Telular Phonecell SX5T CDMA2000 1X series User Manual

Fixed wireless terminal
Hide thumbs Also See for Phonecell SX5T CDMA2000 1X series:
Table of Contents

Advertisement

Quick Links

Download this manual
Phonecell
SX5T CDMA2000
1X
®
®
Fixed Wireless Terminal
SX5T-505C/-535C D
-B
800/1900 MH
CDMA
UAL
AND
Z
SX5T-500C S
-B
800 MH
CDMA
INGLE
AND
Z
SX5T-500C S
-B
1900 MH
CDMA
INGLE
AND
Z
U
M
SER
ANUAL
11/19/04
Part Number 56029901

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Phonecell SX5T CDMA2000 1X series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Telular Phonecell SX5T CDMA2000 1X series

Summary of Contents for Telular Phonecell SX5T CDMA2000 1X series

  • Page 1 Phonecell SX5T CDMA2000 ® ® Fixed Wireless Terminal SX5T-505C/-535C D 800/1900 MH CDMA SX5T-500C S 800 MH CDMA INGLE SX5T-500C S 1900 MH CDMA INGLE ANUAL 11/19/04 Part Number 56029901...
  • Page 2 (Optional) Before installing the Phonecell ® SX5T, carefully remove the contents from the shipping carton and check for evidence of shipping damage. If damage is found, contact your Authorized Telular Distributor or shipping agent immediately. Phonecell SX5T CDMA2000 User Manual...

  • Page 3: Important Notices

    PRODUCTS ("Product") ® These Terms and Conditions are a legal contract between you and Telular Corporation for the title to and use of the Product. BY RETAINING AND USING THE PRODUCT AFTER RECEIPT OF IT, YOU AGREE TO THE TERMS AND CONDITIONS INCLUDING WARRANTY DISCLAIMERS, LIMITATIONS OF LIABILITY AND INDEMNIFICATION PROVISIONS BELOW.

  • Page 4: Table Of Contents

    Table of Contents Quick Connection Diagram....................ii Safe Operation Instructions....................iii Important Notices ........................iii Setup ............................1 RUIM Card Installation (RUIM Model Only) ..................1 Connecting an SX5T Model With a Power Supply................2 Emergency Batteries ........................3 Connecting an SX5T Model With a BBU (Backup Battery Unit) .............4 SX5T Location and Installation......................5 Wall Mounting ..........................5 GPS Antenna Mounting (optional on SX5T-505C/-535C only)............6...

  • Page 5: Setup

    Setup RUIM Card Installation (RUIM Model Only) Consult your service provider to determine if your unit requires the use of a RUIM (Removable User Identity Module) card. If it is a RUIM model, your SX5T will only be able to make emergency calls until you install a RUIM card.

  • Page 6: Connecting An Sx5T Model With A Power Supply

    Connecting an SX5T Model With a Power Supply Your SX5T has either a Power Supply (part #74007301) or a Battery Backup Unit (BBU; part #74006803). If your unit uses a Power Supply, please follow the instructions below to connect the SX5T to your AC power. If it uses a BBU, please see “Connecting an SX5T Model With a BBU”...

  • Page 7: Emergency Batteries

    Emergency Batteries If your SX5T has a Power Supply, you may install emergency batteries to power the device in the event of a power outage. Do not install emergency batteries if your SX5T has a BBU. The SX5T will not automatically switch to battery if AC power fails; you must flip the AC/Battery switch to battery operation - see Figure 5.

  • Page 8: Connecting An Sx5T Model With A Bbu (Backup Battery Unit)

    Connecting an SX5T Model With a BBU (Backup Battery Unit) Your SX5T has either a Power Supply (part #74007301) or a Battery Backup Unit (BBU; part #74006803). If your model has a BBU, it is shipped with the battery disconnected to prevent if from being prematurely drained.

  • Page 9: Sx5T Location And Installation

    SX5T Location and Installation The SX5T comes with a standard spike antenna (TNC) - see Figure 7. For optimal signal strength, choose a location that is above ground and as close to windows (or exterior walls) as possible - see Figure 8.

  • Page 10: Gps Antenna Mounting (Optional On Sx5T-505C/-535C Only)

    GPS Antenna Mounting (optional on SX5T-505C/-535C only) To satisfy the FCC's Enhanced 911 (E-911) Phase II mandate, SX5T-505C and 535C models distributed in the USA include an optional GPS antenna with a mounting bracket and suction cups. The GPS antenna uses satellite technology during emergency calls to automatically report your location to a 911 dispatcher within 50-100 meters in most cases.

  • Page 11: Direct Connection: Phone, Fax And Data

    - see Figure 11 on page 6. If desired, connect a computer to the SX5T. You may either: · Use a Telular USB cable (part #1L01A043 or 81025901) to connect the computer’s USB port to the SX5T’s data port; ·...

  • Page 12: Getting To Know Your Sx5T

    Getting to Know Your SX5T LED Status Indicators The LED indicators are activated when the SX5T is powered on. The following tables describe the modes and operation of the indicators. Note: If you are getting no service, contact your service provider for more information. Signal Strength 3 Signal Strength 2 Signal Strength 1...

  • Page 13: Important Dial Tones

    Call Activity Indicator LED Color Activity Description Flashing Green Incoming call (phone will also be ringing) Green Continuous In an active call Green Fast Flashing Processing data call Amber Continuous Programming Mode Message Indicator LED Color Activity Description Green Flashing New voicemail AC Power/Battery Indicator Color...

  • Page 14: Using The Sx5T

    Using the SX5T Once you have installed and activated your SX5T, you’ll be ready to make and receive calls, set up voicemail, and send and receive faxes. This section explains how to use the features of the SX5T for all your communications. Making Calls To make a call: Pick up the telephone handset.

  • Page 15: Accessing Your Voicemail

    Accessing Your Voicemail With your SX5T, you have two options for accessing your voicemail account from your phone: One-Touch Voicemail Retrieval and Direct Dial . (For more information about your voicemail settings, see “Voicemail Number” and “One-Touch Voicemail Retrieval” on page 16. For information about your voicemail service, please contact your service provider.) To access your voicemail using One-Touch Voicemail Retrieval: •...

  • Page 16: Adjusting Your Phone's Settings

    Adjusting Your Phone’s Settings Volume Level If the volume level on your phone’s receiver is too high or too low during a call, you can adjust the levels using the telephone keypad. To increase the phone’s volume level: • Press To decrease the phone’s volume level: •...

  • Page 17: Audio Line Level

    Audio Line Level If using does not provide satisfactory volume options for you (see “Volume Level” on page 12), you may adjust your phone system’s audio line level. To adjust your phone system’s audio line level: • From Configuration Mode, press <0, 1, or 2>...

  • Page 18: Call Restrict (Sx5T-500C Only)

    Call Restrict (SX5T-500C only) Call Restrict allows you to determine which calls may or may not be placed through your SX5T. When the Call Restrict level is set to Use Table , the Call Restrict feature checks outgoing calls against user-defined permit and deny tables to determine whether to permit or deny the outgoing call.

  • Page 19: Hotline

    Hotline The Hotline feature allows you to program the SX5T to automatically dial a specific phone number after a selected timeout delay whenever you take the phone off-hook. To program the Hotline phone number: • From Configuration Mode, press <phone #> , where <phone #>...

  • Page 20: Voicemail Number

    Voicemail Number You can use Configuration Mode to set the default voicemail number for your SX5T. Note: The voicemail settings for your SX5T should have been configured prior to purchase. The instructions for Voicemail Number and One-Touch Voicemail Retrieval are mainly for your reference. To set the default voicemail number: <voicemail •...

  • Page 21: Using Additional Hardware Devices

    Using Additional Hardware Devices Using an External Answering Machine The SX5T can be used with an external answering machine in place of voicemail. If you plan to use an external answering machine, be sure your service provider has not activated voicemail on your account.

  • Page 22: Windows Xp/Windows 2000 Setup For Data & Pc Fax

    Use a Telular USB cable (part #1L01A043 or 81025901) to connect the computer’s USB port to the SX5T’s data port. (You will also need to run the Telular USB Driver CD to load the appropriate USB driver onto your PC.) ·...
  • Page 23 Click on Add… . Click on Don't detect my modem; I will select it from a list and click Next . Select Standard 19200 bps modem and click Next . Phonecell SX5T CDMA2000 User Manual ®...
  • Page 24 Select the COM port to use (if a COM port does not display, all COM ports are currently allocated). Click Finish . Phonecell SX5T CDMA2000 User Manual ®...
  • Page 25 Configure the SX5 modem interface using the Start > Settings > Control Panel > Phone and Modem Options > Modems tab. Select the 19200 bps Modem and click on Properties . Select the Modem tab. Change the Maximum port speed to 115200 (19200 when faxing) and click OK . Phonecell SX5T CDMA2000 User Manual...
  • Page 26 Configure the USB, Serial or Phone (RJ11) port using the Control Panel > System >Hardware > Device Manager > Ports tab. Select the port used for the SX5T and right click on it. Select Properties from the resulting pop-up menu. Phonecell SX5T CDMA2000 User Manual...
  • Page 27 Click on the Port Settings tab. Use these settings: Bits per second: 115200 (19200 when faxing) Data bits: 8 Parity: None Stop bits: 1 Flow control: Hardware You may now send or receive data and PC faxes. See Sending/Receiving a PC Fax (page 28), Sending/Receiving 1X Data (page 29), or Sending/Receiving Circuit Switched Data (page 30) for details.

  • Page 28: Windows 98 Setup For Data & Pc Fax

    Connect and Select Data Ports. Serial Connection – default setting (Allows PC Fax, 1X Data and Circuit Switched Data) · Use a Telular serial cable (part #1L01A042 or 81025801) to connect the computer’s serial port to the SX5T’s data port. ·...
  • Page 29 Select Standard 19200 bps Modem and click on Properties . Select the appropriate COM port and Maximum speed of 115,200 bps for data and 19,200 bps for PC Fax. Select the Connection tab. Phonecell SX5T CDMA2000 User Manual ®...
  • Page 30 Set Connection Preferences to Data bits = 8, Parity = None and Stop bits = 1, then click Advanced . Check the box for Use Control Flow , then click on Hardware (RTS/CTS) , and then select OK . Phonecell SX5T CDMA2000 User Manual ®...
  • Page 31 Click on OK . Click on Close . You may now send or receive data and PC faxes. See Sending/Receiving a PC Fax (page 28), Sending/Receiving 1X Data (page 29), or Sending/Receiving Circuit Switched Data (page 30) for details. Phonecell SX5T CDMA2000 User Manual ®...

  • Page 32: Sending/Receiving A Pc Fax

    Sending/Receiving a PC Fax A PC with a serial, USB, or phone (RJ11) connection to the SX5T can send and receive faxes using the SX5T. Your account with your service provider must support circuit switched data transfer for the SX5T’s PC fax function to work. Set Your Computer’s Port and Modem Speeds for PC Fax To send or receive faxes, you need to set the port and modem speeds your computer uses for the SX5T to 19200 bps.

  • Page 33: Sending/Receiving 1X Data

    Sending/Receiving 1X Data A PC with a serial or USB connection to the SX5T can send and receive 1X data using the SX5T; a PC with a phone (RJ11) connection cannot. Check with your service provider to see if your account supports 1X data transfer.

  • Page 34: Sending/Receiving Circuit Switched Data

    Sending/Receiving Circuit Switched Data A PC with a serial, USB or phone (RJ11) connection to the SX5T can send and receive circuit switched data using the SX5T. Check with your service provider to see if your account supports circuit switched data transfer. Set Your Computer’s Port and Modem Speeds for Circuit Switched Data To send or receive circuit switched data, you need to set the port and modem speeds your computer uses for the SX5T to 115200 bps.

  • Page 35: Sx5T-500C Advanced Programming Settings

    Advanced Programming Settings Note: The SX5T advanced programming settings are intended primarily for advanced users and system administrators. It is strongly recommended that these settings be altered by qualified technicians only. Entering Configuration Mode (Advanced Settings) The following advanced programming settings require you to place the SX5T in configuration mode. (For more information, see “Entering Configuration Mode”...
  • Page 36 Ring Frequency If required by your system or equipment settings, you may adjust the frequency of the ring signal. To adjust the ring frequency values: • From Configuration Mode, press <0, 1, or 2> , where <0, 1, or 2> are as follows: 0 = 20 Hz –...
  • Page 37 Caller ID Display Setting (SX5T-500C) The SX5T supports two types of caller ID devices: those that require the information to be transmitted to the caller ID device (phone) between the first and second rings (common in North America), and those that require the information to be transmitted prior to the first ring (common in certain European countries).
  • Page 38 Metering Pulse High Gain/Low Gain If required for your phone system application, you may adjust the metering pulse generated by your SX5T from high gain (default setting) to low gain. The gain values are as follows: For 12Khz systems: Low gain = -2dbm (+/- 2dbm) High gain (default) = 1dbm (+/- 2dbm) For 16Khz systems: Low gain = -6dbm (+/- 2dbm)

  • Page 39: Sx5T Troubleshooting

    SX5T Troubleshooting Telephone Service is Not Working (Cannot make or receive calls) • Make sure the SX5T powered on properly. • Make sure any equipment that is externally connected to the SX5T is connected correctly. • Test any externally connected equipment on a known system to verify its operation. •...

  • Page 40: Conformance Statements

    Part 15, Part 22 and Part 24 of the FCC rules. Changes or modifications not expressly approved by Telular Corporation will void your authority to operate the equipment per FCC part 15 paragraph 15.21.These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 41: Blasting Areas

    Driving Check the laws and regulations on the use of cellular products in the areas where you drive. Some jurisdictions prohibit use of a cellular device while driving a vehicle. Even if your jurisdiction does not have such a law, we strongly suggest that, for safety reasons, the driver use extreme caution when operating the cellular device while the vehicle is in motion.
  • Page 42 Patents Telular Corporation products are protected and manufactured under one or more of the following U.S. patents and related international patents and patents pending relating thereto: 4,658,096 4,737,975 4,775,997 4,868,519 4,922,517 5,134,651 5,361,297 5,469,494 5,046,085 5,715,296 6,775,522 6,778,824 6,785,517. Trademarks...
  • Page 43 Phonecell SX5T CDMA2000 User Manual ®...
  • Page 44 647 North Lakeview Parkway Vernon Hills, Illinois 60061, USA Tel: 847-247-9400 • Fax: 847-247-0021 E-mail: support@telular.com http://www.telular.com ©2004 Telular Corporation, all rights reserved. Part Number 56029901...

This manual is also suitable for:

Phonecell sx5t-505c cdma2000 1xPhonecell sx5t-535c cdma2000 1xPhonecell sx5t-500c cdma2000 1x
