OUTDOOR STORAGE
MODEL N° 6422
OWNER'S MANUAL
Keep this Identification Number in case you need to contact our Customer Service Department.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6422 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lifetime 6422

Summary of Contents for Lifetime 6422

  • Page 1 OUTDOOR STORAGE MODEL N° 6422 OWNER’S MANUAL Keep this Identification Number in case you need to contact our Customer Service Department.
  • Page 2 IMPORTANT! PLEASE READ BEFORE BEGINNING ASSEMBLY Dear Valued Customer, We would like to congratulate you on your purchase of a Lifetime© Outdoor Storage Shed! We are confi dent that you have made the perfect choice and you will be very pleased with your new storage solution.
  • Page 3 IMPORTANT! PLEASE READ BEFORE BEGINNING ASSEMBLY inventory of the parts included with your Outdoor Storage Shed. Also, read through the entire instruc- tion manual. It’s always a great practice to get a feel for the fl ow of the process and to familiarize your- self with the parts involved.

  • Page 4: Safety Instructions

    REGISTER YOUR LIFETIME PRODUCT TODAY! There are benefi ts to registering your Lifetime product. With our new online product registration form, it’s fast and easy! Register with us at www.lifetime.com and enjoy these great benefi ts: promotions! But you will need to provide a sales receipt to verify your product purchase date before warranty service will be provided. LIFETIME’S PROMISE TO YOU: Maintaining your privacy is our long-standing policy at Lifetime.

  • Page 5: Before Beginning Assembly

    BEFORE BEGINNING ASSEMBLY Keep the hardware bags and their contents separate. If any parts are missing, call our Customer Service Department. Identify and inventory all parts and hardware using the parts and hardware lists and identifi ers in this document. *Two adults required to complete assembly* (+ one adult suggested as an instruction reader)
  • Page 6 ASSEMBLY GUIDES Refer to the following areas throughout the instructions to assist in the assembly process: This area is located at the top, left-hand TOOLS AND HARDWARE REQUIRED FOR THIS PAGE corner of the page and indicates which tools and hardware are needed to complete the assembly steps on a page.

  • Page 7: Important Notices

    IMPORTANT NOTICES Level Surface Notice: Surface must be leveled before installation. We recommend building a level work space with a concrete or patio style surface. If the surface is not properly leveled, the Outdoor Shed will not assemble correctly. Proper surface leveling will save you time in the long run, so please do not ignore this step. Building Code Notice: Consult all local building codes, as well as city and county ordinances, to ensure that the construction of the Outdoor Shed does not require a building permit.

  • Page 8: Parts & Hardware List

    PARTS & HARDWARE LIST Description Quantity Description Quantity Main Parts BJL 6422 Hardware Bag BEA Truss Assembly Hardware Skylight Truss Connector 1/4” Threaded Rod CSG Floor Assembly Hardware BGT Wall & Roof Installation Hardware 1/4” x 5/8” Phillips Pan-Head Screw...

  • Page 9: Parts Identifier

    HARDWARE IDENTIFIER SKYLIGHT INSTALLATION HARDWARE [BGS] Hardware shown at actual size ADX (x6) AED (x6) PARTS IDENTIFIER Parts are shown at 4% of actual size (Unless indicated otherwise*) AFX (x1) Center Floor Panel Roof Panel AFY (x1) Center Roof Cap Wall Panel Parts are shown at 8% of actual size 48”...
  • Page 10 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO HARDWARE REQUIRED FOR THIS PAGE **SAVE ALL HARDWARE FOR RE-ASSEMBLY!** SHED DISASSEMBLY Remove last three Skylights and set aside. Note: You’re Shed may be a different length than the Shed shown, but the ideas are the same. Remove the back two Center Roof Caps and the Remove the back Roof Panels and Roof End Roof Cap and set aside.
  • Page 11 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO HARDWARE REQUIRED FOR THIS PAGE **SAVE ALL HARDWARE FOR RE-ASSEMBLY!** Remove the next Roof Panels and Roof Support Strips and set aside. Remove the Roof Truss Assembly and set aside.
  • Page 12 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO HARDWARE REQUIRED FOR THIS PAGE **SAVE ALL HARDWARE FOR RE-ASSEMBLY!** Remove the last two side Wall Panels and set aside. order to disconnect the Floor Panels Note: One person should support the rear Wall while it is being tipped and moved.
  • Page 13 FLOOR ASSEMBLY HARDWARE REQUIRED HARDWARE BAG REQUIRED: CSG Hardware shown at actual size BQC (x8) ADC (x1) PLASTIC PARTS REQUIRED Part shown at 4% of actual size AFX (x1) Center Floor Panel HARDWARE BAG REQUIRED: CSG TOOLS REQUIRED ADC (x1) Phillips Screwdriver Safety Glasses...
  • Page 14 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO HARDWARE REQUIRED FOR THIS PAGE Add new Center Floor Panel (AFX) need to tip the rear section forward slightly to connect the Center Floor Panels. Note: Tip up one floor panel and line up tabs and then lay floor panel flat.
  • Page 15 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE BQC (x8) #8 x 1/2” Pan-Head Screws (BQC) near the seam of a Floor Panel and down into the tab of the adjacent Floor Panel at the locations shown. Repeat this step for the second seam.
  • Page 16 TRUSS ASSEMBLY HARDWARE REQUIRED HARDWARE BAG REQUIRED: BEA Hardware shown at actual size ADY (x6) ADK (x6) *AIP (x1) 1/4” Cap Nut Truss Connector Part shown at 50% of actual size 12 11/16” ADH (x1) 1/4” Threaded Rod METAL PARTS REQUIRED Parts shown at 8% of actual size (*Unless indicated otherwise) 51”...
  • Page 17 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/8” ADY (x1) ADK (x1) TRUSS ASSEMBLY Stand a Truss Gutter Channel (AFH) upright and set a Truss Connector (AIP) inside the end of the Channel as shown. Align the holes and secure with one (1) #10 x 3/8” Pan-Head Screw (ADY) and one (1) #10 Cap Nut (ADK). Notch...
  • Page 18 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/8” ADY (x1) ADK (x1) Connect another Truss Gutter Channel (AFH) to the Truss Connector using one (1) #10 x 3/8” Pan-Head Screw (ADY) and one (1) #10 Cap Nut (ADK). Notch Notch...
  • Page 19 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 3/8” ADK (x4) ADY (x4) Lay the Truss Assembly on its side, and align the holes in a Roof Truss Brace (AFG) with those circled on the Truss #10 x 3/8” Pan-Head Screws (ADY) #10 Cap Nuts (ADK).
  • Page 20 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE 7/16” 12 11/16” ADH (x1) (Not to scale) With the Truss Assembly on its side, slide a 1/4” Threaded Rod (ADH) through the Roof Truss Brace and Truss Connector as shown. Secure the top and bottom of the 1/4” Threaded Rod with a 1/4” Cap Nut (ADJ). Tighten all hardware.
  • Page 21 WALL & ROOF INSTALLATION HARDWARE REQUIRED HARDWARE BAG REQUIRED: BGT Hardware shown at of actual size ADZ (x45) 1/4" x 5/8" Phillips Pan-Head Screw (Not all screws will be used) METAL PARTS REQUIRED Parts shown at 8% of actual size Roof Support Strip PLASTIC PARTS REQUIRED Parts shown at 4% of actual size...
  • Page 22 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ADZ (x10) USE THE 1/4” X 5/8” PHILLIPS PAN-HEAD SCREWS YOU REMOVED IN SECTION 1 TO HELP COMPLETE THE ASSEMBLY ON THIS PAGE Secure new Wall Panels (AHD), along with the Panels you removed, to the Shed using the Screws you removed from the Shed during disassembly and the 1/4”...
  • Page 23 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO NEW HARDWARE REQUIRED FOR THIS PAGE USE THE 1/4” X 5/8” PHILLIPS PAN-HEAD SCREWS YOU REMOVED IN SECTION 1 TO HELP COMPLETE THE ASSEMBLY ON THIS PAGE Install the Truss Assembly you removed in Section 1. While one adult holds the Truss Assembly in place, attach the Roof Panels and Roof Support Strips you removed in Section 1.
  • Page 24 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE NO NEW HARDWARE REQUIRED FOR THIS PAGE USE THE 1/4” X 5/8” PHILLIPS PAN-HEAD SCREWS YOU REMOVED IN SECTION 1 TO HELP COMPLETE THE ASSEMBLY ON THIS PAGE Attach a Center Roof Cap you removed in Section 1.
  • Page 25 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE USE THE 1/4” X 5/8” PHILLIPS PAN-HEAD SCREWS YOU REMOVED IN SECTION 1 TO HELP COMPLETE THE ASSEMBLY ON THIS PAGE Install the Roof Panels (AGQ) and Roof Support Strips (AFL) using the hardware furnished with this kit. Install a Center Roof Cap you removed in Install the Roof Panels and Roof Support Strips Section 1 using the hardware from Section 1.
  • Page 26 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ADZ (x6) USE THE 1/4” X 5/8” PHILLIPS PAN-HEAD SCREWS, THE #10 X 1/2” PHILLIPS PAN-HEAD SCREWS, AND THE #10 X 1” FENDER WASHERS YOU REMOVED IN SECTION 1 TO HELP COMPLETE THE ASSEMBLY ON THIS PAGE Install the Center Roof Cap (AFY) furnished with this kit and the End Roof Cap you removed in Section 1 using the hardware you removed in Section 1 and the hardware furnished with this kit.
  • Page 27 SKYLIGHT INSTALLATION HARDWARE REQUIRED HARDWARE BAG REQUIRED: BGS Hardware shown at of actual size ADX (x6) AED (x6) PLASTIC PARTS REQUIRED Part shown at 8% of actual size AHC (x1) Skylight TOOLS REQUIRED Phillips Screwdriver Safety Glasses...
  • Page 28 TOOLS AND HARDWARE REQUIRED FOR THIS PAGE ADX (x6) AED (x6) Install the Skylights you removed in Section 1 and the Skylight (AHC) furnished with this kit using the required hardware.
  • Page 29 LIFETIME OUTDOOR SHED EQUIPMENT 10-YEAR LIMITED FACTORY WARRANTY THE MANUFACTURER RESERVES THE RIGHT TO MAKE SUBSTITUTIONS TO WARRANTY CLAIMS IF PARTS ARE UNAVAILABLE OR OBSOLETE. 1. Lifetime outdoor sheds are warranted to the original purchaser to be free from defects in material or workmanship impair the use of the product.
