  • Page 4: Important Safety Instructions

    ENGLISH IMPORTANT SAFETY INSTRUCTIONS Danger 1. Read all safety and operating instructions before using this Exposure to extremely high noise levels may cause a permanent product. hearing loss. Individuals vary considerably to noise induced hearing 2. All safety and operating instructions should be kept for future loss but nearly everyone will lose some hearing if exposed to sufficiently reference.

  • Page 5: Importantes Instructions De Securite

    FRENCH IMPORTANTES INSTRUCTIONS DE SECURITE 1. Lire avec attention toutes les recommandations et précautions d'emploi avant d'utiliser ce produit. Danger 2. Toutes les recommandations et précautions d'emploi doivent être L‘exposition a des niveaux eleves de bruit peut provoquer une perte conservées afin de pouvoir s'y reporter si nécessaire.
  • Page 6 Introduction Congratulations on your purchase of the NuVo Simplese System. Simplese brings the best of today's digital technology to a true whole-home audio system. Listening to multiple audio sources from independent zones throughout the home has never been easier or more affordable.

  • Page 7: Wiring Diagram

    TNR2 TNR1 TNR2 TNR1 TNR2 TNR1 TNR2 MODEL NV-P2100 HIGH EFFICIENCY 200 WATT STEREO AMPLIFIER 120V 60HZ WATTS NuVo Technologies Cincinnati Ohio. USA AUDIO CONTROL CONTROL SPEAKER SENSITIVITY POWER VOLTAGE UNIT OUTPUT POWER OdBV = 1.0RMS MODE TRIGGER 8 OHM: 70W X 2...
  • Page 8 This is used for factory purposes only and has no system function relevance. 7. LINK This 3.5mm mono output is used to expand the Simplese System from four to eight zones; see Using the Link Jack to Create Eight Zones, pg. 12.

  • Page 9: Keypad Features

    Keypad Features 1. Volume Level The level of the zone volume is indicated by these LEDs (light emitting diodes). 2. Volume Independent audio volume level for each zone is controlled with this button. 3. IR Receiver Each keypad has an IR (infrared) receiver located under the volume button for wireless control of the VOLUME...

  • Page 10: Installing The Simplese System In Your Home

    Installing the Simplese System in Your Home I. Prewire The Simplese System uses Cat-5 cable for keypad control and either two- or four-conductor 16- gauge speaker wire. All the wire is “homerun” from each zone to the location of the Allport connection hub.

  • Page 11: Speaker Wire Termination

    Fig. 2 as positive and green as negative for the second speaker. Note: The Simplese System is designed to handle one pair of 8-ohm speakers per zone. Using more than one pair of speakers per zone could cause damage to the amplifier output.

  • Page 12: Installing The Simplese Amplifier

    Simplese amplifier using stereo RCA cables, fig. 4. IR Outputs ZONE 4 38KHz 56KHz Fig. 5 The Simplese System ships with four IR emitters for transferring IR data from the keypad receivers NORMAL USE FOR SAT FIXED OR CABLE SOURCE INPUT...
  • Page 13 Down disables the group function and causes the keypad to operate independently of all other groups, fig. 8. Volume Reset The Simplese System keypads automatically reset the listening volume to a low level when all zones have been Group Disabled Group Enabled turned off and a zone is turned on again.

  • Page 14: Master Mode/All On

    Master Mode/All On The Simplese System has an All On feature. Any keypad The lit volume LED will within the system, which can be up to eight zones, has the flash when the keypad ability to become a master control for the entire house. The is in Master Mode.
  • Page 15 Zone 4 is equipped with two types of pre-amp lineouts for use with an additional amplifier. This can be dedicated to an outdoor zone or large living area that would benefit from more than one pair of speakers. NuVo manufactures a 200-watt stereo amplifier specifically designed for this purpose, called the P2100, although any audio amplifier can be used with the lineouts.
  • Page 16 The fixed lineout can be used for zones where it is more appropriate to have a separate volume control from the NuVo keypad for the external amplifier, fig. 10. A good example of this use would be an outdoor zone that is being used in conjunction with zone 4.
  • Page 17 Mute Input and the NuVo MI1 The back panel of the Simplese amplifier has a 3.5mm mono input labeled MUTE. This is designed to be used with the NuVo MI1 Mute Interface. When the MI1 is connected, the system will temporarily mute when the phone or doorbell rings, fig. 11.
  • Page 18 Input Sensitivity for rated power 300mV RMS Unit Weight Kilograms 2.95 Input Overload 3V RMS Unit Weight Pounds Emitter Outputs NuVo reserves the right to change specifications Source Outputs without notice. Output Drive Current 100mA Output Drive Voltage Source 1&2 38kHz/56kHz Selectable Source 3&4...
  • Page 20 420NA4DS011 SMP 510 05 0541 NuVo Technologies 4940 Delhi Pike Cincinnati, Ohio 45238, USA www.nuvotechnologies.com Ph: 513-347-2180...
