Page 4: Important Safety Instructions
ENGLISH Danger Exposure to extremely high noise levels may cause a permanent hearing loss. Individuals vary considerably to noise induced hearing loss but nearly everyone will lose some hearing if exposed to sufficiently intense noise for a sufficient time. The U.S. Government's Occupational Safety and Health Administration (OSHA) has specified the following permissible noise level exposures: DURATION PER DAY (HOURS) 8 6 4 3 2 1... -
Page 5: Importantes Instructions De Securite
FRENCH Danger L‘exposition a des niveaux eleves de bruit peut provoquer une perte permanente de l’audition, Chaque organisme humain reagit differemment quant a la perte de l’audition, mais quasiment tout le monde subit une diminution de I’acuite auditive lors d’une exposition suffisamment longue au bruit intense. - Page 6 Introduction Congratulations on your purchase of the NuVo Simplese System. Simplese brings the best of today's digital technology to a true whole-home audio system. Listening to multiple audio sources from independent zones throughout the home has never been easier or more affordable.
- Page 7 ALL PORT CONNECTION Audio Source 4 Audio VOLUME MUTE MODEL NV-P2100 HIGH EFFICIENCY 200 WATT STEREO AMPLIFIER 120V 60HZ WATTS NuVo Technologies Cincinnati Ohio. USA AUDIO CONTROL CONTROL SPEAKER SENSITIVITY POWER VOLTAGE UNIT OUTPUT POWER OdBV = 1.0RMS MODE TRIGGER...
- Page 8 Simplese LINK ON=+12V SPEAKER AND DATA SIGNALS MUTE RS232 NORMAL USE FOR SAT OR CABLE IR OUT SYSTEM ALL PORT CONNECTION FOUR-SOURCE FOUR-ZONE CONFORMS TO UL STD.6500 CERTIFIED TO 100~240V 50~60Hz 85W CAN/CSA STD.E60065 NuVo Technologies Cincinnati Ohio USA 3033118...
- Page 9 Keypad Features 1. Volume Level The level of the zone volume is indicated by these LEDs (light emitting diodes). 2. Power The power button turns that keypad's zone on and off independently of the other zones. Pressing and holding the power button turns all the zones off simultaneously.
-
Page 10: Installing The Simplese System In Your Home
“homerun” from each zone to the location of the Allport connection hub. Complete Cat 5 Crimping Instructions The NuVo audio systems require Cat 5, unshielded, twisted pair (UTP), for communication between the keypads/Display Pads and the main amplifier unit. Each end of the wire is terminated with an RJ45 connector. - Page 11 Allport cable supplied with the Simplese System, fig. 3. STATUS LINK ON=+12V MUTE RS232 SYSTEM SYSTEM FOUR-SOURCE FOUR-ZONE Simplese 100~240V 50~60Hz 85W SPEAKER AND DATA SIGNALS NuVo Technologies Cincinnati Ohio USA 3033118 ALL PORT CONNECTION Fig. 2 CONFORMS TO UL STD.6500 CERTIFIED TO CAN/CSA STD.E60065 Fig. 3...
- Page 12 Cat-5 splitter. Fig. 4 ZONE 4 38KHz NORMAL FIXED SOURCE INPUT LINE OUT Fig. 6 Simplese D Keypad Model NV-A4DKP-DC-BT NuVo Technologies LLC Cincinnati, Ohio USA www.nuvotechnologies.com Network Connection ZONE 4 FIXED SOURCE INPUT LINE OUT Source 1 Audio Tuner 1 56KHz Fig.
- Page 13 EQ Control and Source Grouping The keypads can be used to set specific zone functions. FLAT These are for bass and treble EQ response and source -4 dB +4 dB grouping. To change bass response, press the Mute -6 dB button and Source 1 button simultaneously.
-
Page 14: Master Mode/All On
Master Mode/All On The Simplese System has an All On feature. Any keypad within the system, which can be up to eight zones, has the ability to become a master control for the entire house. The master keypad will control zone on, volume level, and source selection for all other zones. - Page 15 Zone 4 is equipped with two types of pre-amp lineouts for use with an additional amplifier. This can be dedicated to an outdoor zone or large living area that would benefit from more than one pair of speakers. NuVo manufactures a 200-watt stereo amplifier specifically designed for this purpose, called the P2100, although any audio amplifier can be used with the lineouts.
- Page 16 The fixed lineout can be used for zones where it is more appropriate to have a separate volume control from the NuVo keypad for the external amplifier, fig. 10. A good example of this use would be an outdoor zone that is being used in conjunction with zone 4.
- Page 17 Mute Input and the NuVo MI1 The back panel of the Simplese amplifier has a 3.5mm mono input labeled MUTE. This is designed to be used with the NuVo MI1 Mute Interface. When the MI1 is connected, the system will temporarily mute when the phone or doorbell rings, fig. 12.
- Page 18 600 Ohms Physical Specifications Unit Size Millimeters Unit Size Inches 300mV RMS Unit Weight Kilograms 3V RMS Unit Weight Pounds NuVo reserves the right to change specifications without notice. 100mA 38kHz/56kHz Selectable 38kHz 5V @ 50mA 3-12V DC 90-260VAC 50/60Hz...
- Page 20 SMP 510 05 0541 NuVo Technologies 4940 Delhi Pike Cincinnati, Ohio 45238, USA www.nuvotechnologies.com Ph: 513-347-2180...
