo TouchSystems 3239L User Guide 23...

  • Page 24: Care And Handling Of Your Touchmonitor

    Waste Electrical and Electronic Equipment (WEEE) Directive In the European Union, this label indicates that this product should not be disposed of with household waste. It should be deposited at an appropriate facility to enable recovery and recycling. Elo TouchSystems 3239L User Guide 24...

  • Page 25: Appendix B

    APPENDIX TECHNICAL SPECIFICATIONS...

  • Page 26: 3239L Specifications

    • RGB Analog Video (0.7V p-p, 75 ohm; separate syncs, composite sync, or sync-on-green; TTL positive or negative) • DVI Video (not available for 3239:-xxEx models) Video Signal Connector Analog: 15 pin Female D-Sub Digital: Female DVI-D Elo TouchSystems 3239L User Guide 26...
  • Page 27 Altitude: 0 to 3,658 m Storage Conditions Temp: -20°C to 60°C (-4°F to 122°F) Humidity: 10% to 90% (No Condensation) Altitude: 0 to 12,192 m Dimensions (HxWxD) 474 x 784 x 110 mm Weight 17.3 kg Elo TouchSystems 3239L User Guide 27...

  • Page 28: 3239L 32" Lcd Touchmonitor Dimensions

    3239L 32” LCD Touchmonitor Dimensions Note: Detailed mechanical files can be found at: www.elotouch.com Elo TouchSystems 3239L User Guide 28...

  • Page 29: Regulatory Information

    This equipment generates, uses, and can radiate radio frequency energy, and if not installed and used in accor- dance with the instructions, may cause harmful interference to radio communications. Elo TouchSystems 3239L User Guide 29...
  • Page 30 2) If this equipment appears to cause interference with radio or television reception, or any other device: a) Verify as an emission source by turning the equipment off and on. b) If you determine that this equipment is causing the Elo TouchSystems 3239L User Guide 30...
  • Page 31 The following marks have been issued for the unit and appear on the safety label as shown in the illustration below: LISTED 3Z74 E162681 301 Constitution Drive lamp contains mercury - Dispose of properly Tested To Comply With FCC Standards FOR HOME OR OFFICE USE Elo TouchSystems 3239L User Guide 31...

  • Page 32: Warranty

    Seller’s facilities or at Buyer’s premises. If Seller is unable to modify, repair, or replace a Product to conform to the war- ranty set forth above, then Seller shall, at Seller’s option, either refund Elo TouchSystems 3239L User Guide 32...
  • Page 33 Products made or authorized by Buyer. Buyer will indemnify Seller and hold Seller harmless from any liability, claims, loss, cost, or expenses (including reasonable attorney’s fees) attribut- able to Buyer’s products or representations or warranties concerning same. Elo TouchSystems 3239L User Guide 33...

  • Page 34: Product Information

    D-85521 Ottobrunn Belgium Germany Tel +81(45)478-2161 (800) ELO-TOUCH Tel +49 (0)(89) 60822-0 Fax +81(45)478-2180 Tel +32(0)(16)35 21 00 (800) 356-8682 Fax +49(0)(89) 60822-180 www.tps.co.jp Fax +32(0)(16)35 21 01 Tel 650-361-4800 elosales@elotouch.com elosales@elotouch.com Fax 650-361-4747 eloinfo@elotouch.com Elo TouchSystems 3239L User Guide 34...
