Overview

The IR-1 and the IR-1-01 can operate any Kramer RS-232 controlled
switcher or matrix that is listed in Table 2. Both the IR-1 and the IR-1-01:
Have their own hand held wireless remote control transmitter
includes the protocols of all Kramer devices and is programmable to control
any Kramer machine (see Figure 1)
Transmit to an identical remote receiver, either built-in (see Figure 2) or
external (see Figure 3). The remote receiver includes non-volatile memory that
retains the last setting, even after the power supply is interrupted
Achieving the best performance means:
Pointing the remote control transmitter directly at the remote receiver
(whether built-in or external)
Making sure that nothing blocks the path of the infra-red beam
Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and elevated
noise levels
Avoiding interference from neighboring electrical appliances that may
adversely influence signal quality
1 Both the IR-1 and IR-1-01 remote control transmitter deliver instantaneous results and have a range of up to 15 meters
2 For example, do not place a group of switchers in front of the remote receiver. This may prevent it from receiving signals
from the remote control transmitter
2
Overview
KRAMER: SIMPLE CREATIVE TECHNOLOGY
