  6. Assembly instructions and owner's manual

Lifetime 6424 Assembly Instructions And Owner's Manual

30” shed extension kit
Hide thumbs Also See for 6424:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
5/1/2006
®
VISIT THE LIFETIME WEB SITE:
WWW.LIFETIME.COM
** Do Not Contact the Store **
For Assistance, including missing or broken parts,
Call Customer Service at:
1 (800) 225-3865
30" Shed Extension Kit
MODEL #6424
ASSEMBLY
INSTRUCTIONS AND
OWNER'S MANUAL
Save this instruction in the event that the manufacturer has to be contacted for replacement parts.
INSTRUCTION #1012324

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6424 and is the answer not in the manual?

Questions and answers

Related Manuals for Lifetime 6424

Summary of Contents for Lifetime 6424

  • Page 1 5/1/2006 ® VISIT THE LIFETIME WEB SITE: WWW.LIFETIME.COM ** Do Not Contact the Store ** For Assistance, including missing or broken parts, Call Customer Service at: 1 (800) 225-3865 30” Shed Extension Kit MODEL #6424 ASSEMBLY INSTRUCTIONS AND OWNER’S MANUAL Save this instruction in the event that the manufacturer has to be contacted for replacement parts.
  • Page 2 **A MINIMUM OF TWO ADULTS ARE REQUIRED FOR ASSEMBLY** BEFORE BEGINNING ASSEMBLY ® VISIT THE LIFETIME WEB SITE: Identify and inventory all parts using the checklist boxes on the Parts List. Keep the WWW.LIFETIME.COM hardware bags and their contents separate. If any parts are missing, call our Customer Service Department.
  • Page 3 **Save all hardware for re-assembly!** HARDWARE IS ACTUAL SIZE (unless otherwise indicated) Remove last three skylights. Remove the back 3 roof caps. Tools and Materials Required for Assembly (Not Included) 7/16” Wrenches (2) 3/8” Wrenches (2) #2 Phillips screwdriver or Electric drill with pillips head If you are Installing a New Shed 1.
  • Page 4 Remove the next Roof panels and Roof support bars. Remove the last two Side Wall Panels. Slide the back section of the shed away from the front. You Remove the Roof Truss. will need to tip the back section forward slightly in order to disconnect the fl...
  • Page 5 Assemble Window Add new fl oor panel. Then, slide the back section into place Remove plastic sheeting from Window (AE) and slide Window and connect the fl oor panels (you will need to tip the panels forward into slot on the Window Wall Panel (125). Attach a Window Latch (TK) slightly to connect the panels).
  • Page 6 11 Assemble Truss Slide a Threaded Rod through the Truss Support Brace and the top of the Truss Connector. Attach Brace (AC) to two Roof Truss Channels (AB) (one on each side of Brace. Secure Brace with screws (TF) and nuts (TE). Follow picture above to connect Brace to a Truss Channel at each end of the Brace.
  • Page 7 Add Truss. Add Truss. Add Roof panels and Roof Supports. Roof Panel Ridge Add Roof panels and Roof Supports. Roof Panel Wall Add a center Roof Cap. Add a center Roof Cap.
  • Page 8 ® Outdoor Shed purchase. By following the instructions below, your new Lifetime shed should provide you with years of service and enjoyment. Cleaning and Care The polyethylene walls and shelves are stain- and solvent resistant. To clean, use a mild soap and a soft-bristled brush.
