- Page 1 Phonecell SX5T-515C ® CDMA2000 ® Fixed Wireless Terminal 1900 MH CDMA ANUAL 10/05/06 Part Number 56036001...
- Page 2 QUICK CONNECTION GUIDE SX5 Fixed Wireless Terminal Phonecell SX5T CDMA User Manual ®...
-
Page 3: Contents
PRODUCTS ("Product") ® These Terms and Conditions are a legal contract between you and Telular Corporation for the title to and use of the Product. BY RETAINING AND USING THE PRODUCT AFTER RECEIPT OF IT, YOU AGREE TO THE TERMS AND CONDITIONS INCLUDING WARRANTY DISCLAIMERS, LIMITATIONS OF LIABILITY AND INDEMNIFICATION PROVISIONS BELOW. -
Page 4: Table Of Contents
TABLE OF CONTENTS QUICK CONNECTION DIAGRAM.................ii CONTENTS ........................iii Safe Operation Instructions ..................iii Important Notices.......................iii Technical Support ......................iii SETUP ...........................1 Connecting an SX5T Model With a Power Supply ............1 Emergency Batteries....................2 Connecting an SX5T Model With a BBU (Backup Battery Unit)........3 SX5T Location and Installation ..................4 Wall Mounting......................4 GPS Antenna Mounting .....................5... -
Page 5: Setup
Setup Connecting an SX5T Model With a Power Supply Your SX5T has either a Power Supply (part #74007301) or a Battery Backup Unit (BBU; part #74006803). If your unit uses a Power Supply, please follow the instructions below to connect the SX5T to your AC power. If it uses a BBU, please see “Connecting an SX5T Model With a BBU”... -
Page 6: Emergency Batteries
Emergency Batteries If your SX5T has a Power Supply, you may install emergency batteries to power the device in the event of a power outage. Do not install emergency batteries if your SX5T has a BBU. The SX5T will not automatically switch to battery if AC power fails; you must flip the AC/Battery switch to battery operation - see Figure 5. -
Page 7: Connecting An Sx5T Model With A Bbu (Backup Battery Unit)
Connecting an SX5T Model With a BBU (Backup Battery Unit) Your SX5T has either a Power Supply (part #74007301) or a Battery Backup Unit (BBU; part #74006803). If your model has a BBU, it is shipped with the battery disconnected to prevent if from being prematurely drained. -
Page 8: Sx5T Location And Installation
SX5T Location and Installation The SX5T comes with a standard spike antenna (TNC) - see Figure 7. For optimal signal strength, choose a location that is above ground and as close to windows (or exterior walls) as possible - see Figure 8. -
Page 9: Gps Antenna Mounting
GPS Antenna Mounting To satisfy the FCC's Enhanced 911 (E-911) Phase II mandate, a GPS antenna with a mounting bracket and suction cups is supplied with this unit. The GPS antenna uses satellite technology during emergency calls to automatically report your location to a 911 dispatcher within 50-100 meters in most cases. -
Page 10: Getting To Know Your Sx5
GETTING TO KNOW YOUR SX5 LED Status Indicators The LED indicators are activated when the SX5 is powered on. The following tables describe the modes and operation of the indicators. NOTE: If you are getting no service, contact your service provider for more information. RSSI 3 RSSI 2 RSSI 1... -
Page 11: Important Dial Tones
Hook Indicator LED Color Activity Description Green Flashing (with ringer) Incoming call Green Continuous FWT is off hook Green Fast Flashing Processing data call Green Slow Flashing Call on hold Message Indicator LED Color Activity Description Green Slow Flashing New voice mail AC Power/Battery Indicator LED Color Activity... -
Page 12: Call Functions
CALL FUNCTIONS Making Calls 1. Pick up the telephone handset (the phone is now “off-hook”). 2. Listen for dial tone. If service is not available, a No-Service tone is produced. Hang-up the phone and try again. If the No-Service tone continues, contact your service provider to verify that cellular service is available. -
Page 13: Accessing Voice Mail
Call Forwarding To use Call Forwarding, press *72 followed by the 10-digit number to which you want to forward calls, then press FLASH. Entering Configuration Mode To change the following phone setting options, you must first enter Configuration Mode: Audio Line Level, Auto-Send Delay, Frequently Dialed Numbers (Zero Delay Dialing), Pulse Dialing, and TTY Use. -
Page 14: Emergency 911 Mode
Emergency 911 Mode When hanging up after you dial 911, you will have to exit emergency 911 mode. Until you do this, you will hear an audio indication and you will not be able to make any other calls. To exit emergency 911 mode, press #*119#. -
Page 15: Sx5 Troubleshooting
SX5 TROUBLESHOOTING Telephone Service is Not Working (Cannot make or receive calls) · Make sure the SX5 powered on properly. · Make sure any equipment that is externally connected to the SX5 is connected correctly . · Test any externally connected equipment on a known system to verify its operation. ·... -
Page 16: Conformance Statements
Part 15, Part 22 and Part 24 of the FCC rules. Changes or modifica- tions not expressly approved by Telular Corporation will void your authority to operate the equip- ment per FCC part 15 paragraph 15.21.These limits are designed to provide reasonable protec- tion against harmful interference in a residential installation. -
Page 17: Blasting Areas
installed or inadequately shielded electronic operating and entertainment systems in motor vehi- cles. Check with the manufacturer or its representative to determine if these systems are ade- quately shielded from external RF energy. You should also check with the manufacturer of any equipment that has been added to your vehicle. -
Page 18: Warranty
(15) months from date of shipment from Telular. Telular, at its option, shall at no charge either repair, replace or refund the purchase price of the Product during the warranty period, provided it is returned by Buyer in accordance with the terms of this warranty to the Telular designated repair center. - Page 19 LIMITATION ON HOW LONG AN IMPLIED WARRANTY LASTS. VI. SOFTWARE PROVISIONS: Laws in the United States and other countries preserve for Telular certain exclusive rights for copyrighted Telular software such as the exclusive rights to reproduce in copies and distribute copies of such Telular software.
- Page 20 647 North Lakeview Parkway Vernon Hills, Illinois 60061, USA Tel: 847-247-9400 • Fax: 847-247-0021 E-mail: support@telular.com http://www.telular.com ©2006 Telular Corporation, all rights reserved. Part Number 56036001...
