2
Assemble Floor
2a Lay Outer Floor Panel (109) fl at on the ground.
Hold a Center Floor Panel (110) at an angle
(as shown) and fi t tabs into slots and lay Center Floor
Panel fl at. Add next Center Panel (110) and last Outer
Panel (109).
1.
109
3
Assemble Window
3a Remove plastic sheeting from Window (AA) and slide
Window into slot on the Window Wall Panel (125).
Attach a Window Latch (HQ) above each corner of the Window
as shown. When tightening Screws (SS), ensure the Window
Latches slide freely.
3b
Do not overtighten. Insert Screw (TC) into the hole in the
window. Set panel aside. Repeat steps 3a and 3b for the
second Window.
Insert window
with bent edge at
top and pointing
away from the wall.
8

Before Beginning!

Remove the Parts List from the center of this manual, and locate
color "Construction Tips" insert in box.
110
2.
Hardware Bags:
1001632
CAUTION
Sharp objects may damage your
floor. If resting sharp, heavy
objects on your shed fl oor, place a
block of wood between the sharp
object and fl oor.
3.
110
SS (8)
HQ (4)
1015974 Screwdriver
1004015
HQ
Place screw (TC) in this hole to
keep window from sliding up
too far. Insert until fl ush with the
109
TC (2)
HQ
window
